17/09/2023
Keeping Your BMW C650GT in Top Shape
The BMW C650GT is a sophisticated maxi-scooter, offering a blend of comfort, performance, and practicality. While it's built to last, regular and proper maintenance is key to ensuring its longevity and optimal performance. Whether you're a seasoned mechanic or a budding DIY enthusiast, understanding the core maintenance tasks for your C650GT will save you time and money in the long run. This guide will walk you through some of the essential service points, drawing on common experiences and providing helpful tips to make the process smoother.
1. The All-Important Oil Change
Changing the engine oil is arguably the most fundamental maintenance task for any vehicle. For the BMW C650GT, this process is generally straightforward, but there are a couple of nuances to be aware of. You'll typically need 15w50 oil, and a specific filter will be required, which you might need to order in. The main point of attention is the presence of an extra drain hole and an internal tube filter. When removing this tube filter, exercise caution. More importantly, when reinstalling it, ensure it's seated correctly. A clever trick is to use a screwdriver or socket extension to keep the tube in place as you manoeuvre it back into its recess within the engine. This prevents it from dropping into the engine internals, which would be a costly mistake.
2. Effortless Air Filter Replacement
Fortunately, the air filter on the C650GT is refreshingly simple to access and replace. You'll need to remove the upper right-side panel. Once this is off, you can easily locate and remove the air filter cover. Swapping the old filter for a new one is a quick and easy job, requiring no special tools or complex procedures. This is one of those tasks that can be ticked off your maintenance list with minimal fuss.
3. Understanding the Rear Chain Drive
While many scooters feature belt drives, the C650GT utilises a chain drive system. Checking and adjusting the chain tension is crucial for drivetrain efficiency and longevity. You'll find an inspection window on the side of the swinging arm, allowing you to check the chain's slack. If the chain is loose, don't immediately assume you need a new chainset. BMW offers chain rails that can be used to adjust the tension. These are relatively easy to install if you have the service manual. When performing this maintenance, it's advisable to have a replacement swinging arm gasket on hand, although some owners have reported success reusing the original without leaks. The oil within the swinging arm can become quite dirty, but changing it is also a simple process, with drain and fill holes conveniently located on the bottom and top of the unit, respectively. It's a good idea to order a set of chain rails and a spare gasket in advance of starting this job.
4. Tackling the Variator Maintenance
Maintenance involving the belt, rollers, and sliders within the variator can be more involved. This typically requires removing a significant number of panels from the right side of the scooter, as well as the variator covers themselves. Be extremely careful when removing these panels, as the tabs are prone to breaking, and replacement parts can be quite expensive. To properly reassemble the variator cover, you'll need specific tools: a 4-inch long Torx socket set for torqueing the bolts, the BMW-specific variator tool to prevent rotation, and a 33mm socket for removing the main variator bolt. A unique aspect of the BMW variator is the requirement for specific lubrication. You'll need to lubricate one of the splines with Unirex N3 grease. Finding an alternative lubricant for this specific application might be challenging, and BMW is the primary source for this grease. Therefore, ensure you have the correct grease, along with the necessary tools and replacement parts (belt, rollers, sliders), before you begin dismantling the scooter.
5. Gearbox Oil Service
In addition to the chain drive and variator, the C650GT also features a gearbox that requires its own lubrication. This gearbox uses 75w90 gear oil. Accessing the fill plug is generally not too difficult, though you'll likely need a tube or syringe to inject the new oil effectively. The main challenge lies in accessing the drain plug. The exhaust expansion chamber significantly obstructs the plug. While the manual might suggest a complex procedure involving removing side panels, the coolant tank, radiator, centre stand, and the entire exhaust system, there's a potentially simpler method. By disconnecting only the muffler (not the entire exhaust system) and the centre stand, you may be able to lower the exhaust enough to gain access to the drain plug. This can save a considerable amount of time and effort.
6. Spark Plug Replacement Strategy
Replacing the spark plugs on the C650GT also involves a degree of disassembly. The spark plugs are located behind the radiator, meaning you'll need to remove the right-side panels and the coolant tank and radiator to reach them. A smart tip here is to consider performing the spark plug replacement concurrently with the variator maintenance. Since you're already dismantling much of the same area for the variator, combining these tasks minimises the number of times you have to take the panels apart, thereby reducing the risk of damaging any components and saving you valuable time.
Summary of Key Maintenance Points and Tips
| Component | Key Considerations | Helpful Tips |
|---|---|---|
| Engine Oil | Extra drain hole, internal tube filter. | Use a tool to keep the tube filter in place during reinstallation. |
| Air Filter | Easy access via right-side panel. | No special tools required; a straightforward swap. |
| Chain Drive | Chain rails for tension adjustment, gasket. | Order chain rails and a spare gasket in advance. |
| Variator | Requires specific tools (Torx sockets, variator tool, 33mm socket), Unirex N3 grease. | Be careful with panel tabs; have all parts and tools before starting. |
| Gearbox Oil | Obstructed drain plug. | Consider removing only the muffler and centre stand to access the drain plug. |
| Spark Plugs | Located behind the radiator. | Combine with variator maintenance to reduce disassembly. |
Frequently Asked Questions (FAQ)
Q1: How often should I change the engine oil on my BMW C650GT?
Refer to your owner's manual for the specific recommended interval, but generally, an oil change every 6,000-10,000 miles is a good guideline, depending on your riding conditions.
Q2: Can I use a universal grease instead of Unirex N3 for the variator?
It is highly recommended to use the specified Unirex N3 grease. Using an incorrect lubricant could lead to premature wear or component failure in the variator.
Q3: What is the correct tyre pressure for a BMW C650GT?
Tyre pressure can vary depending on load and riding conditions. Always consult your owner's manual or the sticker on the scooter (often found near the swingarm or under the seat) for the manufacturer's recommended PSI for both front and rear tyres.
Q4: How difficult is it to change the drive belt on a C650GT?
Changing the drive belt requires accessing the variator, which involves removing several panels and specific tools. While not overly complex for someone with mechanical experience, it's more involved than a simple oil change. If you're not comfortable with this level of disassembly, it's best left to a qualified technician.
By understanding these key maintenance procedures and following the provided tips, you can keep your BMW C650GT running smoothly and reliably for many miles to come. Regular servicing not only ensures optimal performance but also helps in identifying potential issues before they become major problems.
