31/12/2020
The CFMOTO Ibex 800, known as the 800MT in many parts of the world, has quickly cemented its place as a formidable contender in the middleweight adventure touring segment. Built upon the proven foundation of KTM's 790 Adventure engine platform, this motorcycle offers an impressive blend of performance, technology, and value. However, like any precision machine, its longevity and reliability hinge significantly on adhering to a diligent maintenance schedule, particularly regarding crucial tasks such as oil changes. What might surprise many owners, especially those in different geographical locations, is the marked discrepancy in recommended oil change service intervals.
The Curious Case of Varying Oil Change Intervals
At the heart of the CFMOTO Ibex 800 / 800MT lies a 799cc liquid-cooled parallel twin engine, a direct descendant of the powerplant found in KTM's 790 series motorcycles. This heritage suggests a robust and well-engineered unit capable of handling substantial mileage between services. Indeed, for most of the world, CFMOTO recommends a generous oil and filter change interval of 9,000 miles (15,000 km). This aligns closely with the maintenance schedule of its KTM brethren, a testament to the engine's inherent durability and design efficiency.
However, for owners in the United States, the picture is notably different. CFMOTO USA advises a significantly shorter oil and filter change interval: every 3,000 miles (5,000 km) or 12 months. This three-fold reduction in recommended mileage for oil changes is a critical point of divergence and one that owners must be acutely aware of, depending on where their motorcycle was purchased or is primarily ridden. This regional variation underscores the importance of consulting your specific owner's manual, or the manual relevant to your region, to ensure compliance with the manufacturer's guidelines and preserve your warranty.
Beyond Oil: Comprehensive Maintenance for Your Ibex 800
While oil changes are paramount, they are but one facet of a holistic maintenance regimen designed to keep your CFMOTO Ibex 800 / 800MT running optimally. The overall maintenance schedule is quite comprehensive, though it can appear somewhat intricate due to varying intervals for different components. To simplify, we can categorise the maintenance into annual checks and periodic services.
Annual Service Checklist
Regardless of mileage, certain checks should be performed annually to ensure all systems are functioning correctly and safely. These are general inspections and adjustments that contribute to the bike's overall health and rider safety.
- Brake and clutch levers, and brake pedal – inspect, adjust (Brake free play: 10-15mm / 0.4-0.6 inches; Brake pedal free play: 5-10mm / 0.2-0.4 inches)
- Throttle system – inspect
- Tyre condition – check condition and pressure
- Front and rear brakes – inspect
- Brake discs – inspect thickness, condition
- Brake pads – inspect thickness
- Brake fluid level – inspect
- Brake lines – check for damage, kinks
- Steering bearings – check
- Front and rear suspension – check for leaks
- Radiator fan function – check
- Cooling hoses – check
- Chain guard – inspect
- Electrical wiring, check for damage and kinks
- Electrical equipment – inspect function
- Diagnostic interface – check for trouble codes with diagnostic tools
Periodic Maintenance Schedule
The periodic maintenance schedule dictates when specific components require inspection, replacement, or adjustment based on mileage or time, whichever comes first. This schedule is crucial for the long-term reliability of your Ibex 800 / 800MT.
| Item | US Interval (miles / km) | ROW Interval (miles / km) | Time Interval |
|---|---|---|---|
| Engine Oil – replace | 3,000 / 5,000 | 9,000 / 15,000 | Every Year |
| Oil filter – replace | 3,000 / 5,000 | 9,000 / 15,000 | Every Year |
| Oil screen – clean | 3,000 / 5,000 | 9,000 / 15,000 | Every Year |
| Clutch – inspect | 9,000 / 15,000 | ||
| Idle speed – inspect / adjust | 9,000 / 15,000 | ||
| Throttle valve – clean | 9,000 / 15,000 | ||
| Coolant – inspect level | 9,000 / 15,000 | Every Year | |
| Coolant – replace | Every 4 Years | ||
| Air filter – replace | 9,000 / 15,000 | Every Year | |
| Spark plugs – replace (NGK LMAR9AI-10, Gap: 1.0 mm, Torque: 10 Nm / 7 ft-lb) | 18,000 / 30,000 | ||
| Valve clearances – inspect / adjust | 18,000 / 30,000 | ||
| Wheel bearings – inspect | 9,000 / 15,000 | ||
| Brake fluid – replace | Every 2 Years | ||
| Battery – inspect | 3,000 / 5,000 | Every 6 Months | |
| Fuse / circuit breakers – check function | 3,000 / 5,000 | Every 6 Months | |
| Suspension system – check | 3,000 / 5,000 | Every 6 Months | |
| Frame – check for damage, rust | 18,000 / 30,000 | ||
It's worth noting that the break-in schedule, typically a first service involving an oil and filter change, is a crucial initial step not explicitly detailed in the regular schedule but implied as an early annual service.
