Dyna Dual Front Disc Brake Conversion

Many Harley Davidson Dyna Glide owners lament the single front brake setup as a significant weakness, often citing a lack of stopping power. For those who demand superior performance and enhanced safety, especially on a motorcycle weighing over 600 lbs, the addition of a second front brake is often considered essential. Fortunately, the Dyna platform is well-suited for this modification, readily accepting parts from various Harley models, making the conversion a popular and achievable upgrade. This comprehensive guide will walk you through the process of converting your 2000-2015 Harley Davidson Dyna Glide from a single front disc brake to a more potent dual front disc brake system.

Why Convert to Dual Front Discs?

While a single front brake might suffice for leisurely cruising, it can prove inadequate for more spirited riding or emergency situations. The increased mass of a Dyna requires a robust braking system to ensure rider safety and confidence. A dual disc setup significantly improves:

• Stopping Power: More friction surface means more stopping force.
• Brake Feel: Better modulation and feedback from the levers.
• Heat Dissipation: Two rotors spread the heat load, reducing fade under heavy use.
• Aesthetics: Many riders find the dual disc look more aggressive and balanced.

Parts and Tools You'll Need

Before embarking on this project, gather all necessary components and tools. While original Harley parts are an option, aftermarket kits and salvaged parts from other Harley models can offer significant cost savings.

Essential Parts:

• Fork Leg(s) with Caliper Mounts: You'll need at least one right-side fork leg, or potentially both, depending on your chosen donor parts. These are identifiable by the mounting bosses for the brake caliper.
• Brake Calipers: Two front brake calipers are required.
• Brake Rotors: Two front brake rotors compatible with your chosen wheels and calipers.
• Master Cylinder: A larger bore master cylinder (typically 11/16") from a Harley Touring model is recommended to adequately supply fluid to both calipers.
• Brake Lines: A new set of brake lines designed for a dual disc setup is essential. Braided stainless steel lines are a popular upgrade for improved feel and durability.
• Fork Oil: The correct weight and amount as specified in your Dyna's service manual.
• Threadlocker (Blue): For securing rotor bolts.
• Anti-Seize Lubricant: For the front axle.
• New Fork Seals and Dust Covers (Recommended): It's good practice to replace these while the forks are disassembled.

Required Tools:

• SAE Wrench and Socket Set
• Hex (Allen) Wrench Set (Sockets or T-handles)
• 3/8" and 1/2" Ratchets, Breaker Bar, and Extensions
• Torque Wrenches (in/lbs and ft/lbs)
• Catch Pan and Shop Rags
• Fork Seal Driver (Essential for proper seal installation)
• Phillips and Flat Head Screwdrivers
• Parts Cleaner
• Punch (Drift)
• Hammer
• Rubber Mallet
• Motorcycle Jack
• Fork Holding Tool (Recommended for fork disassembly)
• Vise (Recommended for fork disassembly)

Step-by-Step Conversion Guide

Step 1: Lift and Support the Bike

Safely lift the front of your Dyna using a reliable motorcycle jack. Ensure the bike is stable and securely supported before proceeding. The goal is to have the front wheel clear the ground, allowing for easy removal.

Figure 1. Motorcycle supported by frame jack. (Illustrative description)

Step 2: Prepare for Fork Leg Removal

Begin by removing the front fender. Undo the mounting bolts or nuts securing the fender to each fork leg and carefully remove it. This will provide better access to the fork components.

Figure 2. Fender mounting bolts. (Illustrative description)

Next, drain the brake fluid from the front brake system. Attach a length of vinyl hose to the caliper bleed nipple. Remove the master cylinder reservoir cap. Open the caliper bleeder screw and operate the brake lever to purge the fluid into a catch container. Once drained, close the bleeder and remove the hose.

Figure 3. Draining brake fluid from system. (Illustrative description)

Disconnect the brake line from the caliper by removing the banjo bolt. Repeat this process for the brake line at the master cylinder. Remove the caliper mounting bolts and slide the caliper off the rotor. Set the caliper aside.

Figure 4. Caliper/brake line removal points. (Illustrative description)

Remove the front axle nut and washer. Loosen the slider cap bolts (pinch bolts) on the right fork leg, then carefully slide the front axle out of the fork legs to remove the front wheel.

