2005 Yamaha V Star 1100: Engine and Specs Unveiled

The 2005 Yamaha V Star 1100, also affectionately known as the Drag Star or XVS1100, stands as a testament to Yamaha's enduring legacy in the cruiser motorcycle segment. This model, part of the well-regarded middleweight V Star series, offers a compelling blend of classic aesthetics, reliable performance, and touring-friendly features. While it may not boast the outright power of larger displacement bikes, its usability, comfortable ride, and attractive price point have cemented its status as a favourite among riders seeking a dependable and stylish cruiser. This article delves into the heart of the 2005 V Star 1100, exploring its engine, specifications, various trims, and what owners can expect.

The Heart of the V Star 1100: Engine and Performance

At the core of the 2005 Yamaha V Star 1100 lies a robust oil/air-cooled, 4-stroke, SOHC, V-twin engine. This powerplant, a descendant of the highly respected Virago series, displaces 1,063 cc (64.9 cubic inches). It features a bore and stroke of 95 mm by 75 mm (3.74 x 2.95 inches) and a compression ratio of 8.3:1. Fuel delivery is managed by a pair of Mikuni BSR37 dual flat-slide carburettors, complemented by a non-woven fabric-element air filter and twin exhaust pipes, contributing to the bike's distinctive sound and power delivery. This engine configuration is renowned for its ample low- and mid-range torque, making it ideal for relaxed cruising and confident acceleration.

The engine's performance figures are as follows:

*Courtesy of Bikes Wiki

Fuel and Lubrication Requirements

The 2005 V Star 1100 is equipped with a 17-litre (4.5 US gallons) fuel tank, including a 4.5-litre (1.1 US gallons) reserve. It requires unleaded gasoline with a minimum Octane rating of PON 86/RON 91. While fuel variants containing up to 5% MTBE or 10% ethanol with appropriate additives are permissible, blends containing methanol are not recommended due to potential performance issues and fuel system damage.

For lubrication, the V Star 1100 utilises a wet sump system. The oil capacity is 3 litres (3.2 US quarts) for a standard oil change, increasing to 3.1 litres (3.3 US quarts) when the oil filter is also replaced. The final gear oil capacity is 0.19 litres (0.20 US quarts).

Yamaha recommends using SAE 10W-30 or 20W-40 Yamalube 4 motor oils that meet JASO T903 MA/MB standards with a minimum API grade of SJ. It's crucial to use oils without chemical additives, as they also lubricate the clutch assembly. Avoid oils labelled "Energy Conserving II" or those with a "CD" (or higher) diesel specification.

Drivetrain and Transmission

Power is transferred to the rear wheel via a reliable 5-speed constant-mesh manual transmission, operated by a left-foot shifter. The clutch assembly is a wet, multi-disc type, known for its smooth engagement. The final drive is handled by a shaft drive system, which is low-maintenance and contributes to the bike's overall clean appearance. The gearing is well-spaced to take advantage of the engine's strong torque curve, providing a responsive riding experience.

Ignition and Electrical System

The 2005 V Star 1100 employs a digital transistorized coil ignition system for reliable spark generation. Starting is facilitated by an electric starter. The charging system is powered by a triple-phase A.C. magneto. The bike is equipped with a 12V 12 Ah (10 HR) GT14B-4 battery, which powers the lighting and electronic accessories. When replacing the battery, the Yuasa YUAM624B4 YT14B-BS is a common and compatible option. It's important to note that the battery format used in the 1,300cc V Stars (Strykers) is incompatible.

Ignition is handled by an NGK BPR7ES or Nippon Denso W22EPR-U spark plug, with a specified electrode gap of 0.7–0.8 mm (0.028–0.031 inches) and a torque setting of 20 Nm (2.0 kgf-m, 14.5 ft-lbf).

Tires and Brakes

The 2005 V Star 1100 typically rolls on bias-ply tubeless tires: a 130/90 16MC (67S) at the front and a 170/80 15MC (77S) at the rear. These are usually mounted on 16M/C x MT3.00 and 15M/C x MT4.50 cast wheels respectively. Common tyre brands fitted as original equipment include Dunlop D404s or Bridgestone Exedra G702/3s, depending on the specific trim. Recommended cold tyre pressures are between 225–250 kPa (33–36 psi), varying slightly for solo or pillion riding.

For stopping power, the V Star 1100 features a triple-disc brake setup. The front brakes consist of twin-piston calipers acting on 298 mm discs, while the rear utilises 282 mm discs with similar calipers. This provides strong and reliable braking performance.

Suspension and Chassis

The motorcycle is built around a double-cradle tubular steel chassis with a 33° caster angle and 132 mm (5.2 inches) of trail, contributing to its stable handling characteristics. Up front, 41 mm telescopic forks with oil-damped coil springs provide 140 mm (5.5 inches) of wheel travel. At the rear, a linkage-type suspension system with oil-damped gas shocks offers adjustable preload and rebound damping, providing 113 mm (4.45 inches) of wheel travel.

