Unleashing the Beast: Mk2 Focus RS Tuning Guide

Ever since its grand debut in 2009, the Ford Focus RS Mk2 has ignited a fervent tuning war, a spectacle not witnessed with such intensity since the halcyon days of the Cossie in the mid-Nineties. This machine, a true enthusiast's dream, responds to modifications with an almost uncanny ease, much like a hot knife gliding through butter. Specialists, having already seen the fantastic potential of the Mk2 Focus ST, were chomping at the bit to get their hands on the even more potent, full-fat RS model. What started as a factory-quoted 301bhp quickly escalated to 350-370bhp almost overnight, leveraging modified versions of upgrades previously developed for the ST. It wasn't long before tuners were setting their sights on, and subsequently shattering, the 500bhp barrier. But the thirst for power remained unquenched, leading to an explosion of innovation and customisation. This guide, drawing insights from Fast Ford magazine, delves into how you can truly put your own stamp on the formidable Mk2 RS.

The Legendary Mk2 Focus RS: A Tuner's Dream

The Mk2 Focus RS isn't just another hot hatch; it's a phenomenon. Its aggressive stance, distinctive styling, and the unmistakable growl of its five-cylinder engine captured hearts from day one. But beyond its aesthetic appeal and factory performance, lies a chassis and powertrain ripe for significant enhancements. This car truly kick-started the current trends of aggressive WRC-style bodykits, lairy rear wings, and bespoke graphics packages, transforming it into a canvas for automotive artistry and engineering prowess.

Why the Mk2 RS is a Tuning Marvel

The sheer adaptability of the Mk2 RS means it can be whatever you envision. Whether you seek subtle tweaks for an OEM-plus comfortable fast-road cruiser, a motorsport-inspired approach to forge a devastating track weapon, or a truly unique show car that reflects your individuality, the RS delivers. It accommodates visions from a usable, mild-mannered 300bhp to a rip-your-face-off 1000bhp-plus, proving that if you truly desire it, the Mk2 RS can achieve it.

Engine Tuning: Unlocking the Five-Cylinder Powerhouse

At the heart of the Mk2 Focus RS lies the same basic 2522cc, in-line five-cylinder, Volvo-sourced, turbocharged Duratec engine as found in the ST, yet with crucial differences that allow the RS to produce significantly more power from the factory. The RS’s engine block is substantially stronger, meaning the 'block mod' often required on a tuned ST isn't necessary for the RS until you're chasing truly monumental power figures.

The Duratec Engine: RS vs. ST

While sharing its core, the RS engine benefits from factory enhancements that bolster its strength and performance. However, even this robust platform has areas that can be improved upon. One critical component to consider is the inlet manifold. Darren Evans from BD Performance notes, “We’ve seen these fail, and when the plastic inlet cracks it implodes; this can cause small pieces of plastic to be sucked into the engine and damage pistons, bend valves, and cause all kinds of mess.” Upgrading to a performance replacement is a no-brainer; it not only bolts straight on but drastically improves underbonnet aesthetics and provides a noticeable increase in mid-range torque. Collins Performance’s Gary Lendon advises that their testing found the Anembo Engineering version to yield the best results, albeit at a higher cost.

Essential Bolt-On Upgrades

For those looking for an initial power boost, a combination of an upgraded air filter or induction kit, a performance exhaust, and a remap will typically see power increase to around 340-350bhp. The Mountune/RS500 airbox lid is highly effective, retains an OEM look, and can support over 400bhp. Exhaust system choices vary depending on your desired sound and aggression, but a sports cat or de-cat is essential for anything beyond 370bhp. The standard intercooler can manage up to approximately 340-350bhp, but it becomes a restriction. An upgrade here, paired with big boost pipes, can push the same modifications to around 360-370bhp. The Airtec Stage 2 intercooler is a popular choice, offering excellent value for money and recommended for power levels up to around 420bhp.

Fuel System Enhancements

Beyond 370bhp, the standard fuel system begins to struggle. To achieve over 400bhp, bigger injectors and a beefier fuel pump are required. Two main approaches exist: one involves fitting Bosch injectors (ranging from £450 for 550cc to £550 for 1000cc units) coupled with a high-flow 340 litre-per-hour fuel pump (around £750). The alternative, championed by Mountune for the Ford-approved MP350 kit on the RS500, focuses on increasing fuel pressure rather than just flow rates. Gary explains, “This helps keep the desired spray pattern of the injectors to ensure smooth idle and low-speed running, but still deliver enough fuel when needed.” While the RS500’s 6-bar high-pressure fuel pump is costly (£1800), alternatives exist. BD Performance offers external fuel pump setups (single or twin Bosch 044 pumps with a swirl pot, twin kit around £1300 for over 500bhp), and Collins provides an alternative in-tank pump for £949 (with a £450 rebate for exchanging your original unit).

