Rotax Engine Overhaul & Upgrade Costs

When it comes to keeping your aircraft in peak condition, the engine is undoubtedly the heart of the operation. Rotax engines, renowned for their reliability and performance in the light aviation sector, are a popular choice for many aircraft owners and builders. However, like any mechanical component, they require periodic maintenance, and often, owners consider upgrades to enhance performance or longevity. This article delves into the costs associated with overhauling and upgrading various Rotax engine models, providing a comprehensive guide for those looking to invest in their aircraft's powerplant.

Understanding Rotax Engine Services

There are generally three main avenues when it comes to Rotax engine services: complete engine solutions, overhaul and upgrade packages, and overhaul-only services. Each offers a different approach to refreshing or enhancing your engine's capabilities.

Complete Engine Solutions

These are pre-assembled engines that do not require you to supply your existing unit. They represent a 'turnkey' solution for those who want a new or upgraded engine without the process of sending in their own for work. These are often the most straightforward option if you don't have a core engine to provide.

Overhauled and Upgraded Solutions

This service begins with your existing Rotax engine. It is then meticulously overhauled to restore it to its optimal operating condition, and simultaneously, it can be upgraded with performance-enhancing modifications. This is a popular choice for those who want to leverage their current engine's components while benefiting from modern improvements.

Overhaul-Only Option

For owners who simply want to restore their engine to factory specifications without any performance enhancements, an overhaul-only service is available. This focuses on replacing worn parts, refurbishing critical components, and ensuring the engine runs as reliably as it did when new.

Rotax Engine Options and Pricing

The following table outlines the costs for various Rotax engine configurations, including complete solutions and specific upgrade paths:

Rotax 612 “Big Bore” Explained

The Rotax 612 “Big Bore” upgrade is a significant performance enhancement. By increasing the cylinder bore size from the standard 582's dimensions to 76mm-78mm, and incorporating custom rods, this engine configuration pushes out an impressive 73+ horsepower. Crucially, it is designed to utilise the stock 582 exhaust system, making it a more integrated upgrade. The crankshaft is specifically built to handle this increased power output, ensuring durability and reliability.

Rotax 612 “RAVE” and Rotax 670 “King Kong”

Taking performance further, the Rotax 612 “RAVE” also benefits from the larger 76mm-78mm cylinders and custom rods, but with the addition of RAVE (Rotary Aspiration Valve Enhancement) technology. This results in a substantial 83 horsepower. However, this increased power necessitates a custom RAVE exhaust system, which is priced separately. Similarly, the Rotax 670 “King Kong” is the pinnacle of performance in this range, delivering a formidable 92 horsepower. This also requires the custom 612/670 RAVE exhaust. While the company generally doesn't work on 670 engines, exceptions may be made for specific operational conditions, such as high-elevation airports.

Gearbox Considerations

The gearbox is a critical component that interfaces the engine with the propeller. Compatibility and cost are important factors when selecting or upgrading your engine. Here's a breakdown:

The “E” gearbox is often the most cost-effective way to incorporate electric start into your engine setup, adding $2150 to the overall cost. It's important to match the gearbox to the engine's power output to avoid potential damage or performance limitations.

Overhauled Engine Pricing

Restoring your existing Rotax engine to its former glory is a cost-effective way to ensure continued airworthiness and performance. The overhaul service typically includes a comprehensive list of replacements and inspections:

• Rebuilding the crankshaft with new double-slotted connecting rods, main bearings, rod bearings, thrust washers, and crank pins.
• Installation of a new piston and ring kit.
• Rebuilding of the Rotary Valve system as necessary.
• Installation of a ceramic water pump seal.
• Bead blasting and meticulous inspection of all parts.
• Priming, painting, and application of a two-part clear coat.
• Surface treatment of the cylinder head.
• Implementation of oil feed modifications.
• Thorough inspection and testing of the Ducati dual ignition system.
• Replacement of spark plugs, wires, caps, and coil protection boots.
• Sonic cleaning of carburetors and inspection of all jets.
• Installation of new carburetor boots.
• Replacement of all seals and gaskets.
• Inspection of the customer's gearbox, reinstallation with a propeller, and a 2-hour test run.
• Provision of a new Logbook and a 2-year warranty commencing from the first flight.

