Bosch Diesel Test Benches: A Comprehensive Guide

In the intricate world of diesel engine maintenance and repair, precision and reliability are paramount. For workshops striving to deliver top-tier service, the right diagnostic equipment is not just beneficial; it's essential. Among the leading names in this field, Bosch stands out as a global powerhouse, renowned for its innovation and quality. But who exactly makes these sophisticated Bosch test benches? The answer, while rooted in the extensive network of the Bosch Group, often involves specialised partners who bring these advanced tools to the front lines of automotive service. In the UK and Ireland, Merlin Diesel Systems plays a pivotal role as a national distributor for Bosch Test Benches and Tooling, serving the independent diesel network.

Understanding the Bosch Group's Reach

The Bosch Group is a titan in the technology and service sector, operating across four key business areas: Industrial Technology, Consumer Goods, Mobility Solutions, and Energy and Building Technology. Their global presence, with 129 engineering locations worldwide as of September 2021 and a substantial 2020 sales revenue of €71.5 billion, underscores their dominance and commitment to innovation. This extensive reach means that while Bosch is the overarching brand and innovator, the manufacturing and distribution of specific product lines, like their advanced diesel test benches, are often integrated into specialised divisions or handled by trusted partners who uphold the brand's stringent quality standards.

The Role of Merlin Diesel Systems

For workshops in the United Kingdom and Ireland, Merlin Diesel Systems acts as a crucial link to Bosch's cutting-edge diesel testing technology. As a national distributor, they are instrumental in making Bosch test benches and associated tooling accessible to the independent diesel repair network. This partnership ensures that workshops have access to the latest equipment, backed by expert support and distribution, enabling them to tackle the complexities of modern diesel systems. Merlin Diesel Systems' focus on the independent sector highlights Bosch's commitment to empowering a wide range of automotive professionals.

Key Bosch Diesel Test Bench Models

Bosch offers a range of test benches designed to meet the diverse needs of modern diesel workshops. Let's delve into some of their prominent models:

Bosch DCI 700 Test Bench

Designed with the future of diesel diagnostics firmly in mind, the Bosch DCI 700 is a state-of-the-art test bench capable of handling the latest common rail injector technologies. Its advanced measurement system allows for comprehensive testing of injectors from both passenger cars and commercial vehicles, including those featuring sophisticated technologies like Needle Closing Control (NCC) and Valve Closing Control (VCC). The DCI 700 is engineered for super-efficiency, boasting short mounting and testing times. In fact, it can test up to four common rail injectors in under 15 minutes, a significant time-saver for busy workshops.

Ergonomics have also been a key consideration in the DCI 700's design. It features a tapered base, allowing operators to stand closer to the bench without needing to bend awkwardly to mount injectors. This, along with other user-friendly features, makes the DCI 700 exceptionally easy to operate. The scope of delivery typically includes a high-pressure pump (CP4.2), a CRI accessory kit for both solenoid and piezo CRIs, a 6” LCD Touchscreen, and a swivelling tray for a keyboard and mouse, ensuring a complete and integrated testing solution.

Features Overview of the DCI 700:

• Ergonomic and intuitive design: Facilitates effortless operation.
• Short mounting and testing times: Maximises workshop efficiency.
• Tests all cars and commercial vehicles: Offers broad versatility.
• New technology integration: Ensures futureproofing of equipment.
• Adjustable screen: Allows personalised height and angle settings for each operator.
• Faster, more accurate test measuring: Delivers precise outcomes for injector adjustments.
• Online updates: Keeps test specifications current.
• Bright, dazzle-free workspace lighting: Enhances visibility of leaks and operator comfort.
• Clear and accurate results: Enables printed test reports (printer optional) to demonstrate expertise.
• No need for high-pressure hoses: Contributes to reduced service costs.

The DCI 700's versatility can be further enhanced with optional accessories, allowing it to test CRIN injectors and future generations of these critical components. This includes support for CRIN 1, CRIN 2, CRIN 3, and CRIN 4.2, with provisions for third-party CRI injectors in development.

Bosch EPS 205 Test Bench

For workshops seeking a more economical yet highly capable solution, the Bosch EPS 205 test bench is an excellent choice. It provides immediate and precise results for common-rail diesel components, eliminating the need to send parts out to specialists, thereby reducing turnaround times for customers. The EPS 205 can generate test pressures of up to 1,800 bar, simulating realistic operating conditions. Its automatic cycling through test points and a simple menu for measurement results make it a space-saving machine that streamlines the diagnostic process.

Technicians can quickly and efficiently test, diagnose, and repair diesel faults using this intuitive equipment. The EPS 205 is designed to be an automatic test bench, supporting a wide array of injectors, including CRI Piezo (Bosch, Denso, Siemens, Continental), Solenoid valve CRI, Solenoid valve CRIN (Bosch), Solenoid valve CRI from third-party manufacturers, and DHK/UI nozzles. Its ability to economically test both common-rail diesel injectors and conventional nozzle-and-holder assemblies means workshops can extend their service capabilities significantly with just this one piece of equipment.