Forged Internals: Building for Extreme Power

From 420bhp upwards, the complexity increases significantly as the limits of the stock internals are approached, and the factory turbo reaches its maximum. Forged conrods and pistons are available for £1200-£1300. To truly bombproof the bottom end for extreme power, a block fitted with ductile steel liners costs £1600, a modification proven to withstand over 1000bhp.

Turbocharging: Boosting Beyond Limits

The stock turbo, impressive as it is, won't get you anywhere near 1000bhp, nor will the stock head and camshafts. Upgrading these components is crucial for substantial power gains.

Hybrid Turbo Solutions

A set of Newman fast road camshafts, costing around £600, can lift power to over 450bhp when combined with appropriate breathing and fuelling modifications. The cylinder head flows sufficiently for 500bhp with a mild port job, but for over 600bhp, larger 1mm oversize valves are necessary. Due to the RS’s turbo having its exhaust housing cast into the exhaust manifold, swapping to a larger blower isn't straightforward. Instead, companies like Turbo Performance offer hybrid versions that modify your original turbo for much greater power potential. Mark Arnold from Turbo Performance details their options: “Our Stage 1 turbo has the compressor housing machined for a larger 67mm billet compressor wheel, complete with cut-back blades on the turbine wheel and a 360-degree thrust bearing. That’s good for 450bhp and costs about £850. Our Stage 3 will take power over 500bhp, adding an even larger 71mm compressor wheel with a larger K24 turbine shaft, costing about £1100.”

Large Frame Turbos and Custom Setups

For anything beyond hybrid turbos, physically larger housings are required. The Garrett GTX3076 is a popular choice at £1500, enabling an RS to produce well over 600bhp with the correct supporting modifications. Many other large turbos are available today, but they necessitate a separate manifold and likely an external wastegate setup, which adds to the overall cost. For enormous power RS builds, the turbo itself can become so large that it struggles to fit between the engine and the bulkhead. This is where 'sidewinder' style manifolds come into play, repositioning the turbo above the gearbox where more space is available, though this requires extensive custom fabrication.

ECU and Remapping: The Brains Behind the Brawn

The standard Bosch ME9 ECU is a remarkably powerful piece of kit, with numerous software upgrades available. Mountune and Collins Performance offer tunes that can push power to around 420bhp, and these can often be flashed directly to the ECU by the owner using handsets like the mTune or iFlash system. Revo and Motorsport Developments provide offerings that require installation by an authorised dealer, with the factory ECU capable of supporting up to 600bhp.

The Rise of Standalone Management Systems

A true game-changer in recent years has been the introduction of plug-and-play standalone engine management systems, such as the Syvecs system offered by Devil Developments. These systems completely replace the Bosch ME9 unit, integrating fully with the rest of the car while offering complete mappability. This allows for advanced features like flex-fuel sensors, which determine the ethanol content of the fuel and automatically adjust the engine mapping accordingly. Syvecs systems also boast an excellent torque biasing traction control system, which is crucial for making 1000bhp cars compliant and practical enough for street use. A full Syvecs system costs around £3000, and for maximum performance, you'll likely want to add the 4-inch MAF-less crossover pipe (£450, as big turbo upgrades can cause issues with the factory MAF sensor) and a flex-fuel sensor (£180) to utilise exotic fuel blends for those headline power figures.

As a general rule, up to 420bhp can be achieved relatively easily with bolt-on upgrades and a home ECU reflash. From there, up to 600bhp is possible on the stock ECU with a built bottom end and a larger turbo. However, for anything beyond 600bhp, you'll be looking at a custom build supported by a standalone ECU.

Transmission Tuning: Handling the Torque

The M66 six-speed gearbox in the Mk2 RS is a robust unit, capable of handling a significant amount of power. It has been known to cope with some truly crazy bhp figures, particularly if the mapping is sympathetic and the car isn't subjected to aggressive launches or harsh shifts. Gary Lendon at Collins Performance confirms that even the driveshafts are considerably tougher than those on the ST and generally pose no concern on most modified machines. Naturally, extreme power levels or sustained hard use on track will be a different story. For the ultimate transmission in a Mk2 Focus, the Quaife QKE45Z M66 sequential gearbox is the go-to option, offering unparalleled performance. However, once all the necessary components are factored in, don't expect much change from £10,000.

