Unlocking EFI Potential for Your MGB B-Series

For many MGB enthusiasts, the allure of modern performance and reliability often leads to contemplating upgrades, and Electronic Fuel Injection (EFI) stands at the forefront of such aspirations. While often associated with modern engine swaps like the M/T16 or K-Series, the idea of fitting EFI to the venerable B-Series engine itself is a fascinating, albeit complex, endeavour. Owners are typically driven by a desire for improved fuel economy, sharper throttle response, more consistent cold starting, and a definitive cure for the dreaded 'run-on' problem that plagues many carburettor-equipped classics.

Unlike simply bolting on a new carburettor, an EFI conversion is a comprehensive undertaking that requires a suite of interconnected components to function correctly. At its core, an EFI system demands a reliable high-pressure fuel supply, precise engine management, and an array of sensors to provide the ECU with real-time operational data. Understanding these fundamental requirements is the first step in appreciating the scope of such a project.

The Core Components of an EFI System

Before delving into the specifics of fitting EFI to a B-Series, it's essential to grasp the basic anatomy of an Electronic Fuel Injection setup. Each component plays a vital role in ensuring optimal fuel delivery and engine performance:

• Fuel Delivery System: This typically involves a modified fuel tank or a dedicated swirl pot, fed by a low-pressure pump from the main tank. A high-pressure fuel pump then delivers fuel to the injection system. A return rail for excess fuel back to the tank is usually required, although some modern in-tank pumps incorporate a bleed-off valve for direct return.
• Engine Management System (ECU): The brain of the operation, the Electronic Control Unit processes data from various sensors and calculates the precise amount of fuel to inject and when to ignite it.
• Sensors: A network of sensors provides the ECU with critical information about the engine's operating conditions. These typically include:
  • Engine Temperature Sensor: Usually reads coolant temperature.
  • Ambient Air Temperature Sensor: Measures the temperature of the incoming air.
  • Manifold Absolute Pressure (MAP) Sensor: Detects changes in manifold pressure, indicating engine load.
  • Throttle Position Sensor (TPS): Informs the ECU about the throttle opening and rate of change.
  • Oxygen (Lambda) Sensor: Fitted in the exhaust downpipe, it measures the oxygen content in the exhaust gases, allowing for closed-loop fuel control to optimise the air/fuel ratio.
  • Crank Position Sensor (CPS): Crucial for timing, often utilising a toothed wheel (e.g., 36-1) on the crankshaft pulley for DIY systems.

The B-Series Challenge: Siamesed Inlet Ports

The primary hurdle in fitting EFI to a standard B-Series engine lies in its unique cylinder head design, specifically the siamesed inlet ports. Unlike modern engines with individual ports for each cylinder, the B-Series shares inlet runners between cylinders. This design can lead to 'charge robbing,' where one cylinder 'steals' fuel/air mixture intended for another, particularly at certain engine speeds and loads. This characteristic complicates precise fuel delivery, which is the cornerstone of EFI.

Experiments with port injection (injectors placed close to the cylinder head, creating a 'dry' manifold only delivering air) on siamesed-ported engines have shown mixed results. While sequential injection (where the ECU precisely controls one fuel squirt per cylinder per induction stroke) offers the best hope for mitigating charge robbing, it necessitates an expensive ECU and large injectors that can deliver a lot of fuel very quickly. As engine speed increases, the precise timing required becomes incredibly challenging. Furthermore, large injectors can suffer from poor atomisation and sensitivity at part-throttle openings, impacting drivability. Consequently, most A-Series and B-Series converters accept the limitations of siamesed ports and opt for an aggregated, 'wet manifold' approach, where fuel is introduced further upstream in the manifold.

Viable EFI Options for the B-Series

Despite the inherent challenges, several approaches have been explored and implemented to bring EFI to the B-Series engine. Each offers a different balance of complexity, cost, and performance potential:

1. Throttle-Body Injection (TBI)

This is often considered the simplest and most straightforward method for a B-Series conversion. TBI systems, as seen in earlier EFI Metros, utilise a combined single throttle-body/injection housing. This unit effectively replaces a single SU carburettor, bolting directly onto a single-carb manifold (or a twin-carb manifold adapted for a single TBI). Being a 'wet manifold' approach, the fuel is introduced higher up in the intake system, before the siamesed ports. The absence of the carburettor's venturi can improve flow rates, and the ECU provides software-based 'needle/jet' adjustment. TBI units often operate at lower fuel pressures, simplifying the high-pressure fuel delivery side of the system.