Chain Maintenance: A Critical Element for Adventure Riding
Given the Ibex 800's adventurous spirit, often traversing challenging terrains and varied weather conditions, meticulous chain maintenance is paramount. A well-maintained chain ensures efficient power transfer, extends the lifespan of components, and enhances safety.
| Chain Maintenance Item | Interval |
|---|---|
| Check lubrication, and lubricate if necessary | Every 600 km (or after riding in rain / washing bike) |
| Chain tension – check deflection | Every 1,000 km |
Checking and Adjusting Chain Tension
Correct chain tension is vital. To check it, place your motorcycle on its side stand on a level surface with the transmission in neutral. Measure the distance between the lowest point of the swingarm and the chain; it should be approximately 30mm (1.2 inches) in its natural state. Gently push down on the chain with a finger; the deflection should not exceed 50mm (2 inches).
If adjustment is needed:
- Loosen the rear wheel nut and the left and right locking nuts on the swingarm.
- Adjust the adjusting bolts, ensuring you move them by the same amount on both sides, using the reference marks for alignment.
- Once the correct tension is achieved, tighten the axle nut to 90 Nm (66 lb-ft).
- Re-check the chain tension to confirm it remains within specification.
- Finally, tighten the lock nuts securely.
Tyres: The Foundation of Your Ride
The CFMOTO 800MT / Ibex 800, whether the Sport with cast wheels or the Touring with spoked rims, shares identical tyre dimensions and specifications. Both variants come equipped with Maxxis tubeless tyres, designed for versatility and performance.
| Wheel Position | Tyre Size | Recommended Tyre Pressure (Cold) |
|---|---|---|
| Front | 110/80-19 | 33-35 psi / 225-240 kPa / 2.25-2.4 bar (One person / 2-up) |
| Rear | 150/70-17 | 36-41 psi / 250-280 kPa / 2.5 – 2.8 bar (One person – 2-up) |
The Touring model benefits from a Tyre Pressure Monitoring System (TPMS), a valuable feature for adventure riders who frequently adjust pressures for varying loads, pillions, or off-road excursions.
About the CFMOTO Ibex 800 / 800MT
The CFMOTO 800MT, or Ibex 800, represents a significant step forward for the Chinese manufacturer and the adventure touring market. It challenges preconceived notions about Chinese-made motorcycles, offering a genuinely high-specification, high-quality machine at a remarkably competitive price point. This achievement is largely due to CFMOTO's long-standing technology exchange and collaboration with KTM, where many KTM components are produced in Chinese factories. This partnership has allowed CFMOTO to license and utilise the proven KTM 790 engine, ensuring a reliable and spirited heart for the 800MT.
The 799cc 8-valve parallel twin engine produces a healthy 70 kW (95 hp / 94 bhp) at 9,000 rpm, delivering ample power for both touring and spirited riding. Its 270-degree crankshaft ensures a characterful engine note. Beyond the engine, the Ibex 800 comes loaded with standard features often found as expensive options on rivals, including multiple ride modes, a slipper clutch, cornering ABS, crash bars, a large TFT screen, fully adjustable suspension, and cruise control. The Touring model elevates this further with heated grips and seats, a taller windshield, hand guards, a centre stand, and a bash plate, making it an incredible value proposition. This combination of advanced features, a reliable engine, and an accessible price point makes the CFMOTO Ibex 800 / 800MT a compelling choice for adventure enthusiasts globally.
Frequently Asked Questions
Why are the oil change intervals different between the US and the rest of the world?
The exact reasoning for the differing intervals isn't explicitly stated by CFMOTO. However, it's common for manufacturers to adjust maintenance schedules based on regional market conditions, emissions regulations, typical riding styles, fuel quality, or even perceived consumer expectations. The longer interval for the 'rest of the world' aligns with the original KTM 790 engine's recommended service schedule, suggesting that engine design supports longer intervals. The shorter US interval could be a more conservative approach.
What type of engine oil should I use for my CFMOTO Ibex 800 / 800MT?
While this article focuses on intervals, always consult your owner's manual for the precise oil type, viscosity, and specification (e.g., API, JASO standards) recommended by CFMOTO. Using the correct oil is crucial for engine protection and performance.
Can I perform the oil change myself?
Yes, for experienced DIY mechanics with the right tools and knowledge, an oil change is a straightforward task. However, always follow the procedures outlined in your official service manual. If you're unsure or lack the necessary tools, it's always best to have the service performed by a qualified technician.
What happens if I extend my oil change interval beyond the recommended mileage?
Extending oil change intervals can lead to oil degradation, reduced lubrication effectiveness, increased engine wear, and potential voiding of your warranty. Engine oil breaks down over time and collects contaminants, losing its ability to protect vital engine components. Adhering to the recommended schedule is critical for engine longevity.
Is the KTM engine in the CFMOTO Ibex 800 / 800MT truly reliable?
The 799cc parallel twin engine from KTM has a strong reputation for reliability and performance in its original applications. Its integration into the CFMOTO platform, with CFMOTO's own quality control, generally maintains this high standard. The wide valve service intervals (18,000 miles / 30,000 km) are a good indicator of the engine's robust design and long-term durability, further reinforcing confidence in its reliability.
