Mastering Your Vehicle's Shaft Drive System

The shaft drive and final gear assembly are integral components of many vehicle's drivetrain, tirelessly working to transmit power from the engine to the rear wheel. While often overlooked, the health of these components is paramount for a smooth, reliable, and safe driving experience. Understanding how to diagnose, maintain, and correctly reassemble these critical parts can save you significant time and expense, ensuring your vehicle performs optimally for years to come. This comprehensive guide will walk you through the essential troubleshooting, inspection, and reassembly procedures for the shaft drive and final gear, empowering you to tackle common issues with confidence.

Troubleshooting Common Shaft Drive Issues

Identifying potential problems with your shaft drive system early can prevent more severe damage and costly repairs. While some symptoms can be subtle, a keen ear and careful observation can help pinpoint issues before they escalate. It's crucial to distinguish between noises originating from the shaft drive and those from the engine or transmission, as this distinction guides your diagnostic path.

Diagnosing Specific Symptoms

Certain sounds and sensations are tell-tale signs of underlying issues within the shaft drive components. Pay close attention to how your vehicle behaves under different conditions, such as acceleration, deceleration, and sustained speed.

Important Note: Damage to bearings, improper gear lash, and gear tooth damage can be exceedingly difficult to diagnose. The symptoms might be very subtle and easily mistaken for normal operating noises. If you suspect damage, it's always best to remove the components for a thorough, specific inspection.

Inspection Notes for Noises:

• Rolling Rumble: If a "rolling rumble" is present, observe if it increases with rear wheel speed, rather than engine or transmission gear speeds, during coasting, accelerating, or decelerating. However, remember that wheel bearings can also produce similar noises.
• Noise Varying with Acceleration/Deceleration: A high-pitched whine, particularly noticeable during deceleration, might indicate insufficient gear lash following an incorrect reassembly. CAUTION: Insufficient gear lash is extremely destructive to gear teeth. If a test ride after reassembly reveals this condition, cease riding immediately to minimise further damage to the gears.
• Slight "Thunk": A subtle "thunk" should be differentiated from normal vehicle operation. It's most apparent at low speeds and could be a warning sign of broken gear teeth. WARNING: If broken gear teeth are suspected, stop riding your vehicle immediately. This condition poses a severe risk, potentially leading to the shaft drive assembly locking up and causing harm to the rider.
• Loose Bolts: If the drive flange/universal joint bolts are slightly loose, you might feel a distinct "clunk" when slowly pulling away or when transitioning from slow acceleration to slow deceleration. At higher speeds, this can manifest as noticeable vibration. WARNING: Do not continue riding a vehicle if you suspect loose flange/universal joint bolts. These components could fail, leading to serious injury.

Troubleshooting Chart for Noise Issues

When basic conditions like a "rolling rumble" or varying noise exist, follow this diagnostic flow:

1. Front Wheel Check: Elevate the front of the vehicle and spin the front wheel. Feel for any indication of wheel bearing damage. If damage is detected, replace the wheel bearing.
2. Rear Wheel Check (Initial): If the front wheel bearings are fine, proceed to check the rear wheel for bearing damage. If no damage is found here, it's less likely that the rear wheel bearings or shaft drive bearings are the source of the noise. Repeat the test or consider removing individual components for closer inspection.
3. Rear Wheel Removal & Inspection: If the rear wheel check suggests damage, remove the rear wheel and inspect its bearings. If damaged, replace them.
4. Drive Shaft Components: If all wheel bearings are ruled out, the issue likely lies within the drive shaft components, which should then be removed for further inspection.

Oil Leak Inspection

Suspecting an oil leak from a shaft drive component requires a meticulous approach to pinpoint the exact source. Begin by thoroughly cleaning the entire vehicle, as dust and grime can obscure or misdirect your leak detection. Once clean and dry, apply a leak-localising compound or a dry-powder spray. This substance will clearly highlight the path of any escaping oil. Operate the vehicle for a short distance to allow any leak to become visible. Bear in mind that a housing might be damaged by road debris or an accident, or a gasket/seal could be cracked. However, on new vehicles, an apparent leak might simply be a rust-preventative coating or excess assembly lubrication. Always re-clean and re-check the area to confirm any actual leakage.

