08/04/2018
The Mazda Miata, affectionately known as the MX-5 in many markets, has long been celebrated for its lightweight chassis, nimble handling, and pure driving pleasure. However, for some enthusiasts, the factory-spec four-cylinder engine, while competent, doesn't quite deliver the exotic character and high-revving thrill that they crave. This is where the allure of engine swaps comes into play, and few swaps are as iconic or as sought-after as fitting a Wankel rotary engine, particularly the Mazda 13B, into the NA (first-generation) Miata. To facilitate this ambitious project, specialised kits are required, and the "Mazda Miata 13B Rotary Mount Kit" from Lucky 7 Racing Products is a prime example of such an offering.
What is a Mazda Miata 13B Rotary Mount Kit?
At its core, a Mazda Miata 13B Rotary Mount Kit is a collection of custom-designed and manufactured components that enable a 13B rotary engine (typically from a Mazda RX-7 or RX-8) to be physically fitted and mounted into the engine bay of a first-generation (NA) Mazda Miata (1989-1997). This isn't a simple bolt-in affair; fitting an engine with a fundamentally different architecture and displacement requires significant engineering to ensure proper alignment, clearance, and structural integrity. The kit bridges the gap between the Miata's chassis and the rotary powerplant.
The Lucky 7 Racing Products Kit: A Closer Look
The information provided highlights a specific kit from Lucky 7 Racing Products. This particular kit is designed to integrate the second-generation 13B rotary engine into the first-generation Miata. Let's break down what this entails and the components typically included:
Key Components of the Lucky 7 Kit:
- Custom Subframe: This is arguably the most critical piece of the kit. The original Miata subframe is designed to accommodate its factory inline-four engine. A custom subframe is fabricated to provide the correct mounting points for the 13B rotary engine and its associated transmission. This ensures the engine sits at the correct angle and height within the chassis for optimal weight distribution and drivetrain alignment.
- Motor Mount Brackets: These brackets attach the rotary engine to the custom subframe. They are engineered to precisely match the mounting points on the 13B engine block and the custom subframe, providing a secure and vibration-dampened connection.
- Polyurethane Mounts: Engine mounts are crucial for isolating the engine's vibrations from the chassis, thereby improving driver comfort. Polyurethane mounts offer a good balance between stiffness (for precise engine location) and damping (for vibration reduction). They are often more durable than rubber mounts.
- Necessary Hardware: The kit will also include all the nuts, bolts, washers, and other fasteners required to securely assemble the subframe, brackets, and mounts. This ensures a complete and hassle-free installation process, as sourcing all the correct hardware can be a time-consuming task.
Quality and Construction:
Lucky 7 Racing Products emphasizes that their components are handmade. This suggests a focus on meticulous craftsmanship and attention to detail, often associated with higher quality and improved strength compared to mass-produced parts. The black powder coating is a practical feature, offering excellent resistance to corrosion, oil, and chemicals, which are common elements encountered in a vehicle's engine bay. This coating not only enhances durability but also provides a clean and professional aesthetic.
The 13B Rotary Engine: A Brief Overview
The 13B rotary engine is a distinctive type of internal combustion engine developed by Mazda. Unlike conventional piston engines, it uses a triangular rotor that rotates within an oval-shaped housing to perform the four strokes of intake, compression, combustion, and exhaust. This design results in a compact engine with fewer moving parts, a smooth power delivery, and a characteristic high-revving nature. The second-generation 13B typically refers to the engines found in the FC RX-7 (1986-1991) and the naturally aspirated versions of the FD RX-7 (1992-2002), as well as the RX-8 (though the RX-8's Renesis 13B-MSP has different intake and exhaust porting, making it a less common swap candidate without further modifications).
Why Convert a Miata to a Rotary?
The appeal of a rotary-swapped Miata is multifaceted:
- Unique Character: The rotary engine offers a sound and a driving experience unlike any other. Its high-revving nature and smooth power delivery are intoxicating for many enthusiasts.
- Power Potential: While the stock NA Miata engine produces around 115-130 bhp, a 13B rotary can easily produce significantly more power, especially with modifications like turbocharging.
- Weight Savings: Rotary engines are generally lighter and more compact than comparable piston engines, which can further enhance the Miata's already excellent power-to-weight ratio and handling dynamics.
- The "Wow" Factor: A rotary-swapped Miata is a head-turner and a conversation starter. It's a testament to creative engineering and a passion for unique automotive builds.
