Kawasaki Z1300: The Mighty Six Cylinder's Quirks

The Kawasaki Z1300, a colossal six-cylinder, water-cooled behemoth, arrived on the scene just a year after Honda's equally impressive CBX. While the CBX had set a high bar, the Z1300 upped the ante with a staggering 120 bhp, a full 15 horses more than its rival. This era was marked by a fierce debate in the motorcycle press regarding the escalating power output from Japanese manufacturers, with whispers of government legislation looming to curb the horsepower race between the 'Big Four'. Britain even introduced a voluntary 125 bhp agreement to preempt any political intervention.

Undeniably powerful, the Z1300's engine alone tipped the scales at more than a typical 125cc bike of the time. Coupled with its shaft drive and a substantial six-gallon fuel tank, the entire package weighed in at a massive 660 lb. Initial impressions from some quarters, such as the author's own experience in Cologne, dismissed the bike as a 'dinosaur', favouring lighter, more agile machines like the Suzuki GS1000 or the Kawasaki Z650. This sentiment was fuelled by the fact that the GS1000 could rival the Z1300 in a straight line but significantly outperform it in the bends, leading to questions about the Z1300's purpose.

The Z1300's Purpose and Success

Despite these early criticisms, the Z1300 enjoyed a production run of ten years, selling around 20,000 units. The primary driver for its existence was likely corporate one-upmanship in the power race. However, contemporary testers were captivated by the bike's remarkably smooth power delivery and its ability to effortlessly cruise at speeds exceeding 100 mph. Ironically, these speeds were only legally permissible on German autobahns, where a voluntary power limit of 100 bhp was in place. As 'Superbike' magazine aptly put it in 1979, "As an exercise in corporate one-upmanship it’s a dazzling success, which isn’t altogether surprising considering that this is its raison d’etre. What is surprising is that, lurking under the tinsel and technology and almost secondary to this central purpose, is a surprisingly good heavyweight bike."

Engineering and Design Choices

Kawasaki's journey with the Z1300 concept began in 1973. To keep the engine relatively narrow, they opted for watercooling and a mere two valves per cylinder. Fuel was supplied by three carburettors, a contrast to the Honda CBX's more intricate arrangement of six angled carburettors. The frame was a conventional, albeit significantly beefed-up, twin-cradle design, typical of the era. Suspension was equally standard, featuring robust 41mm leading axle front forks with air assistance and simple twin shock absorbers at the rear. While many testers of the time considered its handling to be quite competent for its size, this view was not universally shared. Dave Marsden of Z-Power, a former parts manager for a Kawasaki dealership, famously described it in a 1999 'Mechanics Z-Files' article as handling "quite well compared to a pig on stilts," questioning the judgment of contemporary road testers.

Common Problems and Early Faults

As Dave Marsden highlighted, the Z1300 was indeed not without its issues. Owners frequently reported a range of problems, including:

• Leaking fork seals: A persistent issue that compromised front-end performance.
• Warped front brake discs: Affecting braking efficiency and potentially causing vibration.
• Seized rear discs: A serious safety concern that could lead to sudden deceleration.
• Worn rear shocks: Often found to be significantly degraded after as little as 2,000 miles, impacting ride quality and handling.

These early faults were often addressed by Kawasaki under warranty. The author's experience with a later model, registered in 1990 and built in 1989 (the final model year), offered a glimmer of hope that some of these issues had been rectified. This particular bike, owned by John Penney, featured improvements in the suspension department, boasting better forks and rear air shocks. A significant evolution was the introduction of fuel injection in 1984, replacing the carburettors and reportedly boosting power to 130 bhp.

A Ride on a Later Model Z1300

John Penney, the owner of the 1990 Z1300 (a Z-G1300 model), acquired the bike for a considerably reduced price from its original asking of £4000. He had previously postponed a test ride due to winter weather. Having toured the North Yorkshire Moors with luggage and his wife as a pillion, John described the bike as "comfortable but not the best in corners." Despite this, a 1,000-mile trip with the improved suspension made the ride feel like a "wafting along" experience. The odometer showed a modest 11,600 miles.