Clutch and Flywheel Upgrades

The factory clutch and dual-mass flywheel are perfectly adequate for the initial tuning stages, up to around 420bhp. Beyond this point, an upgrade becomes essential. Helix Autosport offers a range of upgrades, including organic and paddle clutch options. The Xtreme Clutch twin-plate upgrade is particularly impressive, utilising two organic drive plates to support over 800lb.ft of torque while remaining comfortable enough for daily road use. This comprehensive kit typically costs around £1600.

Suspension Tuning: Grip and Control

The RS’s RevoKnuckle design was revolutionary, playing a crucial role in enabling these cars to put so much power down through their front wheels. However, it's not without its challenges. Gary Lendon at Collins notes that they've seen RevoKnuckle joints fail, and new replacements are no longer available. Some specialists are exploring refurbishment options, but rust on the pressed-in ball-joint appears to be the primary culprit, underscoring the importance of maintaining a corrosion-free undercarriage. Darren Evans at BD Performance highlights a simple yet effective upgrade: adding a set of Powerflex polyurethane inserts for the upper and lower engine mounts, plus the gearbox mount. All three cost approximately £100 and simply push into the voids of the original rubber bushes, providing additional support and preventing excessive engine movement.

Bushings and Mounts: Taming Movement

The Mk2 Focus platform is notorious for prematurely wearing out the rear bushes on the front wishbones. While the RevoKnuckle design makes the RS somewhat kinder than the ST in this regard, polyurethane upgrades remain a wise investment. Many tuners also suggest incorporating an anti-lift kit when replacing the rear bushes. These kits feature a revised location to offer enhanced caster and anti-lift properties, further improving handling dynamics.

Springs and Coilovers: Dialling in Dynamics

Lowering springs from reputable brands like Eibach or H&R, available for £200-£250, offer an excellent first step in improving handling performance and aesthetics. For superior control and adjustability, however, you'll want to add matched – and ideally adjustable – dampers. This typically leads to investing in a full coilover kit. Bilstein’s B16 kit (£1600) is widely regarded as ideal for fast road use, offering a superb balance of comfort and performance. Dedicated track enthusiasts might consider coilovers like KW’s Clubsport two-way kit (£2300), which provides separate bump and rebound control for precise tuning. BC Racing is another popular choice, striking a balance between practical performance and a sensible budget, with their BR series often available for less than a grand.

Brake Tuning: Stopping Power Matters

The stock 336mm front and 300mm rear brakes on the Mk2 RS perform surprisingly well on most road cars, especially when enhanced with upgraded brake pads, high-quality fluid, and braided brake lines. However, their visual appeal often leaves something to be desired. For owners using their RS on track, or those simply wanting a more visually striking setup peeking out behind their wheel spokes, big brake kits are readily available. Mountune’s Clubsport big brake kit, featuring a six-pot Alcon caliper and 365x32mm floating discs, is one of the best options available, costing £2250. Similar high-performance kits are also offered by AP Racing, EBC, and PB Brakes. At the rear, decent pads coupled with grooved discs and some quality brake lines are generally all that's required to complement the front upgrades effectively.

Wheels and Tyres: The Contact Patch

Sometimes, a simple aesthetic change can make a significant difference; painting the factory 19-inch wheels black is often enough to transform the car's look, though remember to add black wheel nuts for a cohesive finish. The standard offset is quite high at ET60, leading many owners to fit spacers to achieve a more flush fitment and properly fill the arches; 20mm on the rear and 15mm on the front usually does the trick. This effectively reduces the offset to around ET40-45 on the stock 8.5-inch-wide rim, a crucial detail to remember when exploring aftermarket wheel options. Fortunately, a vast array of wheels that fit the 5x108 PCD and 63.4mm centre bore are available from brands like Rotiform, Bola, BBS, and Rota.

Optimising Wheel Fitment

Mountune has simplified the process with its exclusive OZ Racing Ultraleggera HLT wheel, part of their Clubsport chassis upgrades. This wheel not only provides ample clearance for the Clubsport big brake kit but is also wider than the originals at 9 inches and features an optimised offset of ET58. This ensures the arches are perfectly filled without introducing any unwanted torque steer, a common concern with incorrect wheel fitment on high-powered front-wheel-drive cars.

