05/02/2005
The BMW R50/2 is a classic motorcycle, and like any vintage machine, it has its unique quirks and technical nuances. One such aspect that might puzzle owners is the introduction of rotating valves. If you've been wondering when these were first installed on your R50/2 engine and what exactly they do, you've come to the right place. This article delves into the specifics of rotating valves, their function, and their significance for the R50/2 model.
The Introduction of Rotating Valves on the R50/2
The question of when rotating valves were installed on the R50/2 engine is a common one among enthusiasts. According to Roland Slabon's book on restoring BMW motorcycles, specifically on page 92, rotating valves were introduced in October 1966. This change began with engine number 641473. Therefore, if your R50/2 has an engine number higher than this, it is highly likely to be equipped with rotating valves from the factory.
For instance, if your R50/2's engine number is 641915, as mentioned by Sam Barnes in his query, it falls within the range that would have received rotating valves. This technological advancement aimed to improve the engine's performance and, crucially, its longevity.
What are Rotating Valves and How Do They Work?
Rotating valves, as the name suggests, are valves that slowly rotate during the engine's operation. This rotation is not a rapid spin but a gentle, continuous turning. The mechanism behind this rotation typically involves a special spring retainer or a slight modification to the valve stem or rocker arm assembly that imparts a rotational force to the valve as it opens and closes.
The primary benefit of this rotating action is a form of constant lapping. As the valve rotates, its sealing surface against the valve seat is continuously changing. This dynamic contact helps to:
- Improve Sealing: By distributing wear evenly across the valve face and seat, it helps maintain a tighter seal over time.
- Reduce Hot Spots: The rotation prevents specific areas of the valve from overheating due to constant contact with the hot combustion chamber.
- Enhance Valve Life: The even wear and reduced thermal stress contribute significantly to a longer operational life for the valves and their seats.
- Maintain Efficiency: A good seal is crucial for optimal compression and combustion efficiency. Rotating valves help ensure this efficiency is maintained for longer periods.
Impact on Engine Performance and Maintenance
The introduction of rotating valves on the R50/2 was a subtle but important engineering improvement. While the engine might not feel drastically different in terms of outright power compared to a non-rotating valve equivalent, the long-term benefits are significant for owners and restorers.
Table: Benefits of Rotating Valves
| Benefit | Explanation |
|---|---|
| Improved Durability | Even wear distribution extends valve and seat life. |
| Consistent Sealing | Maintains better compression and combustion efficiency. |
| Reduced Thermal Stress | Helps prevent valve warping and seat recession. |
| Lower Maintenance Frequency | Less frequent valve seat adjustments or repairs needed due to wear. |
When working on an R50/2 with rotating valves, it's important to be aware of their presence. While the basic maintenance procedures for valve adjustments remain similar, understanding their function can help diagnose issues. For example, if you suspect valve issues, the presence of rotating valves might suggest a different wear pattern compared to fixed valves.
Valve Clearance and Alloy Mixture Concerns
The provided text also touches upon a potential issue with valve clearance problems on /2 models prior to 1967, linked to a faulty aluminum alloy mixture. This problem is attributed to the potential for the support towers for the rocker arms to recede into the head if the engine overheats. This recession can lead to a loss of correct head torque and, consequently, a disappearance of valve clearance.
If your R50/2, especially one from the earlier production run before the rotating valve introduction, experiences valve clearance issues, it's crucial to consider the possibility of overheating contributing to this problem. Overheating can cause the rocker arm support towers to sink into the cylinder head. This sinking action effectively reduces the gap that should exist between the rocker arm and the valve stem, leading to the valve being held slightly open. This condition, often referred to as 'tight valves,' can cause a loss of compression, poor running, and potential damage to the valve seats and valves themselves if not addressed.
Key Takeaways Regarding Valve Clearance:
- Overheating is the enemy: Avoid letting your engine overheat. Ensure the cooling system (air cooling in this case) is functioning optimally.
- Check rocker arm support towers: If you suspect valve clearance issues, inspect the rocker arm support towers for signs of recession or damage.
- Maintain proper head torque: Ensuring the cylinder head is torqued correctly is vital for maintaining the integrity of the valve train geometry.
- Proper valve adjustment: Always perform valve adjustments when the engine is cold, using the specified clearances. For the R50/2, typical cold clearances are around 0.10 mm for intake and 0.15 mm for exhaust, but always consult your specific workshop manual.
Distinguishing Between Engine Numbers
To confirm whether your R50/2 has rotating valves, the engine number is the definitive factor. As stated, engines produced from October 1966 onwards, starting with number 641473, were fitted with rotating valves. If your engine number is below this, it likely has conventional, non-rotating valves.
Example Scenario:
- Engine Number: 641000 (Prior to Oct 1966) - Likely has non-rotating valves.
- Engine Number: 641473 (From Oct 1966) - Likely has rotating valves.
- Engine Number: 641915 (As mentioned) - Definitely has rotating valves.
Frequently Asked Questions
Q: Do I need to do anything special when adjusting the valves on an R50/2 with rotating valves?
A: The fundamental procedure for valve adjustment remains the same – ensuring the engine is at Top Dead Center (TDC) on the compression stroke and setting the correct cold clearance. The rotating nature of the valves doesn't alter the adjustment process itself, but it contributes to the longevity of the valve train.
Q: Can rotating valves fail or cause specific problems?
A: While generally beneficial, like any component, they can wear. However, failure is uncommon. If issues arise, they are often related to the overall valve train health (e.g., worn valve guides, damaged seats) rather than the rotation mechanism itself failing.
Q: Are parts for rotating valves readily available?
A: For the most part, replacement parts for the rotating valve mechanism (like specialized spring retainers or keepers) are not commonly needed or easily sourced as separate items. The valves themselves are standard parts, and their rotating feature is inherent to their design. If you need valves, ensure you specify the correct part number for models with rotating valves.
Q: My R50/2 is smoking a bit at idle. Could this be related to the rotating valves?
A: Smoking at idle is more typically related to worn piston rings, valve guides, or worn seals. While rotating valves help maintain sealing, they don't inherently prevent oil consumption caused by worn components in other areas of the engine. It's worth checking your oil consumption and performing a compression test to diagnose such issues.
In conclusion, the introduction of rotating valves in October 1966 marked an important upgrade for the BMW R50/2 engine, enhancing its durability and efficiency through a constant lapping action. Understanding these technical details will help you better maintain and appreciate your classic BMW motorcycle.