An intriguing feature of John's bike, possibly indicating American manufacturing origins, was a 'cruise control' button on the switchgear. The juxtaposition of such immense horsepower with a button to enforce a 55 mph speed limit was, as John noted, "Bizarre."

During the test ride, the author initially found the Z1300's 660 lb weight daunting, particularly when navigating junctions at low speeds. While the shaft drive was commendably smooth, free from the transmission snatch found on some V-twin Guzzis, the sheer bulk of the machine made the rider feel less than confident about maintaining balance if a foot had to be put down.

Handling and Performance Characteristics

As the ride progressed, it became evident that the Z1300 demanded a specific riding style. Aggressive inputs and forceful cornering were counterproductive, often leading to front-end wavering under acceleration. The key to managing this powerful machine was rhythm; allowing the bike to flow through bends rather than trying to steer it aggressively. Smoothness and neatness were paramount, with throttle adjustments needing to be subtle. Backing off or aggressively opening the throttle to drive through corners proved ineffective.

The engine, however, was a revelation. Once fully warmed, it idled with the smoothness of a Swiss watch. A slight twist of the throttle sent the 'big Zed' surging forward, the six-into-two exhaust system emitting an unexpectedly shrill wail – a truly magnificent sound. The redline was set at 8500 rpm, and the tachometer needle would race towards it with astonishing speed. While the top speed was quoted at 140 mph, John admitted he "wouldn't want to try" reaching it.

Despite encountering hailstorms and wet roads, the author began to appreciate the Z1300's immense power delivery. Reaching speeds of 100 mph revealed its exceptional straight-line stability; it was phenomenally fast and steady, with no hint of front-end nervousness under power. This confirmed its suitability as a long-distance, fast touring machine. Even considering the earlier handling criticisms, the later model, when ridden with the appropriate style, handled reasonably well. On a smooth, fast track, it was even speculated that it might out-corner a CBX in skilled hands, though it still stood no chance against a GS1000 in the bends. The steering was inherently slow due to the long wheelbase, but once pointed in the desired direction, the bike would dutifully follow.

The Z1300's Legacy

The Z1300, while a remarkable feat of engineering for its time, was never destined to be a revolutionary milestone in motorcycle development in the same vein as the GPz900. The era of the large muscle bikes was already waning by the time of its launch, with manufacturers shifting towards lighter, more compact machines offering comparable power with vastly improved handling.

In conclusion, should one own a Z1300 today? Neil Murray's assessment from a 1993 'Mechanics' article offers valuable insight: "Don’t write off the 13 as a useless lump. It really works very well, especially as a tourer. While not yet really collectable, it certainly will be in the near future. Any well-kept model is unlikely to depreciate." The Z1300 remains a testament to an era of unbridled power and ambition, a machine that, despite its quirks, carved out a unique and enduring place in motorcycle history.

Frequently Asked Questions

What were the main problems with the Kawasaki Z1300?

The most common issues reported were leaking fork seals, warped front brake discs, seized rear discs, and prematurely worn rear shock absorbers. Later models saw improvements, particularly with the introduction of fuel injection and revised suspension components.

Was the Z1300 a heavy bike?

Yes, the Z1300 was exceptionally heavy, weighing around 660 lb when fully fuelled, due to its large six-cylinder engine and robust construction.

How did the Z1300 handle?

Early models were criticised for their handling, described as ponderous or unwieldy. Later models, especially those with improved suspension and fuel injection, handled better but still required a smooth, rhythmic riding style rather than aggressive inputs. Its long wheelbase contributed to slow steering.

What was the power output of the Z1300?

The carburetted models produced around 120 bhp, while the later fuel-injected models saw an increase to approximately 130 bhp.

Is the Kawasaki Z1300 a collectable motorcycle?

While not yet considered a highly collectable classic by all, well-maintained examples are increasingly sought after, and their value is expected to appreciate in the future, particularly for the later fuel-injected models.
