Straighten Your Steering Wheel

It's a common, albeit frustrating, issue: your steering wheel isn't centred when your car is driving straight. This misalignment not only looks unsightly but can also affect your car's handling and even tyre wear. Fortunately, in most cases, correcting a crooked steering wheel is a straightforward process that many drivers can tackle themselves. This article will guide you through understanding why this happens and how to fix it, ensuring your wheels are pointing true.

Understanding the Steering Wheel Alignment

Your steering wheel's position is directly linked to your car's wheel alignment. When your steering wheel is off-centre, it typically indicates that your car's suspension and steering components are not perfectly aligned. This can be caused by a variety of factors, from hitting a pothole to general wear and tear on your suspension parts. The goal of steering wheel alignment is to ensure that your wheels are pointing in the direction you intend, with the steering wheel centred in its natural position.

Common Causes of a Crooked Steering Wheel

Several factors can lead to your steering wheel being off-centre:

• Impacts: Hitting potholes, curbs, or debris on the road can knock your suspension and steering components out of alignment. Even a seemingly minor bump can have an effect over time.
• Worn Components: Over time, parts like tie rods, ball joints, and bushings can wear down. This wear can introduce play into the system, allowing the steering wheel to drift from its centred position.
• Incorrect Alignment Adjustments: If your car has had a previous wheel alignment, it's possible it wasn't set correctly, or that the alignment has shifted since then.
• Suspension Damage: More significant damage to suspension parts, perhaps from an accident, will almost certainly affect steering wheel centering.

Can You Fix a Crooked Steering Wheel Yourself?

The answer is often yes, especially for minor misalignments. The key lies in adjusting the tie rods. These are adjustable metal rods that connect your steering wheel mechanism to your wheels. By lengthening or shortening them, you can change the angle of the wheels and, consequently, the position of your steering wheel when the wheels are straight. However, it's crucial to understand that this is a delicate adjustment. For significant issues or if you're unsure, professional help is always recommended.

DIY Steering Wheel Straightening: A Step-by-Step Guide

Before you begin, gather your tools: a socket set, a wrench, potentially a torque wrench, and a way to safely lift your vehicle, such as jack stands. It's also advisable to have a helper. Always prioritize safety; ensure your vehicle is on a level surface and properly supported.

Step 1: Assess the Misalignment

Park your car on a flat, level surface. Ensure your tyres are pointing as straight ahead as possible. Then, get out and look at your steering wheel. Is it slightly off-centre, or significantly askew? Note how much you have to turn it to the left or right to make the car go straight. This assessment is vital for knowing how much adjustment you'll need.

Step 2: Lift and Secure the Vehicle

Using your jack, carefully lift the front of your vehicle. Place jack stands under the designated support points on the chassis. Slowly lower the vehicle onto the jack stands. Never work under a vehicle supported only by a jack. Ensure the vehicle is stable and secure before proceeding.

Step 3: Locate the Tie Rods

Look under the front of your car, near the wheels. You'll see the steering rack, which connects to the wheels via tie rods. Each tie rod has an inner and outer end. The outer end typically screws into an adjustable sleeve or 'tie rod end'. This is where the adjustment will be made.

Step 4: Loosen the Tie Rod Locking Nut

Each adjustable tie rod end will have a locking nut. This nut prevents the tie rod from moving once it's set. You'll need to loosen this locking nut using a wrench. Often, you might also need to hold the tie rod itself with another wrench to prevent it from turning while you loosen the nut.

Step 5: Make the Adjustment

Now, for the critical part. If your steering wheel is turned too far to the right when the wheels are straight (meaning you have to turn the wheel to the left to correct it), you need to lengthen the left tie rod and shorten the right tie rod. Conversely, if your steering wheel is turned too far to the left, you need to shorten the left tie rod and lengthen the right tie rod.

To adjust, you'll turn the adjustable sleeve on the tie rod. Turning the sleeve clockwise will generally lengthen the tie rod, and counter-clockwise will shorten it. Make small, incremental adjustments – perhaps a quarter or half a turn at a time. Remember, you're adjusting both sides to maintain the overall length and alignment.

Crucially, make the same adjustment on both sides but in opposite directions. For example, if you turn the right side's sleeve a quarter turn clockwise, turn the left side's sleeve a quarter turn counter-clockwise. This keeps the total length of the tie rods the same, preventing further alignment issues.

Step 6: Tighten the Locking Nut

Once you've made an adjustment, tighten the locking nut back up firmly. You may need to hold the tie rod sleeve in place with a wrench while tightening the nut to prevent it from moving. Then, re-tighten the locking nut.

Step 7: Lower the Vehicle and Test

Carefully lower your car back to the ground. Get in the driver's seat and check your steering wheel. Does it feel centred when the car is going straight? If not, repeat steps 2 through 6, making further small adjustments until it's correct. Once satisfied, take your car for a cautious test drive. Ensure the steering feels responsive and the car tracks straight.

Important Considerations and Warnings

• Tyre Wear: Incorrect wheel alignment can lead to uneven and premature tyre wear. Addressing a crooked steering wheel promptly can save you money on new tyres.
• Handling and Safety: A misaligned steering system can affect your car's handling, making it pull to one side, or feel unstable. This is a safety concern.
• Torque Settings: If you have a torque wrench, consult your car's manual for the correct torque settings for the tie rod locking nuts. Over-tightening or under-tightening can cause problems.
• Professional Alignment: While these DIY steps can correct minor steering wheel centering issues, they do not replace a full wheel alignment. A professional alignment checks and adjusts all the critical angles (camber, caster, toe) for optimal tyre wear and handling. If your steering wheel is significantly off, or if you notice pulling to one side, it's best to book a professional alignment.

When to Seek Professional Help

You should always consult a qualified mechanic if:

• The steering wheel is severely misaligned.
• Your car pulls noticeably to one side when driving straight.
• You hear any unusual noises from the steering or suspension system.
• You are uncomfortable performing the DIY adjustments.
• After your DIY adjustments, the problem persists or worsens.

Frequently Asked Questions

Q1: How much does it cost to fix a crooked steering wheel?

A simple steering wheel centering adjustment by a mechanic might cost anywhere from £30 to £70, depending on your location and the garage. However, if the crooked steering wheel is a symptom of a larger alignment issue, a full four-wheel alignment can cost between £60 and £120.

Q2: Will a crooked steering wheel affect my MOT?

Yes, a steering wheel that is significantly off-centre can be a reason for an MOT failure, as it indicates a potential problem with the steering system or alignment, impacting safe driving.

Q3: Can I just adjust the steering wheel itself?

No, the steering wheel is typically splined to the steering column. While the steering wheel can be removed and re-fitted, doing so without understanding the splines and the steering column's indexing can worsen the problem or lead to safety issues. Adjusting the tie rods is the correct method for centering the wheel relative to the direction the car is going.

Q4: How often should I get my wheel alignment checked?

It's recommended to have your wheel alignment checked annually, or if you notice any signs of misalignment such as uneven tyre wear, the car pulling to one side, or a crooked steering wheel.

By understanding the mechanics behind a crooked steering wheel and following these steps carefully, you can often resolve this common automotive nuisance yourself, leading to a more pleasant and safer driving experience.
