Brembo Brake Upgrade for 2022+ WRX

Can You Fit Brembo Brakes to a 2022+ WRX?

For owners of the 2022 and onwards Subaru WRX, the allure of enhanced stopping power is undeniable. Many enthusiasts look towards the highly regarded Brembo braking systems, often seen on previous generations of the Subaru WRX STI, as the ultimate upgrade. The question on many minds is whether it's possible to transplant this superior braking performance onto the latest WRX platform. The answer is a resounding yes, but with crucial caveats and the necessity of specific, engineered components.

The 2022+ WRX represents a significant evolution for the model, built upon Subaru's Global Platform (SGP). This new architecture brings with it revised front suspension geometry. This means that, unlike older WRX models where STI Brembo brakes could often be a direct bolt-on affair, the latest generation requires a more considered approach. The mounting points for the calipers have been shifted outwards, necessitating a change in how the brake rotor is positioned relative to the hub. Simply put, the older STI brake rotors will no longer align correctly with the new caliper mounting locations.

The Challenge and the Solution

Several proposed solutions have emerged to address this geometric change. One common method involves inserting a spacer between the brake rotor and the hub. However, this approach is often frowned upon by performance-minded individuals for several valid reasons. Firstly, it necessitates the replacement of the factory wheel studs with longer versions to accommodate the spacer. This not only adds to the overall cost of the upgrade but also increases the complexity and labour involved in the installation process. Secondly, and perhaps more critically, placing a spacer behind the brake rotor can introduce undesirable vibration issues. This is due to a loss of the precise hubcentric fitment that both the rotor and the wheel rely on for stability. Any imperfections in the flatness of the spacer itself can also exacerbate these vibrations, leading to a less refined driving experience and potentially premature wear on other components.

A more elegant and robust solution involves the design of a custom-made front brake rotor. Specifically, a two-piece rotor design featuring a lightweight, black-anodized aluminium hat has proven to be the optimal approach. This custom rotor is engineered to precisely compensate for the changed caliper mounting location on the 2022+ WRX. By utilising these specially designed rotors, the Brembo calipers can be bolted directly onto the vehicle, mimicking a factory-fit installation. This eliminates the need for spacers, longer studs, and the associated risks of vibration and compromised hubcentricity.

What's Included in a Complete Brembo Upgrade Kit?

A comprehensive Brembo brake upgrade kit for the 2022+ WRX typically includes everything required to transform your car's stopping power. These kits are designed to be a complete solution, offering genuine, brand-new Subaru Brembo calipers. You'll usually find the iconic 6-piston front calipers and 2-piston rear calipers, often available in striking finishes like fluorescent yellow-green or silver, complete with the distinctive black STI logo.

The heart of the front upgrade lies in the custom-designed, two-piece brake rotors. These are often manufactured by reputable brands and feature a slotted design for improved heat dissipation and performance. The lightweight aluminium hats contribute to reducing unsprung mass, which can have a positive impact on overall vehicle dynamics. For the rear, you'll typically find high-quality rotors from manufacturers like KNS or DBA, ensuring a balanced braking performance across the entire vehicle. The kit will also include OEM Subaru brake pads, chosen for their reliability and performance characteristics, along with all the necessary pins, clips, and hardware required for a proper installation. The typical rotor diameters for such a kit are approximately 13.4 inches for the front and 12.8 inches for the rear.

Brake Lines and Installation Considerations

While the kit usually includes all the essential hardware, it's worth noting that you have the option to retain your existing brake lines or upgrade to a set of performance-oriented braided stainless steel brake lines. These aftermarket lines can offer a firmer pedal feel and improved durability. However, meticulous attention must be paid during installation. It is absolutely crucial to ensure that the brake lines do not come into contact with any moving parts of the vehicle, particularly the wheels. This is especially important if you are fitting larger diameter wheels, as the clearance can become tighter.

Minor modifications to the existing dust shields are also part of the installation process. You will likely need to trim the outer lip of the rear brake rotor dust shield to accommodate the larger caliper. Similarly, a small portion of the front dust shield may require trimming to ensure adequate clearance for the bigger Brembo calipers. These are relatively minor modifications that can be easily performed with basic tools.

Wheel Clearance: A Critical Factor

One of the most significant considerations when upgrading to Brembo brakes, especially the larger STI calipers, is wheel clearance. These calipers are notably substantial in size and are positioned further outboard on the 2022+ WRX compared to previous STI models. This means that not all wheels will fit over them without modification or specific design considerations.

It is important to verify that your chosen wheels have sufficient spoke design and offset to clear the calipers. While some aftermarket wheels are specifically designed to accommodate larger brake systems, many factory wheels, and even some aftermarket options, may not offer the necessary clearance. For instance, the 18-inch OEM 2022+ WRX wheels can be used with this upgrade, but they absolutely require the addition of a 20mm wheel spacer to provide adequate clearance. Without this spacer, the OEM wheels will not fit. It is always advisable to consult with the kit provider or a reputable wheel specialist to confirm compatibility before purchasing new wheels or attempting the installation.

Rotor Longevity and Caliper Aesthetics

The custom two-piece front rotors are designed for longevity and ease of maintenance. The system typically allows for the replacement of just the cast iron rotor rings when they eventually wear out, while the black-anodized aluminium hats can be reused. This can be a more cost-effective solution in the long run compared to replacing entire one-piece rotors.

It's also important to manage expectations regarding the cosmetic condition of the Brembo calipers themselves. As these are often sourced directly from Subaru and shipped with minimal protection, it's not uncommon for them to arrive with minor cosmetic imperfections. Subaru packages them to prevent major damage, but minor scuffs or dings in the finish can occur during transit due to their weight and movement within the packaging. These minor cosmetic flaws are considered normal and are generally not grounds for return or exchange. The scarcity and demand for these calipers mean that suppliers often receive them with these minor blemishes.

Kit Options and Compatibility

Brake upgrade kits are often available in various configurations to suit different needs and budgets. You can typically purchase a full-car set, which includes both front and rear upgrades, or opt for a front-only or rear-only kit if you wish to complete the upgrade in stages. This flexibility allows you to tailor the upgrade to your specific requirements.

Regarding vehicle compatibility, these kits are designed to fit all 2022 and onwards Subaru WRX models. However, there is a specific exclusion for the rear kit: it cannot be fitted to CVT (Continuously Variable Transmission) equipped cars that feature an electronic parking brake. This is due to the integrated nature of the parking brake mechanism on these specific models. Manual transmission vehicles and older CVT models without the electronic parking brake are generally compatible.

Frequently Asked Questions

In conclusion, upgrading your 2022+ WRX with Subaru STI Brembo brakes is a feasible and highly rewarding modification. By utilising the correct, engineered components such as custom two-piece rotors and paying close attention to critical details like wheel clearance and installation procedures, you can significantly enhance your vehicle's braking performance and achieve a look that is both functional and aesthetically pleasing. Always ensure you consult with specialists and follow all safety guidelines during the installation process.
