Triumph Bonneville: A Ride Through Time

14/05/2022

Rating: 3.9 (2014 votes)

The Triumph Bonneville, a name that resonates with motorcycle enthusiasts worldwide, represents more than just a machine; it's a slice of British motoring heritage. While the modern iteration may not boast the raw performance pedigree of its 1960s namesake, the English motorcycle has masterfully rebranded itself as a versatile, do-it-all machine for the everyday rider. Available in various guises, including the standard, the upmarket T-100, and the more accessible SE model, the Bonneville line has cast its widest net yet, appealing to a broad spectrum of riders.

What is a Triumph Bonneville?
The Triumph Bonneville is an English motorcycle that retains the styling panache of its identically named predecessor from the 1960s. It has rebranded itself as a do-it-all everyman’s motorbike, although it does not have the performance pedigree established in that era.
Table

The Bonneville SE: A Nimble Urban Navigator

Our exploration of the Triumph Bonneville line brings us to the Bonneville SE, a model that proves itself adept at handling a diverse range of road conditions. Even in a locale like New Orleans, known for its unique blend of urban challenges and scenic byways, the SE shines. Its low seat-height instils confidence, making light work of navigating potholes and dense traffic. At a standstill, the rider can comfortably plant both feet, a testament to its accessible ergonomics. The SE is not just a city bike, however; it offers a satisfying experience when venturing into the fascinating bayou country that surrounds the city.

Cruising down iconic streets like St. Charles Avenue, past historic universities and towards the Mississippi River levee, becomes a pure joy. The 865cc parallel-twin engine, with its 90mm bore and 68mm stroke, delivers a pleasingly torquey performance, offering a claimed 50 ft-lbs of torque at 5800 rpm. While not an automatic, the Bonneville SE provides an easy-to-ride feel, akin to that of a larger scooter. Twisting the throttle unleashes a smooth surge of power, complemented by a light and intuitive clutch. The gearbox, with its five well-spaced ratios, makes shifting effortless, and the wide powerband means that choosing the right gear is rarely a chore. Despite its 495 pounds (wet, claimed) weight, the vertical twin engine's low centre of gravity makes the Bonneville SE highly maneuverable, particularly in urban environments.

The overall riding experience is remarkably transparent, thanks to a natural seating position that offers a commanding view of the road ahead. Be prepared for admiring glances, though. The authentically retro styling, complete with fuel injectors cleverly disguised as carburetors and a fast-idle knob that mimics a choke, along with eye-catching two-tone paint schemes, ensures the Bonneville SE is a head-turner.

Open Road Comfort and Character

Venturing beyond the city limits, the Bonneville SE continues to impress. Following the meandering Mississippi west, the unintimidating nature of the SE allows for spontaneous side trips, such as a jaunt to the top of a levee for panoramic views. The air-cooled motor, while producing a respectable 66 horsepower at 7500 rpm, is most at home cruising at or near the speed limit, rather than being pushed to its absolute limits. The 360-degree firing interval contributes to a persistent, consistent, and appealing vibration that adds to the bike's character. The 4.2-gallon fuel tank provides ample range for exploring, reducing the frequency of fuel stops.

The handling characteristics of the Bonneville SE are well-matched to its modest power output. The 17-inch wheels are fitted with narrower, higher-profile tyres (110/70 front; 130/80 rear) that prioritize comfort over outright performance, aligning perfectly with the Bonneville's intended mission as a relaxed cruiser. Even in tighter, more demanding terrain, such as the Santa Monica Mountains, the SE remains a pleasure to ride, provided one doesn't push too hard.

Suspension and Braking: Functionality Over Flash

The suspension, provided by Kayaba, is adequate for the bike's intended purpose, offering a comfortable ride without being overly plush. Similarly, the single-disc front brake provides sufficient stopping power for the Bonneville SE's performance envelope. It's important to reiterate that this is a friendly, approachable motorcycle, a far cry from the race-bred machines of Triumph's past. For those seeking sharper performance and handling, models like the Speed Triple and Street Triple are readily available on the showroom floor.