Features Overview of the EPS 205:

• Automatic testing: Covers a broad range of injector types.
• Economical testing: Cost-effective for common rail and conventional systems.
• Integrated suction device: Minimises oil misting for a cleaner workshop environment.
• Clear and accurate results: Facilitates professional customer reporting.
• Built-in database: Integrates vehicle and test data for efficient workflows.
• Intuitive interface: Easy for technicians to learn and use confidently.
• 400 V options available: Flexibility to suit different workshop power setups.

Furthermore, the EPS 205 can be used in conjunction with S1000 Coding, offering even greater diagnostic depth and capability.

Bosch EPS 708 Test Bench

The Bosch EPS 708 is a specialist test bench engineered for the rigorous demands of testing common-rail diesel pumps and injectors. It empowers diesel specialists to conduct highly accurate diagnostics on a wide spectrum of diesel components. The bench's advanced electronics ensure precision throughout the testing process, from electronic measurement of injection quantities for cost-effectiveness to electronic regulation across various test stages. Its intelligent self-diagnosis system even prompts technicians when filter changes are required, ensuring the bench operates at peak performance. The EPS 708 is built for excellent performance and longevity.

It is designed to test a comprehensive range of components, including CP1, CP3, CP pumps from Delphi, Denso, and Siemens, Solenoid valve CRIs from Bosch, Delphi, Denso, Solenoid valve CRINs (Bosch), and CRI Piezo injectors from Bosch and Siemens, as well as Denso. The rail is designed for pressures up to 2,500 bar, with the capability to extend current testing pressure levels (2,200 bar) via an add-on kit, ensuring readiness for future developments in diesel technology. Safety is a key feature, with an engine shutdown function that immediately cuts the engine if the hood is opened, protecting users. The EPS 708 also incorporates electronic monitoring of service intervals and offers an optional integrated cooling system for more efficient water usage. Like other Bosch benches, it features a built-in database for efficient workflows and an intuitive interface for ease of use, with 200 V and 400 V options available to match workshop requirements.

Features Overview of the EPS 708:

• Specialist testing: Caters to a wide array of high-pressure pumps and injectors.
• High-pressure capability: Rail designed for up to 2,500 bar, with future-proofing options.
• Engine shutdown feature: Enhances user safety.
• Electronic monitoring: Optimises service intervals and bench efficiency.
• Optional integrated cooling system: Improves water efficiency.
• Built-in database: Streamlines diagnostic workflows.
• Intuitive interface: Ensures ease of learning and operation.
• 200 V and 400 V options: Provides flexibility for workshop setups.

Investing in Quality and Futureproofing

Choosing a Bosch test bench is an investment in accuracy, efficiency, and the future of your workshop's capabilities. These machines are not just tools; they are sophisticated diagnostic platforms that enable technicians to provide precise, reliable service for increasingly complex diesel systems. The collaboration between Bosch's engineering prowess and distributors like Merlin Diesel Systems ensures that workshops in the UK and Ireland have access to the very best in diesel testing technology, empowering them to meet customer demands and stay ahead in a competitive market. Whether it's the advanced capabilities of the DCI 700, the cost-effectiveness of the EPS 205, or the specialist power of the EPS 708, Bosch test benches represent a commitment to quality and a vision for the future of diesel diagnostics.

Frequently Asked Questions

Q1: Who manufactures the core technology behind Bosch test benches?

A1: The core technology, design, and innovation for Bosch test benches originate from the Bosch Group itself, a global leader in automotive technology. While Bosch oversees the development and quality, specific manufacturing and distribution within regions like the UK are often managed through authorised partners.

Q2: How can I purchase a Bosch test bench in the UK?

A2: In the UK and Ireland, Merlin Diesel Systems is a national distributor for Bosch Test Benches and Tooling. You can contact them directly for information on purchasing and support.

Q3: What makes the Bosch DCI 700 suitable for future diesel systems?

A3: The DCI 700 is designed with a new measurement system capable of testing the latest common rail injector technologies, including those with Needle Closing Control (NCC) and Valve Closing Control (VCC). Its ability to be updated and its compatibility with future injector generations via optional accessories make it a future-proof investment.

Q4: Are Bosch test benches easy to use?

A4: Bosch prioritises user experience in its test bench designs. Models like the DCI 700 and EPS 205 feature ergonomic designs, intuitive interfaces, and clear results displays, making them straightforward for technicians to learn and operate efficiently.

Q5: What is the pressure capability of the Bosch EPS 708 test bench?

A5: The Bosch EPS 708 test bench features a rail designed for pressures up to 2,500 bar. It currently supports testing up to 2,200 bar and can be upgraded with an add-on kit to accommodate future increases in diesel technology pressure requirements.