Checking Drained Oil

Whenever you suspect a problem with either the middle or final gear assemblies, draining and inspecting the oil is a crucial diagnostic step. The presence of metal particles on the drain plug or within the oil itself can indicate a bearing seizure or another internal component failure. While a small amount of metallic dust in the oil is normal, larger particles or significant quantities warrant immediate investigation and likely component replacement.

Final Gear Removal Procedures

To access the final gear assembly for inspection or service, follow these methodical steps:

1. Remove the rear axle.
2. Remove the rear wheel.
3. Remove the left shock absorber.
4. Remove Nut 1 (as per service manual diagrams).
5. Carefully remove the final gear assembly 2 (as per service manual diagrams).
6. Remove the four nuts securing the Final Drive unit to the swing arm.
7. Finally, remove the entire final gear assembly from the vehicle.

Gear Lash Check and Adjustment

Maintaining the correct gear lash is vital for the longevity and smooth operation of your final gear. Gear lash refers to the small amount of clearance or play between the teeth of two meshing gears. Too little lash can cause excessive wear and heat, while too much can lead to noise and accelerated wear.

Measurement Process:

1. Secure the gear case firmly in a vice or other suitable support.
2. Remove one nut from the final gear case stud bolt. Install the gear holder (a special tool) over the ring gear surface and stud bolt, securing it with a nut.
3. Install the final gear lash measurement tool onto the gear coupling.
4. Mount a dial gauge against the lash measurement tool at the scribed mark (typically 60 mm or 2.36 inches from the centre of the shaft).
5. Using a special wrench, gently rotate the gear coupling back and forth. Carefully note the lash measurement displayed on the dial gauge.

Final Gear Lash Specifications:

Adjustment Procedure:

If the measured gear lash falls outside the specified limits, adjustments are necessary:

• To reduce gear lash, you need to increase the thickness of the ring gear shim.
• To increase gear lash, you need to reduce the thickness of the ring gear shim.

Important consideration: If it's necessary to increase the ring gear shim by more than 0.1 mm, you should simultaneously reduce the thrust washer thickness by 0.1 mm for each 0.1 mm of ring gear shim increase. Conversely, if you need to reduce the shim by more than 0.1 mm, reverse this procedure.

Disassembling the Final Gear

Disassembly of the final gear assembly should be performed with care, particularly when dealing with bearings and specific fasteners. Remember that some components, once removed, should not be reused.

1. Remove the nuts and bolts securing the bearing housing.
2. Carefully remove the ring gear assembly and the thrust washer from the final gear case.
3. Remove the self-locking nut from the drive pinion. This requires a holding tool (special tool) to secure the pinion while loosening the nut. Once the nut is off, remove the coupling.
4. Remove the drive pinion bearing retainer using a specific retainer remover (special tool). CAUTION: The drive pinion bearing retainer nut has left-hand threads. To loosen it, turn the retainer nut clockwise.
5. Remove the drive pinion and bearing using a slide hammer and adapter (special tool). CAUTION: This drive pinion removal should only be performed if gear replacement is absolutely necessary. Do not reuse bearings or races after they have been removed.
6. Remove the guide collar, oil seal, and roller bearing from the main housing. This process typically requires a press tool (special tool No. 1) and a hydraulic press, along with appropriate supports for the main housing. The roller bearing may be reused if it is entirely undamaged, but the oil seal should always be replaced with a new one.
7. Rear Drive Pinion Roller Bearing Removal (Advanced): Removal of this specific bearing is often difficult and seldom required. If necessary, heat the bare housing to 150°C (302°F) to expand the metal. Then, use an appropriately shaped punch to remove the roller bearing outer race. The inner race can then be removed from the drive pinion.