The wheelbase measures a substantial 1,645 mm (64.8 inches), and the bike has a turning radius of 3.4 metres (11.1 feet). With a ground clearance of 140 mm (5.5 inches), the V Star 1100 maintains a low centre of gravity, enhancing its stability and reducing the likelihood of tipping.

Dimensions and Ergonomics

The overall dimensions for the Standard and Silverado models are approximately 2,460 mm x 945 mm x 1,095 mm (96.9 x 37.2 x 43.1 inches – Length x Width x Height). Custom trims are generally slightly shorter.

The curb weight of the 2005 V Star 1100 ranges from 285 kg (628 lbs.) to 288 kg (635 lbs.), with California models being marginally heavier. The saddle height is comfortably situated between 690–710 mm (27.2–28 inches), accommodating a wide range of rider heights. The maximum load capacity for the trims is between 200–203 Kg (441–448 lbs.), with a Gross Vehicle Weight Rating (GVWR) estimated between 485 Kg (1,069 lbs.) and 491 Kg (1,082 lbs.).

2005 V Star 1100 Trims and Styling

The 2005 model year was notable for Yamaha offering five distinct trims for the V Star 1100, deviating from the usual two or three. Each trim offered unique styling cues:

• Silverado: This top-tier trim featured studded leather saddlebags and seats, a backrest, chromed tank and fenders, and a windshield, signifying a more premium, touring-oriented package.
• Classic: Characterised by blacked-out engine and bodywork, a windshield, and studded leather seats and saddlebags (similar to the Silverado). It was also the only trim to offer a two-tone colour scheme in 2005.
• Custom: Distinguished by spoked aluminium rims, exposed front forks, a narrower front tyre, and a bobbed rear fender. It featured a peg configuration with a heel-toe shifter, unlike the floorboards found on other models.
• Midnight Custom: Similar to the all-black Classic, but without the windshield and studded accessories. Its front fender was also trimmed for a more streamlined look.

The overall design language of the V Star 1100, with its low stance, rounded edges, and elegant simplicity, made it a visually appealing motorcycle that appealed to both experienced riders and newcomers to the cruiser scene.

Common Issues and Owner Feedback

While the 2005 Yamaha V Star 1100 is generally a reliable machine, some common issues have been reported by owners:

• Starting Difficulties: Some riders experience slow turnovers or starting failures. This can be attributed to the high-voltage circuit draining the battery or issues with the ignition system or fuel compression. Regular maintenance, checking battery connections, and inspecting for worn piston rings or leaking valves are recommended.
• Faulty Air Intake Boot: The air intake boot is known to leak or detach, allowing unfiltered air into the engine, which can cause damage. Regular inspection of this component is advised.
• Voltage Regulator Issues: Problems with the charging system, often linked to the voltage regulator or rectifier, can lead to battery charging failures. Voltage testing can help diagnose these issues.
• Laborious Oil Changes: The location of the oil filter can make oil changes inconvenient, often requiring the removal of the exhaust system. Oil filter relocation kits are available to simplify this process.
• Ergonomic Considerations: Some riders, particularly those of taller stature (e.g., 6'1"), have noted that the seating position can feel restrictive on longer rides, with a desire for a wider saddle or a slightly longer seat. Other minor ergonomic wishes include larger mirrors and improved accessory mounting systems.

Pricing and Value

The 2005 Yamaha V Star 1100 had a list price ranging from approximately $8,099 for the Midnight Custom to $9,499 for the Silverado. Over its production run, the V Star 1100 offered excellent value for money, with gradual price increases that were modest compared to the features and performance delivered. Even today, used V Star 1100 models remain popular due to their reliability and classic styling.

Frequently Asked Questions

Q1: What engine does the 2005 Yamaha V Star 1100 have?
A: The 2005 Yamaha V Star 1100 is powered by a 1,063 cc (64.9 cubic inches) V-twin, oil/air-cooled, 4-stroke, SOHC engine.

Q2: What are the key features of the 2005 V Star 1100 trims?
A: Trims varied, with the Silverado offering premium touring features like leather saddlebags and a windshield, the Classic providing a traditional cruiser look, and the Custom featuring spoked wheels and a bobbed fender.

Q3: Is the 2005 V Star 1100 fuel-injected?
A: No, the 2005 V Star 1100 uses a carburetted fuel system with dual Mikuni BSR37 carbs. Fuel injection was introduced on later V Star models.

Q4: What are common problems with the 2005 V Star 1100?
A: Common issues include potential starting problems, air intake boot leaks, voltage regulator issues, and the inconvenience of oil filter access.

Q5: What is the recommended oil for the 2005 V Star 1100?
A: Yamaha recommends SAE 10W-30 or 20W-40 Yamalube 4 motor oils meeting JASO T903 MA/MB standards with a minimum API grade of SJ.

Conclusion

The 2005 Yamaha V Star 1100 remains a highly capable and desirable motorcycle. Its potent V-twin engine, comfortable ride, and classic cruiser styling make it a joy to own and ride. Despite a few minor quirks that can be addressed with regular maintenance or aftermarket solutions, the V Star 1100 offers a fantastic balance of performance, reliability, and value, solidifying its place as a beloved entry in Yamaha's cruiser lineage.