Considerations for a Rotary Swap:
While the prospect is exciting, a rotary swap is a complex undertaking that requires more than just a mounting kit:
- Transmission: The rotary engine's transmission needs to be adapted or a different gearbox chosen that mates correctly to both the rotary engine and the Miata's differential and driveshafts.
- Cooling System: Rotary engines generate heat differently than piston engines, and a custom cooling system, including radiator and fan setup, will be necessary.
- Fuel System: The fuel delivery system will need to be upgraded to support the higher fuel requirements of the rotary engine.
- Electrical System: Integrating the rotary engine's ECU and wiring harness into the Miata's electrical system is a significant challenge.
- Exhaust System: A custom exhaust manifold and system will be required to route the exhaust gases away from the engine bay.
- Driveshaft and Differential: Depending on the chosen transmission, the driveshaft and potentially the Miata's differential may need modification or replacement to handle the increased torque and different output shaft configuration.
- Engine Management: Proper tuning of the engine's ECU is crucial for optimal performance and reliability.
- Fabrication Skills: Beyond the mounting kit, further custom fabrication might be needed for various components.
Cost and Availability:
The Lucky 7 kit is priced at $1,999.00, which is described as the "most affordable and highest caliber Rotary kit on the market." This positions it as a significant investment, but one that simplifies a major hurdle in the rotary swap process. The mention of a "short production run" indicates that these kits may be produced in limited batches, suggesting that interested buyers should act promptly. The 6-8 week lead time after ordering reflects the handmade nature and the production process.
Comparison: Rotary vs. Stock Miata Engine
To better understand the impact of this conversion, let's compare the key characteristics:
| Feature | Stock NA Miata Engine (e.g., 1.6L BP-ZE) | Mazda 13B Rotary Engine (e.g., 2nd Gen) |
|---|---|---|
| Configuration | Inline 4-cylinder | Rotor (Wankel) |
| Displacement | 1.6L or 1.8L | 1.3L (approx. 2.6L effective) |
| Power Output (Stock) | 115-130 bhp | 146-200 bhp (naturally aspirated) |
| Torque Delivery | Linear, mid-range focused | Smoother, higher-revving, less low-end torque |
| Weight | ~150 kg | ~140-160 kg (depending on accessories) |
| Complexity | Relatively simple | More complex due to unique design and support systems |
| Sound | Typical 4-cylinder exhaust note | Distinctive high-pitched rotary "buzz" |
| Maintenance | Well-understood, widely available parts | Requires specialised knowledge, specific apex seal maintenance |
Frequently Asked Questions (FAQs):
Q1: Is this kit compatible with all first-generation Miatas?
The kit is specifically designed for the first-generation (NA) Mazda Miata. Compatibility with specific model years or trims within the NA generation should ideally be confirmed with the manufacturer.
Q2: What specific 13B engine does this kit support?
The information states it supports the "second generation 13B rotary engine." This typically refers to engines from the FC RX-7 and naturally aspirated FD RX-7 models.
Q3: Does the kit include the engine itself?
No, the kit is for the mounting components only. You will need to source a 13B rotary engine and its associated transmission separately.
Q4: What are the advantages of a rotary engine over the stock Miata engine?
Rotary engines offer a unique sound, a smooth and high-revving power delivery, and often a better power-to-weight ratio potential. They are also more compact.
Q5: What are the disadvantages of a rotary engine?
Rotary engines can be less fuel-efficient, may require more frequent maintenance (especially concerning apex seals), and can have a narrower powerband with less low-end torque compared to piston engines.
Q6: How difficult is the installation of this kit?
While the kit simplifies the engine mounting, the overall rotary swap is a complex project requiring significant mechanical skill, fabrication knowledge, and potentially customisation of other vehicle systems (cooling, exhaust, electrical, etc.). It is not a beginner-level project.
Conclusion:
The Mazda Miata 13B Rotary Mount Kit from Lucky 7 Racing Products represents a crucial piece of the puzzle for enthusiasts aiming to transplant the distinctive Wankel rotary engine into their beloved NA Miata. It addresses the fundamental challenge of physically integrating the engine into the chassis, offering a high-quality, handmade solution. While the kit itself is a significant enabler, prospective builders must be prepared for the broader scope of work involved in a complete engine conversion. For those seeking an truly unique and exhilarating driving experience, and possessing the necessary skills and dedication, this kit offers a pathway to achieving a legendary automotive fusion.