Figure 5. Front wheel removal. (Illustrative description)

Finally, loosen the pinch bolts on both the upper and lower triple clamps that secure the fork(s). You can now carefully slide the fork leg(s) out of the triple clamps.

Figure 6. Loosening triple clamp pinch bolts for fork removal. (Illustrative description)

Step 3: Replace Fork Leg and Rebuild Fork

This step involves swapping out your existing fork leg for one equipped with brake caliper mounting points. If your current fork legs are not compatible, you'll need to replace them. Disassembling the fork requires care and the right tools. Using a fork holding tool and a vise is highly recommended to prevent damage.

Figure 7. Exploded view of front fork. (Illustrative description)

Fork Disassembly:

1. Loosen Damper Rod Bolt: With the fork spring still under tension, loosen the damper rod bolt (also known as the seat pipe bolt) located at the bottom of the fork leg. This prevents the damper rod from spinning during removal. Have a catch pan ready as fork oil will drain out.
2. Remove Fork Cap Assembly: Carefully remove the fork tube cap, O-ring, washer, and spring collar. Be aware that these components are under spring pressure, so proceed with caution.
3. Remove Fork Slider Cover: Use a punch to tap the fork slider cover at the designated slot, allowing it to slide off.
4. Remove Seal Retaining Ring: Pry out the fork seal dust cover to expose the fork seal retaining ring. Use a small screwdriver to carefully remove this clip.
5. Separate Fork Tube and Leg: Grip the fork tube and fork leg firmly (or use a fork vise). Employ a smooth, sliding motion, akin to a slide hammer. This action will use the fork bushing on the tube to drive the upper bushing and seal out of the fork leg.
6. Retrieve Lower Stop: Once separated, retrieve the lower stop from inside the fork leg.

Figure 8. Damping rod bolt. (Illustrative description)
Figure 9. Fork seal cover removal. (Illustrative description)
Figure 10. Fork seal dust cover and seal retaining ring. (Illustrative description)
Figure 11. Separating fork tube from fork leg. (Illustrative description)

Fork Reassembly (with New Fork Leg):

1. Install Lower Stop: Place the retrieved lower stop into the new fork leg.
2. Assemble Fork Tube: Gently slide the fork tube assembly into the new fork leg. Slide the top bushing (bushing guide) over the tube, followed by the oil seal spacer (washer).
3. Install Bushing: Use a fork seal driver to carefully drive the bushing into place within the fork leg.
4. Lubricate and Install Oil Seal: Coat the lip of the new oil seal with fresh fork oil. Slide the seal onto the fork tube and drive it into its seat using the fork seal driver. The bushing, washer, and seal can often be driven in as a unit.
5. Install Retaining Ring and Covers: Fit the oil seal retaining ring, ensuring it snaps securely into the groove in the fork leg. Install the dust cover and the fork slider cover.
6. Install Damper Rod Bolt: Either compress the fork spring or install the spring, washer, and collar to keep the damper rod from spinning. Install and torque the damper rod bolt to the manufacturer's specification (typically 106-159 in/lbs).
7. Fill with Fork Oil: Add the correct amount and type of fork oil as specified in your service manual.
8. Exhaust Air and Install Cap: Pump the fork several times to remove any trapped air. Install the fork spring, spring collar, washer, and the fork cap with a new O-ring. Torque the fork cap to the specified range (typically 16-42 ft/lbs).

Figure 12. Fork seal driver being used to install the bushing, washer, and oil seal. (Illustrative description)

Note on Fork Leg Replacement: If you're not comfortable disassembling the forks, many suspension specialists can perform a fork leg swap for a reasonable fee, typically between $150-$200.

Step 4: Install Fork, Wheel, and New Brake Calipers

With the fork leg(s) replaced and the forks reassembled, it's time to put the front end back together.