Reassembling the Final Gear: A Detailed Guide

Reassembly requires precision, particularly when installing bearings and determining shim thicknesses for correct gear positioning. This process is crucial for the optimal performance and longevity of the final gear.

1. Install New Rear Drive Pinion Roller Bearing: Begin by installing the new rear drive pinion roller bearing. For a smooth installation, heat the bare bearing to 150°C (302°F) and use an appropriately sized adapter with a press to install the roller bearing outer race. Subsequently, install the inner race onto the drive pinion.
2. Install Guide Collet, Oil Seal, and Roller Bearing: Using press tool No. 2 (special tool) and a press, install the guide collet, a new oil seal, and the roller bearing into the main housing in that specific order. While a removed roller bearing can be reused if undamaged, it is highly recommended to replace it with a new one for reliability.

3. Final Drive/Ring Gear Positioning (Shimming)

   Note: Gear positioning is absolutely necessary whenever the final gear case, ring gear bearing housing, or any bearing(s) are replaced with new components. This involves calculating precise shim thicknesses to ensure correct mesh and alignment.

   a. Calculating Shim Thickness "A" for Drive Pinion Gear Positioning:
   This thickness is calculated from specific numbers found on the final gear case and the drive gear end.

   To find shim thickness "A", use the formula: A = a - b

   • a = A numeral (usually a decimal number) found on the gear near the tooth, which is either added to or subtracted from the nominal size "84".
   • b = A numeral found on the gear case, appearing as a whole figure (e.g., 83.50).

   Example Calculation for Shim "A":
   If the pinion gear is marked "+01", then 'a' is 84.01.
   If the gear case is marked "83.50", then 'b' is 83.50.
   Therefore, A = 84.01 - 83.50 = 0.51. The necessary shim thickness is 0.51 mm.

   Shim sizes are typically supplied in specific increments. If your calculated thickness doesn't match available shims exactly, use the following rounding chart:

   Last Digits	Rounding (to nearest 0.05 mm increment)
   0, 1, 2	0
   3, 4, 5, 6, 7	5
   8, 9	10

   b. Calculating Shim Thickness "B" for Ring Gear Positioning:
   This thickness is derived from information on the final gear case, ring gear, and bearing.

   To find shim thickness "B", use the formula: B = c + d - (e + f)

   • c = A numeral on the gear case appearing as a whole figure (e.g., 45.52).
   • d = A numeral (usually a decimal number) on the outside of the ring gear bearing housing, added to the nominal size "3".
   • e = A numeral (usually a decimal number) on the inside of the ring gear; either added to or subtracted from the nominal size "35.40".
   • f = A bearing thickness, considered a constant value of 13.00 mm.

   Example Calculation for Shim "B":
   If the gear case is marked "45.52", then 'c' is 45.52.
   If the ring gear bearing housing is marked "35", then 'd' is 3.35.
   If the ring gear is marked "+01", then 'e' is 35.40 + 0.01 = 35.41.
   'f' is 13.00.
   Therefore, B = 45.52 + 3.35 - (35.41 + 13.00)
B = 48.87 - 48.41
B = 0.46. The necessary shim thickness is 0.41 mm (applying rounding rules).

   Note: Use the same rounding chart as for the drive pinion shim calculation to select the correct ring gear shim size.

4. Install Drive Pinion Gear: Install the drive pinion gear with the correct size of shimming and secure it using the bearing retainer nut. Use the drive pinion bearing retainer remover (special tool) for this. Note: The bearing retainer nut has left-hand threads, so turn the nut counter-clockwise to tighten it. Tighten to a torque of 11 m-kg (80 ft-lb).
5. Adjust Gear Lash: Install the ring gear assembly, but initially without the thrust washer. Proceed to adjust the gear lash as detailed in the "Gear Lash Check and Adjustment" section.
6. Measure Thrust Clearance with PLASTIGAGE: Place four pieces of "PLASTIGAGE" between the originally fitted thrust washer and the ring gear. Install the gear case onto the ring gear assembly and tighten the nuts and bolts to the specified torque of 2.3 m-kg (16.6 ft-lb). NOTE: Do not turn the drive pinion/ring gear when measuring clearance with "PLASTIGAGE", as this will skew the readings.
7. Determine Clearance: Remove the ring gear assembly and carefully determine the thrust clearance by measuring the width of the flattened "PLASTIGAGE" against its provided scale. The specified ring gear thrust clearance is 0.1 ~ 0.2 mm.
8. Replace Thrust Washer if Necessary: If the measured clearance exceeds the specification, replace the thrust washer with one of a different thickness to achieve the proper clearance.

