Mastering Fuel Bypass in Blown Alcohol Engines

High-performance engines, especially those running on blown alcohol, demand precise fuel management to unlock their full potential and prevent catastrophic damage. At the heart of this intricate system lies the fuel injector bypass, a critical component that dictates fuel mixture under varying engine loads. This comprehensive guide delves into the mechanics of the fuel injector bypass, with a particular focus on its application within Enderle blown alcohol injector systems, ensuring your engine runs optimally, safely, and powerfully. Understanding how to correctly set up and maintain this system is paramount for any serious racer or performance enthusiast.

The Crucial Role of Fuel Bypass

In a high-pressure fuel injection system, the fuel pump often delivers more fuel than the engine can consume, especially at lower RPMs or partial throttle. This excess fuel needs to be managed effectively. The fuel bypass system serves this vital purpose by returning a precisely controlled amount of fuel back to the fuel tank. This not only maintains a stable fuel pressure within the system but, more importantly, allows for the fine-tuning of the air-fuel mixture. Without a bypass, fuel pressure would skyrocket, potentially overwhelming the injectors or causing an excessively rich condition, leading to poor performance or engine damage. Conversely, an improperly set bypass could starve the engine of fuel, resulting in a dangerously lean condition.

Main Bypass Jet: Your Primary Fuel Mixer

The main bypass jet is the cornerstone of your full throttle fuel mixture control. Located typically under a 9/16 hex plug on the metering valve, this small, precisely drilled orifice, often referred to as a "pill," dictates how much fuel is bled off and returned to the tank at wide-open throttle.

• How it Works: When the engine is at full throttle and the fuel pump is delivering maximum volume, the main bypass jet acts as a controlled leak. By allowing a specific amount of fuel to bypass the injectors and return to the tank, it directly influences the effective fuel pressure and, consequently, the fuel flow to the engine.

• Pill Size Matters: The size of the bypass pill is inversely proportional to the richness of your fuel mixture.

  • A larger bypass pill means more fuel is returned to the tank, resulting in a leaner fuel mixture delivered to the engine.
  • A smaller bypass pill means less fuel is returned, leading to a richen fuel mixture.

• Tuning Impact: This adjustment primarily affects the fuel mixture at full throttle and has minimal to no effect on idle or partial throttle response. When installing a new bypass pill, it's crucial to ensure it is fully seated at the bottom of the threads to prevent leaks and ensure consistent performance. Tuning with the main bypass jet is typically done based on dyno runs, oxygen sensor readings, or track performance data, aiming for the ideal air-fuel ratio for maximum power and engine longevity.

The Nuance of the High-Speed Bypass System

While the main bypass jet sets the overall full-throttle mixture, some high-performance applications, particularly those with complex fuel curves or engines that respond differently across the RPM range, benefit from a high-speed bypass system. This system acts as a secondary, fine-tuning mechanism to lean out the fuel mixture at high rpm.

• Components: It consists of a bypass jet (similar to the main bypass pill) controlled by a high-pressure check valve.

• Operation: The check valve opens only when the fuel pressure reaches a certain threshold, which typically corresponds to higher engine RPMs. This pressure threshold is adjustable by adding or removing shims behind the check valve spring.

  • Adding shims: Increases the spring tension, requiring higher fuel pressure to open the valve. This means the high-speed bypass will engage at a higher RPM, leaning the mixture later.
  • Removing shims: Decreases spring tension, allowing the valve to open at lower fuel pressures, thus engaging the high-speed bypass at a lower RPM and leaning the mixture sooner.

• Purpose: The bypass jet within the high-speed system controls the volume of fuel returned once the check valve opens. This allows for precise tailoring of the fuel curve, preventing the engine from becoming overly rich at peak RPMs, which can otherwise rob power or even lead to spark plug fouling. It's a "fine-tuning" device, complementing the broad adjustment provided by the main bypass jet. Think of it as shaping the top end of your fuel delivery curve.

Idle Control: Precision at Standstill

Even a high-performance engine needs to idle smoothly and consistently. The Enderle system provides specific adjustments for idle control, distinct from the full-throttle bypass settings.

• Idle Mixture: This is controlled by a turnbuckle located on the side of the injector.

  • Rotating the turnbuckle towards the rear of the injector (lengthening the linkage) will richen the idle mixture.
  • Shortening the linkage will lean the idle mixture.

  This adjustment affects only the idle and immediate throttle response and has no bearing on full-throttle performance.

• Idle Speed: The actual idle speed is governed by mechanical stops on each end of the butterfly shaft. These stops prevent the butterflies from closing completely, allowing a controlled amount of air into the engine. Butterflies should be set to a slight opening, typically between 0.009 and 0.011 inches.

• Leakdown Percentage: A key metric for setting up the butterflies and metering valve is the leakdown percentage, usually around 68% for most engines, or up to 70% for very large engines with high boost. This is measured with a specific leakdown tester, not an engine cylinder leakdown tester.

Metering Valve Configurations: Nitro vs. Methanol

The Enderle system offers different metering valve designs tailored to the specific characteristics of various fuels, such as Nitro-methane and Methanol. Understanding these differences is crucial for correct plumbing.

