Unleashing the Potential: The BMW R45 & R65 860cc Performance Kit
The BMW R45 and R65, introduced in 1978, are celebrated for their agility and nimble handling. Their lightweight construction, shorter wheelbase, and reduced width compared to their larger siblings like the R80, R100, and R90S, make them a joy to manoeuvre. However, for many riders, the power output never quite matched the exceptional road-holding capabilities. While the later R65 models, particularly those produced after 1981 boasting 50hp, offered performance levels approaching those of the R80, there remained a desire for more. Enter the 860cc performance kit – a game-changer designed to breathe new life into these beloved Airhead Boxer twins.
This comprehensive kit is engineered as a direct replacement for your existing engine cylinders on Typ 248 BMW R45 and R65 models from 1978 onwards. It represents a significant upgrade, incorporating high-quality components to extract the full potential of the engine's inherent short-stroke design. The result is an engine that not only becomes more powerful but also more tractable, offering a vastly improved and more engaging riding experience. This kit truly transforms the character of these motorcycles, making them a pleasure to ride and unlocking a new level of performance.
What's Inside the 860cc Performance Kit?
The BMW Airhead Boxer 860cc Performance Kit is a meticulously assembled package designed for a straightforward installation. It includes all the essential components to ensure a robust and powerful upgrade:
- Pair of new alloy Nikasil plated cylinders: These high-quality cylinders are the core of the displacement increase, offering superior durability and heat dissipation.
- Pre-fitted stainless pushrod tubes (4): Ensuring reliable operation of the valvetrain, these are conveniently pre-fitted for ease of installation.
- Pair of lighter forged pistons: Forged pistons offer superior strength and lighter weight compared to cast alternatives, allowing the engine to rev more freely. These are designed for a 9.5:1 compression ratio, optimising power output.
- Complete set of piston rings: New rings are crucial for ensuring a proper seal and efficient combustion within the upgraded cylinders.
- Piston gudgeon pins and circlips: These vital components connect the pistons to the connecting rods, ensuring smooth and reliable operation.
- All the necessary gaskets and rubbers: A complete set of gaskets and seals is provided to ensure a leak-free and correct installation of the new components.
The kit is designed as a straight swap, meaning no frame modifications or complex adaptations are required for fitting to the specified R45 and R65 engine blocks. It even accommodates the later post-1985 R65 Monolever and R65 GS models. Crucially, you will need to state your engine number when ordering, as there can be minor differences between model years that the supplier needs to account for.
Performance Gains: What to Expect
The impact of this kit on your R45 or R65 is nothing short of transformative. The increased displacement, combined with the lighter pistons and optimised compression ratio, unlocks significant gains in both power and torque.
For the R65 models, the kit translates into a very noticeable increase of approximately 20% more power. More impressively, the maximum torque is boosted to around 75 Nm at 4200 rpm. This surge in torque makes the bike feel much more responsive and effortless to ride, especially at lower and mid-range revs.
The results for the R45 are even more dramatic. Riders can expect a torque increment of up to a maximum of 70 Nm at 2240 rpm, coupled with an impressive 30% increase in power. This transforms the often-criticised "anaemic" R45, including the R45 N model, into a genuinely spirited and enjoyable machine. The engine's short-stroke advantage is fully exploited, allowing it to rev freely to new highs, making the riding experience a genuine pleasure.
Table: Performance Comparison (Estimated)
To illustrate the impact of the kit, here's an estimated comparison:
| Model | Stock Power (Approx.) | Stock Torque (Approx.) | With 860cc Kit Power (Approx.) | With 860cc Kit Torque (Approx.) |
|---|---|---|---|---|
| R45 (Pre-1981) | 35 hp | 46 Nm | ~45.5 hp (+30%) | ~60 Nm (+30%) |
| R65 (Post-1981) | 50 hp | 57 Nm | ~60 hp (+20%) | ~75 Nm (+31.5%) |
Note: These figures are approximate and can vary based on the specific condition of the donor engine and any other modifications.
Maximising Your Performance Upgrade
While the 860cc kit provides a substantial performance boost on its own, for the ultimate experience, the supplier recommends complementing it with other performance enhancements. Fitting a Sports Camshaft and the recommended Dell'Orto carburettor Conversion Kit can further unlock the engine's potential. These additions work synergistically with the increased displacement to deliver even sharper throttle response, broader power delivery, and an overall more exhilarating ride. Contact the supplier for more details on these complementary upgrades.
Important Considerations for Installation
It is crucial to understand the scope and requirements of this performance kit:
- Compatibility: This kit is exclusively designed as a straight fit for BMW R45 and R65 engines originating from 1978 onwards, including the later R65 GS and Monolever models. It will NOT fit any other BMW Airhead Boxer models, such as the earlier R50 or R60 engine blocks, due to fundamental construction differences. Always verify your engine type before purchasing.
- Specialist Fit Required: The installation of this kit requires specialist knowledge of these engines. Significant expertise and specific BMW Typ 248 engine tools are necessary for correct assembly and fitting. If you are not comfortable with complex engine work or lack the required experience, it is strongly recommended that you entrust this job to a competent and reputable BMW specialist. Incorrect installation can lead to engine damage and void warranties.
A Cost-Effective Alternative?
Beyond the performance benefits, this kit also presents an attractive option if your existing engine cylinders, bores, or pistons are worn out. In such cases, this upgrade kit can offer a lower cost alternative to sourcing and fitting original replacement components. You not only restore your engine to its intended state but also significantly enhance its performance simultaneously.
Frequently Asked Questions
Q1: Will this kit fit my 1977 R75?
No, this kit is specifically designed for the R45 and R65 models from 1978 onwards (Typ 248 engine). It will not fit earlier or different engine displacements like the R75.
Q2: Do I need to machine my crankcase?
No, this kit is designed as a direct replacement for the cylinders and pistons. No machining of the crankcase is required for a standard installation.
Q3: Can I fit this myself?
While possible for experienced mechanics with the right tools and knowledge, it is a specialist job. We highly recommend professional installation by a BMW specialist if you have any doubts about your mechanical capabilities.
Q4: What is the expected lifespan of Nikasil cylinders?
Nikasil plating is known for its excellent durability and wear resistance, often outlasting traditional cast iron liners when properly maintained. They offer superior heat transfer and reduced friction.
Q5: Will this improve my fuel economy?
While the primary goal is performance enhancement, the increased efficiency from new components might lead to slightly improved fuel economy in some cases. However, the significant increase in power and torque will likely encourage more spirited riding, potentially offsetting any gains.
Conclusion
The BMW Airhead Boxer 860cc Performance Kit is an exceptional upgrade for owners of the R45 and R65 models seeking to elevate their riding experience. It addresses the historical power deficit, offering a substantial increase in both horsepower and torque, making these nimble bikes even more engaging and enjoyable. With high-quality components and a design focused on straightforward fitment, this kit represents a compelling investment for those who want to unlock the true potential of their classic BMW.