The Importance of Quality Tyres

Dropping to 18-inch wheels is common for track use, allowing for the fitment of robust options like the Compomotive MO6. However, most owners tend to shy away from increasing to 20-inch wheels unless it's for a show car, as the required lower-profile tyres can significantly degrade ride comfort. It goes without saying that you should always fit decent tyres and avoid anything from the budget sector; after all, it's an RS, and its performance deserves nothing less than premium rubber.

Interior and Styling: Personalising Your RS

The RS was exceptionally well-specced as standard, boasting the legendary Recaro Sportster CS bucket seats, which provide both comfort and excellent support. What you choose to do with the interior will largely depend on your personal tastes and the car's intended use. Show cars might opt for a custom retrim with extensive carbon fibre additions, creating a luxurious and bespoke cabin. In contrast, a track weapon might see all unnecessary weight removed, replaced with a roll cage and four-point harnesses for safety and performance. It's a case of horses for courses, but thankfully, Fast Ford regularly features a wealth of modified cars to provide ample inspiration.

Exterior Styling: Making a Statement

The Ford Focus RS Mk2 was instrumental in popularising the aggressive graphics craze that swept through the fast Ford world. Its assertive shape lends itself perfectly to custom designs, leading to a diverse range of looks, from modern interpretations of classic race liveries to comic book heroes adorning the sides of Mk2s. Of course, you don't need to wrap an RS or paint it a unique colour to make it stand out, but it undoubtedly offers a blank canvas for self-expression. A wealth of styling upgrades are also available; subtle touches such as front splitters and side skirt extensions from Maxton Designs and Triple R Composites offer affordable yet effective tweaks. For those willing to spend more, plenty of sexy carbon fibre parts are available. For an ultra-aggressive appearance, large WRC-style rear wings and wide-arch kits are also readily available, allowing for truly dramatic transformations.

Comparative Table: Tuning Stages Overview

Frequently Asked Questions (FAQs)

Q: Is the Mk2 Focus RS reliable after tuning?

A: The reliability of a tuned Mk2 RS largely depends on the quality of the parts, the expertise of the tuner, and how far you push the power. Mild tunes (up to 400-420bhp) with quality bolt-ons are generally reliable. For higher power figures, internal engine upgrades and a robust fuel system are essential to maintain reliability. Regular maintenance and careful driving are also key.

Q: What's the 'block mod' and do I need it for my RS?

A: The 'block mod' involves shimming the cylinder liners to prevent them from moving under high pressure, a common issue in highly tuned Mk2 Focus ST engines. The RS block is substantially stronger from the factory, so this modification isn't typically necessary until you're chasing very high power figures (e.g., 600bhp+), unlike the ST where it's often recommended much earlier.

Q: Can I tune my Mk2 RS at home?

A: Basic tuning, such as installing an air filter, exhaust, and flashing a pre-made ECU map (like Mountune's mTune), can often be done at home. However, for more advanced stages requiring custom mapping, turbo upgrades, or internal engine work, it's highly recommended to use experienced specialists to ensure safety and optimal performance.

Q: What are the main limitations of the stock Mk2 RS for tuning?

A: The primary limitations for high-power tuning are the stock fuel system (around 370bhp), the standard intercooler (around 340-350bhp), the factory turbo (around 420bhp), and the engine's internal components (conrods, pistons) which typically reach their limit around 420-450bhp without forging.

Q: How much does it cost to get 500bhp from a Mk2 RS?

A: Achieving 500bhp typically requires a comprehensive set of modifications including a full exhaust system, uprated intercooler and boost pipes, a complete fuel system upgrade (injectors, pump), a hybrid turbo, upgraded camshafts, and a high-quality ECU tune. Expect costs to be in the range of £5,000 to £8,000, depending on parts chosen and labour. This doesn't usually include forged internals, which would add significantly to the cost.

The Ford Focus RS Mk2 is more than just a car; it's a statement, a passion project, and a testament to what's possible with dedication and engineering know-how. Its incredible adaptability means that whether your goal is a refined road rocket, a formidable track machine, or a visually stunning showstopper, the Mk2 RS provides the perfect foundation. With an army of specialists and an abundance of aftermarket parts, the only limit is your imagination and, of course, your budget. Embrace the journey, and create a Mk2 RS that is truly yours, embodying power, precision, and unparalleled style.