The cost for overhauling several popular Rotax models is consistent:

It's worth noting that there are known differences between the grey head and blue head versions of the Rotax 582, which may influence specific overhaul procedures or part requirements. Further information on these distinctions can be found through dedicated technical resources.

Overhauled and Upgraded Engine Options

Combining an overhaul with an upgrade offers a significant performance boost for a relatively modest additional cost compared to purchasing a completely new, higher-spec engine. These kits are designed to be integrated during the overhaul process.

The Value of Upgrades

Consider the Rotax 582 to Rotax 612 “Big Bore” upgrade. For an additional $575 on top of a standard $2850 overhaul, you gain approximately 10-15 horsepower. This is a significant increase in performance that can translate to better climb rates, higher cruising speeds, or the ability to operate from shorter airstrips. Similarly, the “RAVE Boss” upgrade provides a dramatic power increase, making it an attractive option for those seeking maximum performance from a 582-based engine.

Custom Exhaust Systems

For the higher-performance Rotax 612 “RAVE” and Rotax 670 “King Kong” engines, a specialized exhaust system is mandatory. These custom exhausts are designed to complement the engine's increased power output and ensure efficient scavenging of exhaust gases.

Custom 612/670 RAVE Exhaust:

• Price Range: $780 to $880
• Styles Available: Side mount (with mounting brackets) and L-shaped Gyro style.
• Includes: RAVE Y-pipe and all necessary hardware.

The choice between exhaust styles often depends on the specific aircraft installation and available space. It's a crucial component for unlocking the full potential of these upgraded engines.

What Parts Do We Use?

Customers have the option to specify the use of ONLY Rotax certified parts. While this ensures adherence to OEM standards, it's important to acknowledge that the availability of traditional Rotax parts for older models, particularly the 670, can be a limiting factor. If a customer requests the exclusive use of Rotax certified parts, and these are available, the cost will be adjusted accordingly. This flexibility allows owners to tailor their overhaul or upgrade to their specific preferences and budget, balancing the desire for genuine parts with the practicalities of availability and cost.

Frequently Asked Questions (FAQ)

Q1: How much does a Rotax 582 overhaul cost?

A standard overhaul for a Rotax 582 engine costs $2850. This includes a comprehensive rebuild and a 2-year warranty.

Q2: What is the cost of a Rotax 612 “Big Bore” upgrade?

The “Big Bore” upgrade kit for a Rotax 582 costs $575, in addition to the standard overhaul cost. This results in approximately 75 horsepower.

Q3: Do I need a special exhaust for the Rotax 612 “RAVE” engine?

Yes, the Rotax 612 “RAVE” engine, which produces 83 horsepower, requires a custom 612/670 RAVE exhaust, typically costing between $780 and $880.

Q4: Can I upgrade my Rotax 582 to a Rotax 670?

Yes, a conversion kit is available to upgrade a Rotax 582 to a Rotax 670 “King Kong” specification, producing 92 horsepower. This kit costs $5275 and requires a custom exhaust.

Q5: What is the cost of adding electric start to my Rotax engine?

Adding electric start typically involves selecting an “E” gearbox, which costs an additional $2150.

Q6: What is covered in a Rotax engine overhaul?

A comprehensive overhaul includes replacing critical engine components like pistons, rings, bearings, and seals, rebuilding the crankshaft and rotary valve system, performing inspections, testing ignition and carburetors, and a final test run. A new logbook and warranty are also provided.

Conclusion

Investing in the overhaul or upgrade of your Rotax engine is a crucial step in maintaining the safety, reliability, and performance of your aircraft. The pricing provided offers a clear insight into the costs involved, whether you're looking for a standard overhaul or a significant performance enhancement. By understanding these options and associated costs, aircraft owners can make informed decisions to keep their engines running smoothly and powerfully for years to come. Remember to consult with your service provider for the most accurate and up-to-date pricing and to discuss your specific aircraft requirements.
