Rotary Screw Compressor Care: Oil & Maintenance

Rotary screw air compressors are the workhorses of many industrial and automotive settings across the UK, known for their reliability and efficiency. However, like any sophisticated piece of machinery, their optimal performance and longevity hinge on proper care and, crucially, the right lubrication. Understanding the role of air compressor oil and adhering to a strict maintenance schedule is not just recommended; it's absolutely essential for ensuring your system operates without a hitch and provides years of dependable service.

Understanding Air Compressor Oil

Air compressor oil is a specialised lubricant, available in both standard and synthetic oil formulations, designed specifically for the rigorous demands of air compression systems. Unlike conventional motor oil, compressor oil is formulated without detergents and typically contains significantly lower levels of carbon, sulphur, and other contaminants. This unique composition is vital as it prevents the build-up of deposits that can hinder performance and damage internal components.

While recreational compressors might use standard oil, rotary screw air compressors almost exclusively rely on synthetic variants due to their superior performance characteristics under high pressure and temperature. The oil's appearance can vary in colour and composition, often presenting as yellow or light brown when new, gradually darkening as it accumulates contaminants over time.

The Vital Role of Oil in Rotary Screw Compressors

Within a rotary screw air compressor, oil performs several critical functions that are indispensable for its operation:

• Lubrication: It provides essential lubrication for all moving parts, significantly reducing friction and preventing premature wear.
• Sealing: The oil creates a crucial seal between the rotating elements (rotors), effectively trapping air and enabling efficient compression.
• Cooling: During the compression process, air heats up considerably. The oil helps to dissipate this heat, keeping the system cool and preventing overheating.
• Protection: By lubricating and cooling, oil protects components from excessive wear and tear, extending the lifespan of the compressor.

Many rotary screw air compressors are categorised as “oil-flooded” or “oil-injected.” This means that oil is directly injected into the rotor housing, where it mixes with the air during compression. Before the compressed air exits the system, the oil is meticulously separated and returned to the system, ensuring clean air output.

It's worth noting that some rotary screw air compressors are designed to be entirely oil-free. While these systems eliminate any risk of oil contamination in the compressed air, they generally come with a higher price tag and tend to be noisier. Oil-free compressors are typically reserved for highly specialised industrial applications where even the slightest oil contamination is unacceptable, such as in food processing or medical oxygen production.

Selecting the Right Oil for Your Compressor

Choosing the correct oil for your rotary screw air compressor is paramount. Always consult your compressor's owner's manual and review warranty details before making a decision. Manufacturers often specify a particular type or brand of oil that is essential for optimal performance and to maintain warranty validity.

For instance, some manufacturers rigorously test their systems with a specific high-performance synthetic rotary screw compressor oil, confirming its ideal chemical composition for component lubrication and protection, proper sealing between rotors, overheating prevention, and optimal air output.

Even if a manufacturer doesn't specify an exact brand, they will typically recommend a 20-weight or 30-weight non-detergent oil. The choice between these often depends on the operating environment:

• 20-weight oil: Generally preferred for colder climates and winter seasons.
• 30-weight oil: Better suited for warmer environments and summer seasons.

Some operators may even switch between these oil weights seasonally to ensure consistent performance year-round.

Maintaining Your Air Compressor Oil

Regular oil maintenance is key to keeping your air compressor in prime condition and upholding its warranty. Always follow the manufacturer's specific service maintenance schedule.

When to Change Your Air Compressor Oil

Oil service intervals can vary significantly, even among different models from the same manufacturer. Below is an example of service intervals for various compressor types:

As illustrated, the recommended service hours and timeframes differ considerably. Therefore, always refer to your specific air compressor's manual to determine the correct oil change schedule. If you cannot locate the manual, contact the manufacturer directly for guidance.