The Triumph Bonneville: An Enduring Appeal

It's easy to be momentarily unimpressed by a motorcycle as disarmingly straightforward as the Triumph Bonneville SE. It doesn't aim to wow you with blistering speed or razor-sharp handling. Instead, it fosters a deep sense of satisfaction and enjoyment. It's a motorcycle that looks effortlessly cool, functions precisely as it should, and makes every ride an easy and pleasurable experience. The Bonneville SE embodies the joy of the ride itself. Think of it as an upright cruiser, but with a welcome dose of peppier performance and more engaging handling.

Why did you choose to specialise in cylinder heads?

Key Features and Specifications (Bonneville SE)

Engine TypeAir-cooled, DOHC, parallel-twin
Displacement865cc
Bore x Stroke90mm x 68mm
Fuel SystemMulti-point sequential electronic fuel injection with SAI
Max Power66 hp (49kW) @ 7500 rpm
Max Torque50 ft-lbs (68Nm) @ 5800 rpm
Transmission5-speed
FrameSteel, tubular cradle
Front SuspensionTelescopic forks
Rear SuspensionPreload adjustable twin shocks
Front BrakeSingle 320mm disc
Rear BrakeSingle 255mm disc
Front Tyre110/70-17
Rear Tyre130/80-17
Seat HeightApprox. 740mm (29.1 inches)
Fuel Tank Capacity16 litres (4.2 US gal)
Wet Weight (claimed)Approx. 225kg (495 lbs)

Frequently Asked Questions

What type of engine does the Triumph Bonneville have?

The Triumph Bonneville is powered by a 865cc, air-cooled, DOHC parallel-twin engine. This engine configuration is a hallmark of the Bonneville lineage, providing a characteristic blend of torque and character.

Is the Triumph Bonneville good for beginners?

Yes, the Triumph Bonneville, particularly the SE model with its lower seat height and manageable power delivery, is often considered a very good motorcycle for beginner riders. Its predictable throttle response, light clutch, and stable handling make it an approachable and confidence-inspiring machine.

What is the difference between the Bonneville SE and the Bonneville T100?

While both share the same core engine and chassis, the Bonneville T100 typically features more premium styling elements, such as spoke wheels, a two-tone paint scheme, and often chrome accents, giving it a more classic, vintage look. The SE generally has cast wheels, a slightly lower seat, and is positioned as a more accessible entry point into the Bonneville family.

Does the Triumph Bonneville have fuel injection?

Yes, modern Triumph Bonnevilles are equipped with multi-point sequential electronic fuel injection, which ensures cleaner emissions, improved fuel economy, and more consistent performance across various conditions. The styling of these injectors is often designed to resemble classic carburetors for aesthetic continuity.

What kind of riding is the Triumph Bonneville best suited for?

The Triumph Bonneville excels at relaxed cruising, commuting, and general-purpose riding. Its comfortable ergonomics, accessible power, and stylish retro design make it ideal for leisurely rides through the countryside, navigating city streets, and enjoying the journey without the need for extreme performance.

Riding Gear for the Bonneville Experience

To complement the riding experience on a Triumph Bonneville, a thoughtful selection of riding gear is essential. While personal preference plays a significant role, the following items are often favoured by riders seeking both protection and style:

  • Helmet: Arai Profile (known for comfort and safety)
  • Jacket: Dainese Chiodo-TT Pelle (offering classic leather protection)
  • Gloves: Dainese X-Ile (providing good grip and feel)
  • Jeans: Cortech Mod Denim (offering abrasion resistance with a casual look)
  • Boots: Cortech Solution WP (for comfort and protection)

This gear selection reflects a balance between protective functionality and a style that complements the retro aesthetic of the Triumph Bonneville, ensuring riders can enjoy their journeys safely and in comfort.
