Ciamillo Lekki8: The Ultra-Light Carbon Brake Revolution

The Dawn of a New Era in Lightweight Braking

The cycling world is constantly pushing the boundaries of what's possible, seeking that elusive combination of performance, weight reduction, and aesthetic appeal. In this relentless pursuit, a new contender has emerged, poised to redefine expectations for road bike braking systems. The all-new Ciamillo Lekki8 carbon fibre road brake calipers are not just an evolution; they represent a significant leap forward, setting a new record for the lightest complete road brake set available on the market. This innovation promises to captivate cyclists who prioritise every gram saved, without compromising on stopping power or reliability.

For those who understand the intricate art of bicycle component design, the name Ciamillo carries a certain weight. Known for meticulous engineering and a dedication to pushing the envelope, Ciamillo's latest offering, the Lekki8, is a testament to this legacy. This isn't merely a new product; it's a fresh start, a rebirth for designer Ted Ciamillo, now operating from Poland. The Lekki8 embodies this new beginning, bringing with it an almost unbelievable reduction in weight.

A New Benchmark in Featherlight Design

The most striking feature of the Lekki8 calipers is their astonishingly low weight. On Ciamillo's own calibrated scales, the complete set, including all necessary pads and hardware, tipped the scales at a mere 144 grams. To put this into perspective, this is significantly lighter than many high-end brake levers alone. The claimed weight, excluding the pads, is an even more astonishing 129 grams. This is broken down further with the front caliper weighing in at a scant 68 grams and the rear at a minuscule 61 grams. These figures are not just impressive; they are revolutionary, marking a new era of ultra-lightweight cycling components.

The Innovation Behind the Weight Saving

So, how has Ciamillo achieved such an extraordinary reduction in weight? The secret lies in the strategic and extensive use of carbon fibre. Unlike Ciamillo's previous GSL brakes, which featured a machined aluminium framework and weighed a still-respectable 155 grams, the Lekki8 has undergone a significant material transformation. The new calipers boast a predominantly carbon fibre body. These carbon fibre plates are expertly bonded to a central, machined aluminium cam. This innovative construction is held together by a carefully selected mix of lightweight yet robust materials, including titanium, alloy, and stainless steel hardware. This combination ensures that while the weight is dramatically reduced, the structural integrity and durability remain paramount.

The design philosophy behind the Lekki8 is a continuation and refinement of Ciamillo's earlier successful designs, such as the GSL and Zero G brakes. However, the Lekki8 incorporates several key improvements to enhance both performance and user experience:

Key Improvements in the Lekki8 Design:

• Enhanced Quick Release: A new, integrated quick-release mechanism has been incorporated, making wheel swaps significantly faster and more convenient. This is a crucial feature for any cyclist who frequently changes wheels or tyres.
• Pivoting Barrel Adjuster: The barrel adjuster, a small but vital component for fine-tuning brake cable tension, is now mounted on a pivot. This clever design ensures the adjuster stays perfectly aligned with the cable housing as the brake lever is pulled. This alignment minimises friction, leading to a smoother, more responsive brake feel and more consistent stopping power.
• Stiffer Cam Support: The central cam, the heart of the braking mechanism, is now supported by a centre bolt. This provides greater rigidity and stability to the entire system, translating into more direct and powerful braking.
• Redesigned Spring System: The return springs have been re-engineered to offer 30% more power. This increased spring tension ensures that the brake arms retract more quickly and decisively after braking, providing a snappier feel and quicker disengagement.

The Story Behind the Name: Lekki8

The name "Lekki8" itself tells a story of resilience and a fresh start. After years of operating as a one-man show, facing challenges with long lead times and occasional delivery issues that understandably frustrated customers, Ted Ciamillo made a significant life change. He closed down his US operations, sold off his equipment, got married, and relocated to Poland. This move to Poland, where he could leverage a lower cost of living and a new environment, allowed him to reboot his design and manufacturing process on a smaller, more manageable scale. "Lekki" is the Polish word for "lightweight," a fitting tribute to the core characteristic of his latest brake design. The "8" signifies that these are the eighth generation of brake calipers he has designed, showcasing a wealth of experience and continuous refinement.