How to Check the Air Compressor Oil Level

Checking the oil level should be a daily routine or performed every time you use the air compressor. Follow these straightforward steps:

1. Ensure the vehicle (if applicable) is parked on level ground and that the compressor system is fully depressurised and cool to the touch.
2. Locate the oil sight glass, if present. The oil level should typically be between the “MAX” and “ADD” arrows or designated marks.
3. If the level is below the required mark, carefully remove the fill cap on the tank. Use a funnel to add the appropriate oil, pouring slowly to avoid overfilling.
4. Continuously monitor the sight glass (or dipstick) until the desired oil level is achieved.
5. Replace the fill cap securely.

If your air compressor lacks a sight glass, you'll likely find a dipstick. Remove the oil fill cap, pull out the dipstick, and check the “min” and “max” lines at the bottom tip to determine if more oil is needed.

Changing Your Air Compressor Oil

While the basic principle of an oil change involves draining old oil and adding new, the specific steps can be quite detailed and vary by model. Always consult your compressor's manual for precise instructions. As an example, here are typical steps for changing oil in some gas-powered air compressors:

1. Thoroughly clean the area around the air compressor's tank and oil filter to prevent any contamination.
2. Remove the oil drain plug and allow the old oil to drain completely into a suitable container (e.g., a 4-litre capacity container).
3. Inspect the O-ring on the oil drain plug for any damage, hardening, or defects. Replace if necessary.
4. Install and securely tighten the oil drain plug.
5. Remove the old oil filter. Verify that the threaded nipple did not unscrew with the filter. If it did, carefully remove it from the filter, avoiding thread damage. To reinstall, clean the threads thoroughly, apply a thread locker (e.g., Loctite 242 blue) to the short-threaded end, and replace it in the air oil separator tank.
6. Clean the gasket sealing surface on the tank's front, inspecting for damage. It must be smooth and free of old gasket material for a proper seal.
7. Apply a thin coat of new compressor oil to the rubber gasket of the new oil filter.
8. Spin the new filter onto the threaded nipple until the gasket makes contact with the sealing surface on the tank. Then, tighten the filter an additional 3/4 to 1 full turn to properly seat the gasket.
9. Remove the filler cap on the oil tank.
10. Fill the tank with the recommended compressor oil until the oil level in the sight glass reaches the “MAX” mark. Note that systems may hold approximately 4 to 9 litres of oil.
11. Recheck the oil level at the sight glass and continue adding oil until the level is correct.
12. Reinstall the fill cap securely.
13. Start the engine and meticulously check for any oil leaks. Allow the system to build to its factory-set pressure (e.g., 145 psi) and for the engine speed to decrease to base idle.
14. Turn off the engine. After allowing the system to sit for approximately 5 minutes, recheck the oil level through the sight glass. The level must be between the “MIN” and “MAX” indicators.
15. Finally, verify there are no oil leaks before resuming operation.

How Much Oil Do I Need?

The oil capacity of air compressors varies significantly, with no universal standard across manufacturers. While some systems may hold approximately 4-9 litres of compressor oil, others may require more or less. Always consult your air compressor's manual or contact the manufacturer directly to determine the exact oil quantity needed for your specific system.

Where to Purchase Air Compressor Oil

Air compressor oil can typically be purchased from specialist air compressor dealers, well-stocked hardware stores, and some automotive shops. For specific brands, it's often best to buy directly from authorised dealers.

Rotary Screw Air Compressor Maintenance: Beyond the Oil

Rotary screw air compressors are renowned for their robust design and relative ease of maintenance, offering many years of dependable service. From large industrial plants to small workshops, their simplicity and reliability make them a popular choice. When properly cared for, a rotary air compressor can deliver thousands of hours of unimpeded performance.

Why Regular Maintenance is Critical

Like all compressor types, rotary screw models require periodic attention. Thanks to their relatively simple internal components, maintenance is generally straightforward. Adhering to a consistent rotary screw compressor maintenance schedule will significantly prolong your machine's life and ensure optimal productivity.

