Bike Brake Safety: Simple Adjustments

Are Your Bicycle Brakes Truly Safe?

Your bicycle's braking system is, without a doubt, the most critical safety feature on your bike. While modern bicycle brakes offer excellent stopping power, they are not immune to the effects of time and use. Over time, brake cables can stretch, brake pads can wear down, and a pad might even start to drag on the rim. Because your safety is paramount and directly dependent on optimal braking performance, we've put together these essential guidelines for common adjustments. These steps will help ensure your bike's 'grippers' are always in peak condition.

Important Note: These instructions are specifically for conventional caliper and cantilever brakes. If your bicycle is equipped with disc brakes, we strongly advise bringing it to our shop for any necessary adjustments. Furthermore, due to the significant impact brakes have on rider safety, we do not recommend attempting adjustments on your conventional brakes unless you are thoroughly confident in your mechanical abilities and can perform the job correctly. It's also crucial to remember that for any brake adjustment to be effective, your wheels must be true and round, meaning they should not have any side-to-side wobbles, up-and-down hops, or bends.

Should you have any questions or require assistance with your brake adjustments, please do not hesitate to give us a call or bring your bicycle in for professional service. We're always happy to help!

Tightening Your Brakes: Restoring That 'New' Feel

Many cyclists experience a slight loosening of their brake lever feel over time. This is often due to cable stretch and pad wear. Fortunately, a simple adjustment can often bring back that crisp, responsive feel.

Adjusting Barrel on Brake Levers (Upright Handlebars)

For off-road, comfort, hybrid, and city bikes typically featuring upright handlebars, you'll find a very convenient device on the brake lever itself, known as an adjusting barrel. This component usually has a knurled edge, making it easy to grip and turn by hand, eliminating the need for tools. It's the perfect solution for making your brakes feel like new again, especially after logging many miles and experiencing some pad wear.

You can even use the adjusting barrel during a ride if your brakes start to feel weak, which can sometimes happen in muddy or wet conditions. To use the adjusting barrels:

1. Turn the barrel counterclockwise by hand.
2. Check the brake feel by squeezing the lever.
3. Once the brakes feel appropriately firm, lock the barrel adjuster in place by turning the lockring (often a second knurled piece) clockwise until it's snug against the lever.

Adjusting on the Brake Caliper (Dropped Handlebars)

On road bikes with dropped handlebars, you'll typically find the adjusting barrels located directly on the brake calipers themselves. To tighten the brakes using these adjusters:

1. Turn the adjusters in the direction that moves the brake pads closer to the wheel rims.

Crucial Point: When your brake pads have worn down significantly, these adjusters will no longer be effective. In such cases, you'll need to turn the adjusters all the way back to their starting position and replace your brake pads to restore proper function.

Troubleshooting Dragging Brake Pads: The Wheel Alignment Factor

One of the most frequently encountered brake problems is a dragging brake pad – a pad that remains in contact with the rim, or stays too close to it, even after you've released the brake lever. The most common culprit for this issue is a misaligned wheel.

This misalignment often occurs when you reinstall a wheel after removing it, perhaps to fit your bike onto a roof rack or to fix a puncture, and you haven't seated it exactly in the centre of the frame or fork. This causes the brake to function improperly because it's then 'tight' against the frame, and it was originally adjusted to align correctly only with a perfectly centred wheel. With the wheel now crooked, the brake cannot operate as intended.

Centering Your Wheel

To correct a dragging brake pad caused by wheel misalignment, the solution is straightforward: simply centre the wheel within the fork or frame.

For the majority of wheels, this involves:

1. Loosening the quick-release skewer or axle nuts.
2. Ensuring the wheel is fully inserted into the dropouts of the fork or frame.
3. Tightening the quick-release skewer or axle nuts securely.

Tip: If your bike is standing upright, a simple way to help seat the wheel fully is to press down firmly on the handlebars (for the front wheel) or the saddle (for the rear wheel). This action can help push the wheel firmly into the dropouts and centre it.

If your bicycle frame has adjustable dropouts that allow you to position the rear wheel in different places, it's essential to check that the wheel is centred equally between the seatstays and the chainstays before tightening it. You can do this by visually inspecting it, or by using your fingers as makeshift 'feeler gauges'. Slide the same finger from each hand into the gap between the rim (or tyre) and the frame on both sides. If the gaps feel equal, the wheel is likely centred.

Fine-Tuning Brake Alignment: When the Wheel is True

If you've confirmed that your wheels are correctly centred within the frame and fork, but a brake pad is still dragging, the brake caliper itself might have been knocked out of alignment, perhaps due to a bump or impact.

Centering Sidepull Brakes (Common on Road Bikes)

For sidepull brakes, the process is as follows:

1. Locate and loosen the main attaching bolt behind the fork crown (for front brakes) or brake bridge (for rear brakes). This bolt holds the brake caliper to the frame. Loosen it just enough so the brake caliper can be moved sideways by hand.
2. Now, squeeze one of the brake levers. This action will pull the brake pads against the rim.
3. While holding the lever squeezed, carefully tighten the main brake bolt you loosened in step 1. This secures the caliper in its newly centred position.
4. Release the brake lever. The pads should now be equidistant from the rim.

