DIY Oil Change: 2017 Hyundai Tucson

The Essential Guide to Changing Your 2017 Hyundai Tucson's Oil and Filter

Keeping your 2017 Hyundai Tucson ticking over smoothly is paramount for its longevity and performance. One of the most fundamental and impactful maintenance tasks you can undertake yourself is a regular oil and oil filter change. This isn't just about topping up; it's about safeguarding your engine from wear and tear, ensuring optimal lubrication, and maintaining efficient operation. While many drivers opt for professional servicing, understanding and performing this task at home can be incredibly rewarding, saving you money and giving you a deeper connection with your vehicle. This comprehensive guide will walk you through the process, from understanding oil types to the final wipe-down, specifically tailored for your 2017 Hyundai Tucson Eco.

Understanding Your Tucson's Oil Requirements

The lifeblood of any engine is its oil, and choosing the right type for your 2017 Hyundai Tucson is crucial. Modern vehicles, including your Tucson, offer a range of oil options, primarily categorised as conventional, synthetic blend, and full synthetic. The debate between synthetic and conventional oil is well-established, with valid points on both sides.

Full synthetic oil is engineered at a molecular level for superior performance. It resists thermal breakdown more effectively than conventional oil, meaning it maintains its lubricating properties for longer periods and under more extreme conditions. This often translates to longer intervals between oil changes, a significant convenience for many owners. It’s also generally considered to offer better protection against engine wear, especially in demanding driving situations or extreme temperatures.

A synthetic blend offers a compromise, combining the benefits of synthetic oil with conventional base oils. This can provide enhanced protection and performance over purely conventional oil, often at a more accessible price point than full synthetic.

Conventional oil, while less sophisticated, can still be a perfectly viable option if your vehicle manufacturer approves it and you adhere to recommended change intervals. It's a cost-effective choice for drivers who consistently perform regular maintenance.

Your 2017 Hyundai Tucson's owner's manual is the definitive source for the correct oil viscosity and specification. It will specify whether your Tucson requires, for example, 0W-20, 0W-30, 5W-20, 5W-30, or 10W-30. Always consult this manual to ensure you are using the oil that meets Hyundai's stringent requirements. For the 2017 Tucson Eco, it's highly probable that a 0W-20 synthetic oil is recommended for optimal fuel economy and engine protection.

Essential Tools and Materials

Before you begin, gather all the necessary tools and materials to ensure a smooth and efficient oil change. Having everything to hand will prevent frustrating interruptions and potential mistakes. Here's a comprehensive list:

• New Engine Oil: The correct type and quantity as specified in your owner's manual. For the 2017 Tucson Eco, this is typically around 4.5-5 quarts of 0W-20 synthetic oil.
• New Oil Filter: Ensure it's the correct filter for your 2017 Hyundai Tucson.
• Wrench for Drain Plug: Typically a socket wrench with the correct size socket for the oil drain plug.
• Oil Filter Wrench: This is essential for removing the old oil filter. There are various types, including strap wrenches, cap wrenches, and pliers-style wrenches. An old fan belt can sometimes be used in a pinch, as suggested.
• Drain Pan: A receptacle large enough to hold all the old engine oil.
• Funnel: To pour the new oil into the engine cleanly.
• Rags or Paper Towels: For cleaning up spills and wiping components.
• Gloves: To protect your hands from oil and grime.
• Safety Glasses: Crucial for protecting your eyes from dripping fluids.
• Jack and Jack Stands: If your Tucson is too low to access the drain plug and filter comfortably. Never rely solely on a jack.
• Wheel Chocks: For added safety when jacking up the vehicle.

Step-by-Step Oil and Filter Change Procedure

With your tools and materials ready, it's time to get to work. Follow these steps carefully:

1. Prepare Your Vehicle

Park your Tucson on a level surface. If you need to raise the vehicle for better access, engage the parking brake firmly and place wheel chocks behind the rear wheels. Use your jack to lift the front of the vehicle at the designated jacking points and securely place jack stands under the vehicle's frame. Lower the vehicle onto the jack stands. Never work under a vehicle supported only by a jack.

2. Locate Key Components

Slide underneath your Tucson. You'll need to locate the oil drain plug and the oil filter. The oil drain plug is typically a bolt located at the lowest point of the oil pan, a metal reservoir beneath the engine. The oil filter is a cylindrical canister, usually screwed into the engine block or a specific housing. Consult your owner's manual or a vehicle-specific diagram if you have trouble locating them.

3. Drain the Old Oil

Position your drain pan directly beneath the oil drain plug. Using the appropriate wrench, carefully loosen and then unscrew the drain plug. Be prepared for the hot oil to start flowing out immediately. Allow the oil to drain completely into the pan. This might take several minutes. Once the oil flow has slowed to a drip, wipe the drain plug clean with a rag and reinsert it. Tighten it firmly with your wrench, but be careful not to overtighten, as this can strip the threads on the oil pan.