For blown alcohol applications, a Spool #17 is typically recommended. It's explicitly advised not to use a Spool #12 or #32.

General Installation Guidelines

Proper installation is as crucial as correct tuning for the reliable operation of your Enderle fuel system.

• Mounting: When installing the injector onto the supercharger, ensure that the mounting bolts are tightened evenly. Uneven tightening can lead to distortion of the injector housing or the supercharger, causing leaks or alignment issues.

• Sealing: Always use a suitable gasket or a high-quality silicone seal between the injector and the supercharger to prevent boost leaks and ensure a perfect seal.

Fuel System Plumbing and Best Practices

The efficiency and safety of your fuel system heavily depend on correct line sizing and component placement.

• Inlet Line: For most fuel pumps, a #12 inlet line is recommended with a -1 size fuel pump. However, larger gear pumps (such as 110, 990, 1100, 1200, or SG2 series) require at least a #12 line, with #16 or even #20 being preferred for optimal flow and pump longevity.

• Pump to Metering Valve: A #8 line should be used for the connection between the fuel pump and the metering valve, ensuring adequate fuel delivery under pressure.

• Return Lines: All return lines in the system, which carry excess fuel back to the tank from bypasses and check valves, should be #6 in size.

• Fuel Tank Placement: For best results, the fuel pump should ideally not be positioned higher than the fuel level in the tank. Furthermore, it is strongly advised against mounting the fuel tank in the rear of the vehicle. Fuel tanks should be located in front of the engine to facilitate consistent fuel supply to the pump, minimising the risk of fuel starvation or cavitation. If a rear-mounted tank is unavoidable, a surge tank is an absolute necessity to maintain a consistent fuel head for the pump.

• Fuel Tank Vent: A properly sized fuel tank vent is critical. It should be ½ inch or larger to allow air to enter the tank as fuel is consumed and to allow vapours to escape, preventing vacuum lock or pressure build-up.

• Crucial Safety Note: Fuel Shutoff: You must use a 3-way fuel shutoff valve with a return line to the fuel tank. A 2-way style shutoff will block the return path, leading to dangerously high fuel pressure that can severely damage the fuel pump and other components in the system.

Maintenance for Longevity

Regular maintenance is paramount to ensure the continued performance and reliability of your Enderle fuel system.

• Draining: The entire fuel system should be thoroughly drained between races or periods of extended storage. This prevents the alcohol (methanol) from absorbing moisture, which can lead to corrosion, and also removes any contaminants that may have accumulated.

• Lubrication: Proper lubrication of the fuel pump and metering valve components is vital to prevent sticking and premature wear. After draining, lubricate the fuel pump with a suitable lubricant such as LPS-3, WD-40, or a light oil. Additionally, remove the inlet line from the metering valve and lubricate the metering piston to prevent it from becoming sticky or drying out, ensuring smooth and consistent operation.

Frequently Asked Questions (FAQs):

Q: What happens if my main bypass jet is too large?

A: A bypass jet that is too large will return too much fuel to the tank, leading to a lean fuel mixture at full throttle. This can result in a loss of power, increased engine temperatures, and potentially severe engine damage due to detonation or pre-ignition.

Q: How do I know if my bypass jet is correct?

A: Determining the correct bypass jet size requires careful tuning, typically performed on a dynamometer or through track testing with proper monitoring equipment (e.g., wideband oxygen sensor, exhaust gas temperature probes). The goal is to achieve the optimal air-fuel ratio for your specific engine and application, balancing power, reliability, and fuel consumption.

Q: Can I use a 2-way fuel shutoff valve with my Enderle system?

A: Absolutely not. Using a 2-way shutoff valve will block the crucial return path for excess fuel, causing extreme pressure build-up within the system. This will inevitably lead to severe damage to your fuel pump and potentially other expensive components. Always use a 3-way fuel shutoff with a return to the tank.

Q: Why is the fuel tank location important?

A: Locating the fuel tank in front of the engine and ensuring the fuel pump is not significantly higher than the fuel level helps gravity feed the pump, preventing cavitation (formation of vapour bubbles) and ensuring a consistent, uninterrupted fuel supply. Rear-mounted tanks often require a surge tank to mitigate these issues.

Q: How often should I lubricate my fuel system components?

A: It is recommended to lubricate the fuel pump and metering piston every time the fuel system is drained, particularly between races or after any period of non-use, to prevent corrosion, sticking, and ensure components move freely.

Conclusion

The fuel injector bypass system, particularly within the sophisticated Enderle blown alcohol injector setup, is far more than just a plumbing component; it is the heart of precise fuel management. From the primary main bypass jet controlling full throttle mixture to the high rpm bypass offering fine-tuned leaning, each element plays a critical role in optimising engine performance and safeguarding against costly damage. Adhering to proper installation, precise adjustment, and diligent maintenance schedules outlined in this guide will ensure your high-performance engine operates at its peak, delivering consistent power and reliability, race after race. Understanding and mastering this system is truly the key to unlocking the full potential of your blown alcohol powerhouse.