1. Save Time and Money

A consistent maintenance schedule dramatically reduces the risk of unexpected system downtime. Routine check-ups enable early detection of potential problems, addressing them before they escalate into more serious, costly issues. Identifying a problem early often means a quick, inexpensive fix, preventing significant losses in productivity.

2. Prevent Emergency Repairs

An irregular maintenance schedule increases the likelihood of sudden, unexpected emergencies. Without regular internal inspections, issues can develop unnoticed, even in relatively new compressors. A sudden breakdown can be time-consuming and expensive to diagnose and repair. Consistent, periodic maintenance allows you to pinpoint and remedy issues almost immediately, avoiding costly emergencies.

3. Improve Your Compressor’s Life Expectancy

Sticking to a rotary screw air compressor maintenance schedule directly extends the compressor’s life expectancy. Regular inspections ensure you get a better return on your initial investment over the years. A well-maintained machine, inspected according to a strict schedule, will undoubtedly last longer and yield substantial productivity throughout its operational life.

Key Rotary Screw Compressor Maintenance Tasks

Rotary screw air compressors are built for heavy-duty operations, but they require periodic inspection to ensure optimal performance. Several key internal components can wear down over time if not properly maintained.

1. Airends

The airend is arguably the most crucial component, responsible for air pressurisation. While an airend can last for at least 40,000 hours, it can fail prematurely if not properly maintained. Extreme system heat, dirty fluid, and contamination are common culprits. During each inspection, check for:

• Overheating: Monitor the compressor’s heat level regularly. While airends are built to withstand heat, system issues can push temperatures beyond acceptable thresholds.
• Improper Lubrication: Insufficient lubrication leads to friction, excess heat, and accelerated wear on internal moving mechanisms.
• Condensation: Daily draining of the air compressor drip tray is vital. Poor ventilation, especially in sub-zero or humid conditions, can also lead to condensation spreading internally.
• Corrosion: The presence of corrosion or rust indicates insufficient maintenance, lubrication, or drainage, often due to moisture absorption or internal friction.
• Over-pressure: If the compressor needs excessive pressure for normal operation, internal parts may be failing, possibly due to grinding and overheating from lack of lubricants.
• Incorrect Control Adjustment: Improper settings can accelerate airend wear. Operators should be well-versed in correct settings and monitor them daily.
• Vibrations: Unusual vibrations signal excess strain on internal parts. This should prompt an immediate shutdown and inspection for airend issues.
• Oil Seal Leaks: Leaking oil deprives mechanisms of vital fluid, leading to mechanical friction and system overheating. Address leaks immediately.
• Bearing Noise: Strange noises, similar to vibrations, indicate internal problems, often worn airend bearings. Pay close attention to oil leaks and motor bearing noises as primary indicators.

2. Drive Train

The drive train guides the motion of the internal mechanisms. Correct alignment and fresh lubrication of gear drives are essential. Check for:

• Poor Alignment: Misalignment causes system stress, potentially leading to premature failure of motor bearings and impacting the airend.
• Worn Belt: A worn or frayed belt lacks sufficient tension, hindering proper drive train movement. Inspect for frayed ends and cracks during tension checks.
• Insufficient Lubrication: Old or spoiled lubricants cause friction within the drive train.
• Improper Belt Tension: Incorrect belt tension renders the machine inefficient. Belt tension should ideally be inspected and adjusted every 500 hours.

Overall, inspect the drive train every other month to ensure the belt is intact, properly adjusted, and the lubricant maintains correct viscosity.

3. Motor

To ensure motor health, ensure sufficient ventilation and monitor ampere draw to prevent overloading. Crucially, motor bearings require proper lubrication during each inspection. Common motor problems arise from:

• Insufficient Grease: Inadequate grease deprives bearings of necessary lubrication, leading to friction, overheating, and system overwork.
• Hardened Grease: In cold environments, grease can harden, losing viscosity and effective lubrication. It can even freeze and become sludgy when temperatures rise.
• Melted Grease: In hot environments, grease can become runny and ineffective. Intense heat can melt grease, leaving metal parts unprotected, especially if the wrong viscosity is used.
• Wrong Grease: Using an incorrect grade of grease won't provide necessary protection against internal mechanical friction, particularly under extreme temperatures.
• Mixed Greases: Greases are not meant to be mixed. Old grease remnants, potentially acidic, can contaminate new applications and ruin their effectiveness.
• Over-greased Parts: Excessive grease can hinder proper bearing movement, acting more like molasses than a lubricant. Apply the recommended amount, no more, no less.