Drive Shaft and Universal Joint

The drive shaft and universal joint are crucial for transmitting rotational power while allowing for movement and articulation. Proper inspection and reinstallation are essential for vehicle safety and performance.

A. Removal

1. Remove the rear wheel.
2. Remove the final gear case assembly.
3. Remove the drive shaft. This may require following the swing arm removal procedure.
4. To remove the universal joint, it is necessary to remove the swing arm. Once the swing arm is off, remove the universal joint assembly.

B. Inspection

1. Drive Shaft: Carefully inspect the shaft splines for any signs of wear or damage. If excessive wear is observed, the drive shaft must be replaced. Note: When reinstalling the drive shaft, always lubricate the splines with molybdenum di-sulfide grease to ensure smooth operation and prevent wear.
2. Universal Joint:
   • There should be absolutely no noticeable play in the universal joint bearings. Any detected play indicates damage, and the universal joint assembly must be replaced.
   • Move the universal joint up and down, and from side to side. It should move smoothly without any tightness, binding, or rough spots. These symptoms are indicative of damaged bearings, necessitating replacement of the entire universal joint assembly.

C. Reinstallation

When installing the drive shaft and the universal joint, reverse the removal procedure. Pay close attention to the following critical points:

1. Lubricate the shaft splines thoroughly with molybdenum di-sulfide grease before installation.
2. Tighten the universal joint securing bolts and the final gear case securing nuts to their specified torque values to ensure safety and proper operation.

Frequently Asked Questions (FAQs)

Q1: What does a "rolling rumble" from my rear wheel area indicate?

A1: A "rolling rumble" that increases with rear wheel speed, rather than engine speed, could point to damaged shaft drive bearings or potentially rear wheel bearings. Further diagnosis by isolating components is recommended.

Q2: Why is proper gear lash so important for the final gear?

A2: Proper gear lash ensures that the gear teeth mesh correctly, preventing excessive wear, noise, and heat buildup. Too little lash can cause rapid wear and even gear failure, while too much can lead to noisy operation and premature component fatigue.

Q3: Can I reuse the oil seal or bearings after disassembling the final gear?

A3: It is strongly recommended to replace oil seals with new ones whenever they are removed, as they are prone to damage and leakage upon reinstallation. While some roller bearings might be reusable if undamaged, it is generally advised to replace them with new ones during a major overhaul to ensure maximum reliability and prevent future issues.

Q4: What should I do if I suspect loose universal joint bolts?

A4: If you suspect loose universal joint bolts, you must stop riding immediately. Continuing to ride can lead to component failure, which could result in a loss of power transmission or even severe injury due to parts breaking away.

Q5: Why is heating parts necessary during some reassembly steps?

A5: Heating components, particularly bearing races or housings, causes them to expand slightly. This expansion allows for easier and less stressful installation of bearings, ensuring they seat correctly without damage. Once the heated part cools, it contracts, creating a secure, interference fit with the bearing.

Maintaining the shaft drive and final gear assembly is a critical aspect of vehicle care, ensuring reliable power delivery and a smooth ride. By understanding the common symptoms of problems, performing meticulous inspections, and following precise reassembly procedures, you can significantly extend the life of these vital components. Always prioritise safety, use the correct tools, and adhere to specified torque values to prevent costly repairs and ensure your vehicle remains in top condition.