If a minor adjustment is still needed after this, look for a small screw, often located on the top of the brake caliper body. Turning this screw clockwise typically moves the brake pad on that side of the caliper away from the rim, and vice versa. However, remember that this screw is intended for very minor 'fine-tuning' and not for major alignment corrections. If adjusting this screw doesn't resolve the issue, reset it to its original position and re-examine your wheel's centering, as that is the more probable cause of the problem.

Centering Linear-Pull Brakes (Common on Off-Road and Hybrid Bikes)

Linear-pull brakes, also known as V-brakes, have a different adjustment mechanism:

1. On the side of the brake arm, you'll find a small adjustment screw.
2. Turning this screw clockwise will move the brake pad on that particular arm away from the rim. Turning it counterclockwise will move the pad closer to the rim.

Adjust these screws carefully until both pads are centred and have an equal gap from the rim when the brake lever is released.

Eliminating Brake Binding: Ensuring Smooth Operation

Your bicycle brakes should operate smoothly and with minimal effort. The brake pads should retract cleanly and quickly away from the rims as soon as you release the brake levers. If they don't, or if the action feels stiff or 'sticky', it could indicate that the brake pivots or the inner brake cables are dry or dirty, causing binding.

Lubricating Brake Pivots

To free up stiff brake pivots:

1. Apply a small amount of light lubricant (like a bicycle-specific lube or a light machine oil) to the points where the brake arms pivot on the caliper body.
2. Squeeze the brake levers repeatedly. This action helps to work the lubricant into the pivot points.

Critical Warning: Be extremely careful NOT to get any lubricant on the brake pads or the wheel rim. If any lubricant accidentally gets onto these surfaces, wipe them thoroughly clean with rubbing alcohol to ensure proper braking performance.

Lubricating Brake Cables

If lubricating the pivots doesn't solve the binding issue, the problem might lie with the inner brake cable and its housing. This is typically more relevant for rear brake cables, especially those with 'split' housing (where the outer housing is made of two or more sections with visible gaps).

Inspect the brake cable housing where it enters the frame's cable stops. If these stops are split, you can often remove the outer housing section. This allows you to lubricate the inner cable directly. If the housing stops are not split, you'll need to use gravity and a bit of patience:

1. Raise the bike so the frame is oriented such that gravity will help the lubricant flow down the cable housing.
2. Apply a few drops of lubricant directly onto the exposed inner cable where it enters the housing.
3. Squeeze and release the corresponding brake lever repeatedly. This action helps to draw the lubricant into the housing and along the inner cable.
4. Repeat this process for any subsequent sections of housing, and for the front brake cable as well if it exhibits similar stiffness.

For Split Housing Sections:

1. Open the quick-release lever on sidepull brakes or unhook the 'noodle' on linear-pull brakes. This provides extra slack in the system.
2. You should now be able to gently pull on the sections of outer housing, freeing them from the frame's cable stops.
3. Slide the outer housing section (or the front section on bikes with flat handlebars) along the inner cable.
4. Lubricate the inner cable thoroughly where it runs inside the housing. This should eliminate any internal friction and binding.
5. Once lubricated, reconnect the outer housing sections to the frame stops and reassemble the brake mechanism. Your brakes should now feel significantly smoother.

When to Seek Professional Help

While these adjustments can address common brake issues, some problems may require professional attention. If you've followed these steps and your brakes are still not performing optimally, or if you're uncomfortable with any part of the process, please don't hesitate to contact us. Our experienced technicians are ready to service your brakes and ensure your ride is as safe as possible.

Frequently Asked Questions (FAQ)

Q1: My brake pads are worn down. Can I just keep adjusting the barrel adjuster?
A1: No. Barrel adjusters are for minor adjustments to compensate for cable stretch and slight pad wear. Once the pads are significantly worn, they need to be replaced. Continuing to adjust the barrel will not restore proper braking and can even damage the system.

Q2: How often should I check my bicycle brakes?
A2: It's good practice to check your brakes before every ride, especially if you haven't ridden in a while. A quick squeeze of the levers to feel for responsiveness and a visual check of the pads and cables is recommended. For regular riders, a more thorough check and adjustment every few months, or as needed, is advisable.

Q3: What's the difference between adjusting a road bike brake and a mountain bike brake?
A3: The main difference lies in where the barrel adjusters are located. Road bikes often have them on the lever or caliper, while mountain bikes (especially those with linear-pull or V-brakes) might have them on the lever or sometimes on the brake arms themselves. The principle of adjusting pad-to-rim distance remains the same.

Q4: My brakes feel spongy. What could be wrong?
A4: A spongy feel can be caused by several things: stretched cables, contaminated brake pads, or air in the brake system (though this is more common with hydraulic disc brakes). For cable-actuated brakes, check for cable stretch and ensure the pads and rims are clean. Lubricating the cable and pivots can also help.

Q5: My wheels are true, but the brake still rubs. What else could it be?
A5: If the wheel is centred and true, the brake caliper itself might be misaligned with the rim. This usually requires adjusting the caliper's mounting bolt and potentially using the small centering screw on the caliper body, as described in the 'Fine-Tuning Brake Alignment' section above.