Without the right grade and proportion of grease, the metal bearings of a rotary compressor will grind against each other with every motor revolution.

4. Filters

A rotary screw air compressor contains an air/oil separator, an oil filter, and an inlet filter. All must be periodically inspected to ensure optimal filtration and prevent the spread of dirt and oily mist. Ideally, inlet filters should be checked after every 2,000 hours of operation, and fluid filters every 1,000 hours. Filter maintenance prevents:

• Airend Wear: Dirty filters can diminish pressurised air quality, reduce ventilation, and lead to airend wear.
• Component Contamination: Unfiltered dirt and oil spread throughout the compressor, causing dust to collect on oily, moisture-laden surfaces, leading to issues with various components.
• Oil Contamination: Poor filtration can dirty the oil and grease, reducing lubrication quality and increasing breakdown vulnerability.
• System Overheating: Accumulation of airborne particles due to insufficient inlet filtration can cause system overheating, shortening the service life between maintenance rounds.
• Reduced Air Quality: Poor filtration negatively impacts end-point applications, as outbound pressurised air becomes dusty, oily, and watery.

When filters are neglected, the air compressor loses its ability to perform its core functions effectively.

5. Lubricants (General Oil Health)

The oil supply is vital for the system's health, ensuring clean movement between parts and maintaining coolness during operation. Oil must be changed periodically. Sample the oil every two or three months to check its colour and consistency. When levels drop, drain the old oil and refill. Do not mix old and new oils, as contaminants from the old oil can affect the new supply. Prevent the following:

• Leaky Oil: Indicates a vital fluid deprivation, possibly due to a crack in the compartment or an ill-fitted fastener.
• Acidic or Contaminated Oil: Oil left too long, especially with moisture, dirt, or rust, can develop acidic qualities.
• Runny Oil: Oil losing its specified viscosity ceases to be an effective lubricant, performing little better than water.
• Mixed Oil: Mixing different grades or types of compressor oil, or mixing new oil with old, contaminated oil, can have detrimental effects on system health.
• Improper Oil: Using an oil grade not recommended in the manual can lead to lubrication problems and machine issues.
• Diluted Oil: Dirt, dust, or watery mist from poor filtration or inadequate drainage can contaminate and dilute the oil.

Oil lifespan varies from 3,000 to 8,000 hours depending on operations. Consult your user's manual or manufacturer for the best oil type for your compressor model.

Rotary Screw Compressor Maintenance Schedule

Over 3,000 hours of use, compressor settings can shift, potentially harming system health. Regular checks are crucial.

Daily Maintenance

At the end of each working day, check the control panel displays to ensure normal readings. Verify gauges are set correctly according to your model's specifications. Compare current readings to previous records to ensure consistency. Perform these observations for all operating modes, even at partial load. If readings deviate without adjustments, it's time for an inspection.

Quarterly and Biannual Maintenance

After every 1,000 to 3,000 hours of operation, inspect and service your air compressor's filters as necessary. Always refer to the maintenance checklist in your instruction manual. Intervals vary greatly:

• Daily Inspections
• Weekly Inspections (condensate drain, compressor/motor/gearbox readings)
• Quarterly Service
• Annual Service
• Major Overhaul

On a weekly basis, inspect the condensate drain and clean it if needed. Record compressor, motor, and gearbox readings, cross-referencing with your manual to ensure consistency with manufacturer recommendations.

Rotary Screw Compressor Troubleshooting Tips

Even with diligent maintenance, occasional mechanical issues may arise, especially in heavy-use environments. Knowing how to troubleshoot is an essential part of proper screw compressor service.

