Hope RX4+ Caliper Compatibility Guide

Understanding Hope RX4+ Disc Caliper Compatibility

For cyclists looking to upgrade their braking system, the Hope RX4+ hydraulic disc calipers represent a significant step up in performance and reliability. With over 25 years of experience in designing and building top-tier hydraulic disc-brake systems for mountain bikes, Hope has now turned its expertise towards the road, cyclocross, and gravel cycling markets. This article aims to provide a clear and comprehensive understanding of which brake levers are compatible with the highly acclaimed RX4+ calipers, ensuring you can make an informed decision for your build.

The Hope RX4+ Calipers: A Closer Look

The Hope RX4+ calipers are a testament to meticulous engineering and high-quality manufacturing. CNC machined from a solid block of 2014 T6 aluminium at Hope's renowned Barnoldswick factory, these calipers are built to last and perform. They are available in a range of six attractive colours, allowing for aesthetic customization to match your bike.

Designed with versatility in mind, the RX4+ calipers are offered in versions for both post-mount and flat-mount road disc brake setups. This means they can accommodate 140mm, 160mm, and even 180mm rotors, offering flexibility depending on your braking needs and frame specifications. Each caliper set comes complete with two pairs of Hope's own disc brake pads, specifically recommended for road and gravel use. Furthermore, Hope includes a comprehensive caliper bleed kit and all the necessary fittings for your frame and brake line, along with clear instructions to aid in installation.

In terms of weight, the RX4+ calipers are impressively light. For instance, a Flat Mount Front +20mm caliper designed for a 160mm rotor weighed in at just 119g (including pads and spring), while the Flat Mount Rear caliper tipped the scales at 101g. These figures are notably lighter than comparable calipers from other major brands, such as Shimano's GRX400.

The pricing of the Hope RX4+ calipers positions them in a competitive bracket, falling between Shimano's Ultegra and Dura-Ace offerings, and aligning closely with SRAM's Red calipers. This pricing reflects the premium materials, manufacturing processes, and the performance benefits they deliver.

Brake Lever Compatibility: The Key Question

One of the most common questions for anyone considering the Hope RX4+ calipers is about lever compatibility. Hope has strived to make the RX4+ as accessible as possible to a wide range of riders and their existing setups. Therefore, the RX4+ calipers are designed to be universally compatible with all common Shimano, SRAM, and Campagnolo drop-bar hydraulic brake levers.

This broad compatibility means that whether you are running a Shimano GRX, Ultegra, or Dura-Ace groupset, a SRAM Force, Rival, or Red setup, or a Campagnolo hydraulic disc brake system, the Hope RX4+ calipers should integrate seamlessly. This significantly simplifies the upgrade process, allowing you to benefit from Hope's superior braking technology without needing to replace your entire groupset or brake levers.

Understanding Fluid Compatibility: Mineral Oil vs. DOT Fluid

A crucial aspect to consider when choosing Hope RX4+ calipers is the type of hydraulic fluid they are designed to work with. This is where a key distinction needs to be made based on your existing brake system. Shimano and Campagnolo systems typically use mineral oil, a stable and widely used fluid in many hydraulic systems. In contrast, SRAM brakes traditionally use DOT fluid, which has different properties and maintenance requirements.

To ensure optimal performance and prevent potential damage, Hope produces two distinct versions of the RX4+ calipers:

• Mineral Oil (M) Calipers: These are designed specifically for systems that use mineral oil.
• DOT Fluid (D) Calipers: These are engineered for systems that operate with DOT fluid.

How can you identify which version you need? Hope clearly marks these calipers. Look for a small letter etched onto the bore cap of the caliper. An 'M' indicates it's designed for mineral oil, and a 'D' signifies compatibility with DOT fluid. It is absolutely vital to match the caliper's fluid type with the fluid used in your brake levers and system. Using the incorrect fluid can lead to seal damage, leaks, and a significant compromise in braking performance.