1. Install Forks: Slide the fork(s) back through the upper and lower triple clamps. Snug the triple clamp bolts for now.
2. Set Fork Height: Adjust the fork height so that the top of the fork tube protrudes through the upper clamp by approximately 1/2 inch. This measurement is taken from the top of the fork bolt to the top surface of the upper triple clamp.
3. Torque Triple Clamps: Torque the upper and lower triple clamp pinch bolts to the specified values (typically 30-35 ft/lbs).
4. Install Rotors: Mount the new brake rotor(s) onto the wheel hub. Apply blue Threadlocker to the fastening bolts and torque them to the specified range (typically 16-24 ft/lbs).

Figure 13. Measuring fork tube protrusion. (Illustrative description)
Figure 14. Installing new brake rotors. (Illustrative description)

5. Install Front Wheel: Lightly lubricate the axle with anti-seize compound. Position the front wheel between the fork legs and slide the axle into place. Install the axle washer and nut. Torque the axle nut to the specified value (typically 60-65 ft/lbs).
6. Tighten Slider Cap Bolts: First tighten the rear slider cap bolt (pinch bolt) to the specified torque (10-14 ft/lbs), followed by the front slider cap bolt to the same specification.
7. Install Calipers: Slide the new brake calipers onto the new brake rotors. Tighten the caliper mounting bolts securely (typically 28-33 ft/lbs).
8. Reinstall Fender: Attach the front fender to its mounting points on the fork legs and tighten the mounting nuts (typically 15-21 ft/lbs).

Pro Tip: Some Dyna models may come from the factory 'dual brake disc ready,' meaning the wheel hub is already set up for a second rotor. Check your wheel hub for the necessary mounting holes.

Step 5: Replace Master Cylinder and Brake Lines

A dual disc system requires a master cylinder capable of delivering more brake fluid volume than a single disc setup. To ensure proper operation and feel, the stock 9/16" bore master cylinder should be replaced with a larger 11/16" unit, commonly found on Harley Touring models. While some riders prefer the feel of a smaller bore master cylinder, the larger unit generally provides better performance for dual discs.

Figure 15. Larger master cylinder for dual brakes. (Illustrative description)

Along with the new master cylinder, you must install a new set of brake lines designed to feed both calipers. This is an ideal opportunity to upgrade to braided stainless steel lines for improved aesthetics and performance.

Figure 16. Typical dual brake line kit. (Illustrative description)

For detailed instructions on replacing the master cylinder, consult a guide on master cylinder replacement.

Step 6: Bleed the Brakes

The final and crucial step is to fill the front brake system with fresh brake fluid and meticulously bleed all air from the lines and calipers. Proper bleeding is paramount for achieving optimal braking performance and a firm lever feel.

Figure 17. Filling master cylinder with fresh brake fluid prior to bleeding. (Illustrative description)

For a comprehensive guide on bleeding your brakes, refer to a dedicated brake fluid replacement tutorial.

Frequently Asked Questions

Q1: Can I use parts from different Harley models?

A: Yes, the Dyna is quite adaptable. Many components from Sportster, Softail, and Touring models can be cross-referenced for this conversion. However, always confirm compatibility before purchasing.

Q2: Do I need to replace my wheel?

A: Not necessarily. Many Dyna wheels are already designed to accept a second rotor. Check your wheel hub for the correct bolt pattern and spacing.

Q3: How long does this conversion typically take?

A: For an experienced DIY mechanic, the process can take anywhere from 4 to 8 hours. If you're less experienced, allow a full weekend to ensure thoroughness and avoid rushing.

Q4: What are the torque specifications for key components?

A: Torque specs vary slightly by model year. Always consult your specific Dyna service manual. However, common torque values are provided within this guide for reference (e.g., axle nut, triple clamps, caliper bolts, rotor bolts).

Q5: What if I'm uncomfortable doing this myself?

A: If you lack the confidence or tools for any part of this process, particularly fork disassembly or brake bleeding, it's wise to seek professional help from a qualified motorcycle mechanic or a reputable custom shop.

Conclusion

Converting your Harley Davidson Dyna from a single to a dual front disc brake system is a significant upgrade that dramatically enhances safety and performance. While it requires a degree of mechanical aptitude and the right tools, the ability to stop more effectively is a worthwhile investment for any Dyna rider. By following these steps, you can transform your Dyna's braking capabilities and enjoy a more confident and controlled riding experience.