4. Remove the Old Oil Filter

Reposition the drain pan to catch any oil that might spill when you remove the filter. Use your oil filter wrench to loosen the old oil filter. As mentioned, for many Hyundais, an old fan belt can be looped around the filter to provide grip for unscrewing it by hand. If it's too tight, use your wrench. Once loose, unscrew the filter by hand. Be aware that the filter will still contain some oil, so tilt it carefully as you remove it to minimise spillage.

5. Prepare and Install the New Oil Filter

Before installing the new filter, take a clean rag and wipe down the filter mounting surface on the engine to ensure it's free of old gasket material. Dip your finger in some of the new engine oil and lightly lubricate the rubber gasket on the new oil filter. This helps create a good seal and makes future removal easier. Screw the new oil filter on by hand until the gasket makes contact with the mounting surface. Then, tighten it an additional three-quarters to one full turn by hand. Most filters do not require a wrench for installation; hand-tight is usually sufficient.

6. Add New Engine Oil

Locate the oil fill cap on top of the engine. It's usually marked with an oil can symbol or the word "OIL". Remove the cap and insert your funnel. Carefully pour the correct amount of new engine oil into the engine. Refer to your owner's manual for the exact capacity, but for the 2017 Tucson Eco, it's typically around 4.5 to 5 quarts.

7. Check the Oil Level

Once you've added the oil, replace the oil fill cap. Start the engine and let it run for about a minute. This allows the new oil to circulate throughout the engine and fill the new oil filter. Turn off the engine and wait for a few minutes (5-10 minutes is ideal) to allow the oil to settle back into the oil pan. Remove the dipstick, wipe it clean with a rag, reinsert it fully, and then pull it out again. Check the oil level against the markings on the dipstick. It should be between the "MIN" and "MAX" marks. If it's low, add a small amount of oil, wait a few minutes, and check again. Do not overfill.

8. Final Checks and Cleanup

Before lowering the vehicle, quickly check under the car for any leaks around the drain plug and the new oil filter. If everything looks good, carefully jack up the vehicle again, remove the jack stands, and lower the vehicle to the ground. Dispose of the old oil and filter responsibly. Many auto parts stores and local recycling centres accept used motor oil and filters.

Important Considerations and Tips

• Safety First: Always wear safety glasses and gloves. Engine oil and other automotive fluids can be harmful. Ensure your vehicle is securely supported if you are working underneath it.
• Warm Engine: It's generally easier to drain old oil when the engine is warm, as the oil flows more freely. However, be cautious as the oil will be hot. Allow the engine to cool slightly before draining.
• Proper Disposal: Never pour used engine oil down drains or onto the ground. It is highly toxic and environmentally damaging.
• Torque Specifications: While hand-tightening the oil filter is common, for the drain plug, using a torque wrench to tighten it to the manufacturer's specification (found in your owner's manual or a service manual) is the best way to prevent leaks or damage.
• Resetting the Oil Change Light: After changing the oil, you'll likely need to reset the "Oil Change Required" or similar maintenance reminder light on your dashboard. The procedure for this varies by vehicle, so consult your owner's manual for specific instructions for your 2017 Hyundai Tucson.

Frequently Asked Questions (FAQs)

Q1: How often should I change the oil in my 2017 Hyundai Tucson?

A: Consult your owner's manual for the recommended oil change interval. For synthetic oil, it might be every 7,500 to 10,000 miles, while conventional oil might require changes every 5,000 miles or every 6 months, whichever comes first. Driving conditions (e.g., stop-and-go traffic, extreme temperatures) can also influence the frequency.

Q2: Can I use a different viscosity oil than what's recommended?

A: It is strongly advised to stick to the oil viscosity recommended in your owner's manual. Using a different viscosity can affect engine performance, fuel economy, and potentially lead to increased wear.

Q3: My oil filter is very tight. What can I do?

A: If a standard oil filter wrench isn't working, you might need a more robust type of filter wrench, or a filter cap wrench that fits specifically over the end of the filter. As mentioned, a sturdy old fan belt can also provide excellent grip.

Q4: How do I know if I need to use jack stands?

A: If you cannot comfortably and safely access the oil drain plug and oil filter without raising your vehicle, then you must use a jack to lift it and, crucially, jack stands to support it safely. Never work under a vehicle that is only supported by a jack.

Q5: What is the correct oil capacity for my 2017 Hyundai Tucson Eco?

A: While it's always best to check your owner's manual, the 2017 Hyundai Tucson Eco typically requires around 4.5 to 5 quarts (approximately 4.3 to 4.7 litres) of engine oil.

Conclusion

Performing your own oil and oil filter change for your 2017 Hyundai Tucson is a manageable and highly beneficial task. By understanding the correct oil, gathering the right tools, and following these steps meticulously, you can ensure your engine receives the care it needs to perform optimally for years to come. Regular maintenance, starting with this fundamental procedure, is the key to a long and healthy life for your vehicle.
