28/09/2011
The familiar, yet often unwelcome, screech or squeal of brakes can be a common annoyance for many drivers. While the effectiveness of your braking system is paramount, the noise generated can detract from the overall driving experience. Fortunately, there are solutions available to combat this issue, and at the forefront of these are anti-noise brake shims. These clever components, particularly the high-quality SDT SHIMS antinoise manufactured by SDT Brakes, play a crucial role in achieving a quieter and more refined braking performance. This article will delve into the world of anti-noise shims, exploring their composition, the benefits they offer, and crucially, when and how they should be employed to effectively silence your brakes.
- Understanding Brake Noise
- What are Anti-Noise Brake Shims?
- The Advanced Composition of SDT SHIMS Antinoise
- Key Benefits of Using Anti-Noise Shims
- When Should You Use Anti-Noise Brake Shims?
- How to Install Anti-Noise Shims
- Comparing Shims to Other Noise Reduction Methods
- Frequently Asked Questions
- Conclusion
Understanding Brake Noise
Before we explore the solution, it's important to understand the root causes of brake noise. The primary culprit is often vibration. When you apply the brakes, the brake pad is pressed against the brake disc. This friction, while necessary for stopping, can cause microscopic movements and vibrations between the pad, the caliper, and the disc. These vibrations resonate and are amplified, manifesting as the audible squeal or groan we associate with braking. Factors such as the material composition of the brake pads, the condition of the brake discs, and even the ambient temperature can influence the likelihood and intensity of this noise.
What are Anti-Noise Brake Shims?
Anti-noise brake shims are specifically designed components that act as a barrier to dampen these vibrations. Think of them as a sophisticated form of insulation for your brake pads. The SDT SHIMS antinoise from SDT Brakes are a prime example of this technology. They are not merely a piece of metal; rather, they are engineered with a multi-layered construction to absorb and dissipate the vibrational energy that would otherwise be transmitted and amplified.
The Advanced Composition of SDT SHIMS Antinoise
The effectiveness of an anti-noise shim is directly related to its construction. SDT Brakes prides itself on the quality and innovation behind its SDT SHIMS antinoise. These shims are primarily composed of carbon, a material known for its excellent vibration-dampening properties. The composition is further enhanced by an advanced design featuring seven distinct layers. These layers incorporate a blend of high-performance compounds, including specialized fibers and Kevlar fibers. This intricate layering is meticulously designed to absorb vibrations across a wide range of frequencies, significantly reducing the noise generated during braking.
Key Benefits of Using Anti-Noise Shims
The advantages of incorporating anti-noise shims into your braking system extend beyond just a quieter ride. Here are the primary benefits:
- Significant Noise Reduction: This is the most immediate and noticeable benefit. By dampening vibrations, shims drastically reduce or even eliminate the irritating squeal and groan associated with braking.
- Reduced Vibrations: The shims don't just tackle audible noise; they also minimise the physical vibrations felt through the steering wheel and pedal, leading to a more comfortable driving experience.
- Temperature Management: The multi-layered construction of the shims helps to insulate the brake piston from the heat generated during braking. This can lead to a reduction in the temperature transmitted to the piston, potentially extending the life of brake fluid and other components.
- Preventing Premature Pad Replacement: Unwanted noise can sometimes lead drivers to believe their brake pads are worn out and require immediate replacement, even when they are not. Using shims can resolve the noise issue, potentially saving you the cost and hassle of unnecessary brake pad changes.
- A Cleaner Alternative to Copper Paste: Traditionally, anti-squeak copper paste was used to lubricate the contact points and reduce noise. However, copper paste can be messy, attracting dirt and debris, and potentially contaminating other brake components. SDT SHIMS antinoise offer a clean, effective, and long-lasting alternative.
When Should You Use Anti-Noise Brake Shims?
The decision to use anti-noise shims is typically driven by the presence of brake noise. However, certain scenarios make their use particularly beneficial:
- When Experiencing Persistent Brake Squeal: If your brakes are consistently making noise, especially a high-pitched squeal, shims are a strong consideration.