Common Issues and Solutions

Compressor Won’t Start

• Probable Causes: Power supply interruption, inadequate voltage, loose wires, blown fuses, faulty or tripped temperature switch, inadequate system pressure.
• Solutions: Check power supply, wiring, fuses, and temperature switch. Verify system pressure.

Compressor Stalls After Starting

• Probable Causes: Pressure switch adjustment needed, incorrect unit rotation, low voltage, loose supply wires.
• Solutions: Adjust pressure switch, check power supply, tighten belts, inspect check valve for proper function.

Compressor Won’t Reach Desired Pressure Level

• Probable Causes: Air leaks, pressure switch incorrectly set, faulty solenoid or inlet valve.
• Solutions: Check for leaks, adjust pressure switch, examine inlet valve and solenoid operation.

Compressor Won’t Load

• Probable Causes: Pressure switch set too high, faulty inlet valve or solenoid.
• Solutions: Check pressure switch setting, examine inlet valve and solenoid.

Compressor Is Experiencing Oil Carryover

This occurs when lubricating oil bypasses the separator filter and enters the piping system, causing performance issues.

• Primary Causes: Excessive oil in reservoir, excessively low operating temperatures, faulty separator filters, oil degradation.

Discharge Pressure Is Too Low

• Probable Causes: Plugged oil cooler or separator, reduced incoming power voltage, electrical phase imbalance, airend failure.
• Solutions: Check compressor voltage supply, tighten belts to manufacturer specifications.

Frequently Asked Questions About Rotary Screw Air Compressors

Q: What is the main difference between air compressor oil and motor oil?
A: Air compressor oil is specifically formulated without detergents and has lower levels of carbon, sulphur, and other contaminants compared to motor oil. This prevents harmful build-up within the compressor system.

Q: Can I use regular motor oil in my rotary screw air compressor?
A: No, it is strongly advised against. Motor oil contains detergents that can cause foaming, emulsification, and deposit build-up in air compressors, leading to damage and reduced efficiency. Always use oil specifically designed for air compressors.

Q: Why do some rotary screw compressors not require oil?
A: Oil-free rotary screw compressors are designed for applications where any oil contamination in the compressed air is absolutely unacceptable, such as in food processing or medical industries. They achieve compression without oil but are typically more expensive and louder.

Q: How often should I check my air compressor's oil level?
A: It is recommended to check the oil level daily, or every time you use the air compressor, to ensure it remains within the recommended operating range.

Q: What happens if I don't change my compressor oil on time?
A: Failing to change the oil can lead to oil degradation, reduced lubrication effectiveness, increased friction and heat, accelerated wear on components like the airend and bearings, and potential system breakdowns. It can also void your warranty.

Q: What does "oil-flooded" or "oil-injected" mean?
A: These terms describe rotary screw compressors where oil is injected into the rotor housing during compression. The oil mixes with the air for lubrication, sealing, and cooling, but is then separated from the air before it leaves the system.

Q: Why is consistent maintenance important for my rotary screw compressor?
A: Regular maintenance saves time and money by preventing unexpected downtime and costly emergency repairs. It also significantly extends the life expectancy of your compressor, ensuring optimal productivity for many years.

Q: What are the signs of a problem with the airend?
A: Signs of airend issues include overheating, unusual vibrations, strange bearing noises, oil seal leaks, and the compressor requiring excessive pressure to operate normally. Improper lubrication or condensation can also cause damage.

Q: How often should filters be inspected in a rotary screw compressor?
A: Inlet filters should ideally be checked after every 2,000 hours of operation, and fluid filters every 1,000 hours. Always refer to your compressor's manual for specific recommendations.

Q: Can mixing different types of compressor oil cause issues?
A: Yes, mixing different grades or types of compressor oil, or mixing new oil with old, contaminated oil, can severely reduce lubrication effectiveness and lead to system problems. Always use the specified oil type.