Performance and Feel: What to Expect

The RX4+ caliper's design is termed 'monobloc'. This means it is machined from a single piece of aluminium, as opposed to being constructed from two separate pieces. This monobloc construction results in a significantly stiffer caliper body. A stiffer caliper flexes less under braking pressure, allowing the four pistons to push the brake pads firmly and squarely against the rotor every time. This translates directly into more consistent, powerful, and modulated braking.

During rigorous testing across various conditions, the performance of the RX4+ calipers remained consistently impressive. Brake rub, a common annoyance for many cyclists, was a rarity. It only occurred momentarily when water or liquid temporarily filled the small gap between the pads and the rotor, a minor and transient issue.

When paired with excellent brake levers, such as Shimano's GRX levers, the brake feel delivered by the RX4+ calipers is exceptional. Riders can expect a lever feel that is at least on par with the best road disc brakes currently available. This includes superb fine control, allowing for precise modulation of braking power, and phenomenal stopping power when it's needed most. Whether you're riding on smooth tarmac, loose gravel, or wet and muddy trails, the RX4+ calipers inspire immense confidence. Furthermore, pad wear has been observed to be no worse than comparable rival products, ensuring good longevity.

Installation and Bleeding Process

While the performance of the Hope RX4+ calipers is undeniable, the installation and bleeding process might present a slightly steeper learning curve for those accustomed to the plug-and-play nature of some larger brands. Hope's bleeding process, particularly on a first-time build with their hydraulic disc brakes, can be a little more involved. It may require fitting and removing the syringe multiple times during the routine.

This process can lead to a small amount of oil wastage and requires a bit more cleanup afterwards. However, it's important to note that Hope provides all the necessary kit to perform the bleed. With practice, many riders find that the process becomes simpler and quicker. For those who prefer to delegate this task, most local bike shops are well-equipped to handle the bleeding of Hope hydraulic disc brakes.

Hope RX4+ vs. Competitors: A Quick Comparison

To further illustrate the value and performance of the Hope RX4+ calipers, let's consider a brief comparison with some key competitors:

*Note: Weights and specific features can vary slightly depending on the exact model and configuration.*

Frequently Asked Questions

1. Can I use my existing Shimano levers with Hope RX4+ calipers?

Yes, provided you select the correct version of the RX4+ calipers. If your Shimano levers use mineral oil, you will need the 'M' version of the RX4+ calipers. If, for some reason, your Shimano system used DOT fluid (which is uncommon), you would need the 'D' version.

2. Do Hope RX4+ calipers work with SRAM eTap AXS levers?

Yes, the RX4+ calipers are compatible with SRAM drop-bar hydraulic brake levers, including those from the AXS range. Ensure you use the 'D' (DOT fluid) version of the calipers to match SRAM's fluid requirements.

3. What about Campagnolo hydraulic levers?

Absolutely. The RX4+ calipers are designed to work with Campagnolo hydraulic disc brake levers. As Campagnolo uses mineral oil, you will need the 'M' version of the RX4+ calipers.

4. How do I know if I need the 'M' or 'D' version of the calipers?

Check the hydraulic fluid used in your current brake system. Shimano and Campagnolo systems use mineral oil, so you need the 'M' calipers. SRAM systems use DOT fluid, so you need the 'D' calipers. The calipers themselves are marked with an 'M' or 'D' on the bore cap.

5. Are the Hope RX4+ calipers better than stock Shimano or SRAM calipers?

Many users report a noticeable improvement in braking power, modulation, and lever feel with the Hope RX4+ calipers due to their monobloc design, four-piston configuration, and high-quality construction. While stock calipers are generally very good, the RX4+ offers a premium upgrade for discerning riders.

The Bottom Line

Hope has successfully leveraged its extensive experience in mountain bike braking to create a superb hydraulic disc caliper for road, cyclocross, and gravel cyclists. The Hope RX4+ calipers offer dependable performance, enhanced power, and excellent modulation, compatible with a wide array of popular brake levers from Shimano, SRAM, and Campagnolo. By carefully selecting the correct fluid-specific version ('M' for mineral oil or 'D' for DOT fluid), you can significantly upgrade your bike's braking system, enjoying greater confidence and control on all terrains.