- With Abrasive or Performance Brake Pad Compounds: High-performance or racing brake pads, while offering superior stopping power, often use more aggressive friction materials. These materials are inherently more prone to generating noise. Using shims with such pads is highly recommended to mitigate this.
- When Seeking a Quieter Driving Experience: Even if the noise is not severe, if you value a quiet cabin and a refined driving experience, shims can be a worthwhile upgrade.
- As a Proactive Measure: For drivers who anticipate issues with noise, or who are replacing brake pads and want to ensure a quiet operation from the outset, installing shims during the pad replacement process is a sensible approach.
How to Install Anti-Noise Shims
Proper installation is crucial for the effectiveness of anti-noise shims. SDT SHIMS antinoise are designed for ease of use, but professional installation is always recommended to ensure they are fitted correctly and safely.
The installation process involves the following key steps:
- Preparation: The SDT SHIMS antinoise sheets are self-adhesive, making application straightforward. However, before applying the shim, it is imperative to thoroughly clean the brake pad support. Any dirt, grease, or old residue must be removed to ensure a secure and effective bond between the shim and the support.
- Trimming (if necessary): The material of the shims is designed to be cut and adapted to fit various brake pad models. If the shim, once applied to the support, protrudes beyond its edges, it should be carefully trimmed to ensure it sits flush and does not interfere with other brake components.
- Placement: The shims are designed to be placed on the pad support. Specifically, they should be positioned between the brake piston and the back of the brake pad support. This placement ensures they are directly in the path of the vibrations being transmitted.
- Professional Installation: Due to the critical nature of the braking system, it is highly recommended that the installation of anti-noise shims be carried out by qualified professionals in a reputable workshop. They have the expertise and tools to ensure the shims are fitted correctly, and that the entire braking system remains in optimal condition.
Comparing Shims to Other Noise Reduction Methods
While shims are a highly effective solution, it's useful to compare them to other methods:
| Method | Pros | Cons |
|---|---|---|
| Anti-Noise Shims (e.g., SDT SHIMS) | Highly effective vibration dampening, clean application, can reduce heat transfer, durable. | Requires proper installation, may need trimming for specific pads. |
| Copper Paste | Can reduce initial squeal, readily available. | Messy, attracts dirt, can be washed away by heat and moisture, less effective long-term than shims. |
| Different Pad Material | Can resolve noise issues if the original pads were the sole cause. | May compromise braking performance (e.g., quieter pads might have less initial bite), can be expensive, doesn't guarantee noise elimination. |
Frequently Asked Questions
Q1: Will shims affect my braking performance?
A1: No, when installed correctly, anti-noise shims do not affect the braking performance. Their sole purpose is to dampen vibrations and reduce noise.
Q2: How long do anti-noise shims last?
A2: The lifespan of shims depends on various factors, including driving conditions and the quality of the shim. However, high-quality shims like those from SDT Brakes are designed for durability and can last for the life of multiple sets of brake pads.
Q3: Can I install shims myself?
A3: While the shims are self-adhesive and the material is adaptable, we strongly recommend professional installation. Incorrect installation can compromise safety and the effectiveness of the shims.
Q4: Are shims suitable for all types of vehicles?
A4: Yes, anti-noise shims can be beneficial for a wide range of vehicles, particularly those experiencing brake noise, or those fitted with performance-oriented brake pads.
Q5: How do I know if my brakes are noisy due to the pads?
A5: Brake noise can stem from various sources. However, a consistent squeal or groan during braking, especially when the pads are not excessively worn, often points to a vibration issue that shims can address.
Conclusion
The pursuit of a quiet and comfortable driving experience often leads to investigating the source of brake noise. Anti-noise brake shims, particularly the advanced SDT SHIMS antinoise from SDT Brakes, offer a highly effective and clean solution. By understanding their sophisticated multi-layered composition of carbon and Kevlar fibers, and by recognising when to use them – especially with aggressive pad compounds or when persistent noise is an issue – you can significantly enhance your vehicle's braking refinement. Remember, while the shims themselves are designed for ease of application, professional installation is the key to ensuring both safety and optimal performance. Investing in quality anti-noise shims is an investment in a quieter, more pleasant, and ultimately more refined drive.