Versatility and Customisation: Standard and Long Reach

Understanding that cyclists have diverse needs and rim preferences, the Lekki8 calipers are available in two distinct versions: standard reach and long reach. The long-reach variant is a prime example of the new modular design philosophy. The caliper legs can be detached and replaced with longer ones, adding an extra 5mm of reach. This expansion in length comes with a negligible weight penalty of just 2 grams. This feature is invaluable for riders whose brake pads might be too close to the tyre or the top of the rim, especially when using wider rims or slightly larger tyres. Both the standard and long-reach models are designed to accommodate rims with widths ranging from 19mm to 28mm and can comfortably clear tyres up to 32mm in width, offering considerable versatility for modern road bike setups.

Material Breakdown and Future Enhancements

The construction of the Lekki8 is a masterclass in material science for cycling components. The current versions predominantly utilise titanium hardware throughout. The critical centre bolt, for instance, features a titanium stud encased within an alloy bolt head, offering a perfect balance of strength, corrosion resistance, and weight. The smaller bolts that secure the carbon fibre plates, however, are currently made of steel. Ted Ciamillo has indicated that in the next production batch, these steel bolts will be replaced with titanium versions, an upgrade that is expected to shave off an additional 4 grams from the total weight. This continuous drive for refinement underscores the brand's commitment to achieving the absolute pinnacle of lightweight design.

Availability and Pricing

For cyclists in North America, Irish Cycles is handling the distribution of the Ciamillo Lekki8 calipers. European distribution is managed directly by Ciamillo from their Polish base. As of the time of this report, Ted confirmed that over 120 sets of these revolutionary brakes were in stock, ensuring timely delivery for eager customers. The pricing reflects the advanced materials and meticulous engineering involved:

Pricing Structure:

• Lekki8 Standard Reach Calipers: $539 per set. Buyers can choose between Shimano or Campagnolo style pad holders to suit their existing component groupset.
• Lekki8 Long Reach Calipers: $559 per set. This option provides the added versatility for specific frame and wheel combinations.

Frequently Asked Questions

Q1: Are the Ciamillo Lekki8 calipers truly the lightest available?
Yes, with a measured weight of just 144g for the complete set (including pads and hardware), they set a new benchmark for the lightest complete road brake set on the market.

Q2: What are the main materials used in the Lekki8 calipers?
The calipers feature a predominantly carbon fibre body with a machined aluminium cam, held together by a mix of titanium, alloy, and stainless steel hardware. Future versions will use more titanium hardware.

Q3: What is the weight of the front and rear calipers individually?
The front caliper weighs approximately 68g, and the rear caliper weighs approximately 61g (claimed weights without pads).

Q4: What is the significance of the name "Lekki8"?
"Lekki" is Polish for "lightweight," reflecting the primary feature of the calipers. The "8" indicates that these are the eighth generation of brake designs by Ted Ciamillo.

Q5: Do the Lekki8 calipers come in different reach options?
Yes, they are available in both standard reach and a long-reach version, which offers an additional 5mm of clearance and can be achieved by swapping the caliper legs.

Q6: What is the maximum tyre clearance for the Lekki8 calipers?
Both models can accommodate rims from 19-28mm wide and clear tyres up to 32mm.

Q7: Where can I purchase the Ciamillo Lekki8 calipers?
In North America, they are distributed by Irish Cycles. In Europe, distribution is handled directly by Ciamillo. You can also find more information at Lekki8.com.

Q8: How does the pivoting barrel adjuster improve performance?
The pivoting barrel adjuster minimises friction on the brake cable by staying aligned with the housing as the brake lever is actuated, resulting in a smoother and more responsive braking feel.

Conclusion: A Featherweight Champion

The Ciamillo Lekki8 carbon fibre road brake calipers are more than just a component; they are a statement. They represent the culmination of years of design experience, a bold embrace of new materials, and a renewed commitment to innovation. For the weight-conscious cyclist, the performance enthusiast, or simply the rider who appreciates cutting-edge engineering, the Lekki8 offers an unparalleled combination of lightness, refinement, and stopping power. They are a testament to what can be achieved when design, materials, and passion converge, setting a new standard for what we can expect from the braking systems on our road bikes. The future of lightweight braking is here, and it's incredibly light.