2. Port Injection (Challenges and Niche Applications)

While ideal for engines with individual inlet ports (like the 1500 Midget), port injection on a standard B-Series head is generally not recommended. Even if space were found on shared runners for two injectors per port, the internal shape of the B-Series head's inlet ports would prevent injectors from spraying directly onto the back of the correct inlet valve. In fact, shared injectors right at the port could potentially exacerbate charge-robbing issues depending on the spray pattern. Unless undertaking a significant cylinder head modification or fitting a cross-flow head, port injection offers limited benefits for the standard B-Series.

3. Direct SU Replacement Throttle Bodies

For those seeking a 'stealth' conversion, some firms offer throttle bodies designed to bolt directly onto existing SU carburettor flanges. Jenvey, for example, produces individual throttle bodies (ITBs) with or without injectors, along with SU flange adapters. While this approach maintains a classic appearance, it can be prohibitively expensive. In many cases, the cost might justify investing in a dedicated cross-flow head and a more suitable multi-throttle body setup, such as motorcycle ITBs.

4. Motorcycle Individual Throttle Bodies (ITBs)

A more creative and often more cost-effective solution, particularly for those with a flair for fabrication, involves adapting motorcycle ITBs. Sets from bikes like the GSXR-600 can be configured to create multi-throttle assemblies, similar to the Sebring triple-Weber setup. These injectors are typically rated for around 50HP per ITB, meaning a pair could adequately fuel a B-Series producing around 100BHP. They can be mounted as direct replacements for twin SUs, offering a bespoke, high-performance EFI solution.

Off-the-Shelf DIY EFI Kits

For those who prefer a more integrated and less bespoke solution, certain manufacturers have developed specific EFI kits for the MGB:

Moss Europe / Webcon Kit

Initially, EFI offerings for the MGB were driven by stringent emissions controls in some American states. However, Moss Europe, in collaboration with Webcon, has introduced a comprehensive 'out of the box' solution that goes beyond just emissions compliance, aiming to enhance overall drivability.

The Webcon kit is a significant advancement, featuring an aluminium cross-flow cylinder head as a central component. This crucial design change fundamentally addresses the siamesed port issue, allowing for true port injection and vastly improved charge distribution. The system then utilises side-draft throttle bodies and Webcon's Alpha management system. Key features include:

• Aluminium Cross-Flow Cylinder Head: A game-changer for B-Series EFI, enabling individual porting and superior airflow.
• 2 x 45mm ALPHA Throttle Bodies: Equipped with State-of-the-Art Weber PICO injectors for precise fuel delivery.
• Webcon Alpha PRO4 Electronic Control Unit: A powerful and modern ECU pre-mapped for most road and fast road driving requirements.
• Improved Throttle Response and Power Delivery: Designed to provide a more managed spread of torque and power, making the MGB more tractable and enjoyable to drive.
• Enhanced Fuel Economy: A direct benefit of more efficient engine management.
• Closed-Loop Lambda Control: Capable of optimising the air/fuel ratio for maximum efficiency and suitability with a catalytic converter if needed.
• Comprehensive Kit: Includes the cylinder head, inlet manifold, throttle bodies, ECU, injectors, wiring harness, and a remote-mounted high-pressure fuel swirl pot.

Further fine-tuning and mapping can be performed by an approved Webcon dealer, allowing for customisation to specific engine builds or driving styles.

Other Options: Extrudabody & TWM Induction

While less detailed information is readily available for these, Extrudabody and TWM Induction are other names that occasionally surface in discussions regarding B-Series EFI conversions. These typically offer various throttle body solutions that might be adapted with a suitable manifold and engine management system.

Comparing EFI Options for the B-Series

To help summarise the options, here's a brief comparison:

The Benefits of EFI on Your B-Series

Beyond the technical challenges, the rewards of converting to EFI on a B-Series engine are compelling:

• Improved Fuel Economy: Precise fuel metering means less waste and better miles per gallon.
• Sharper Throttle Response: No more flat spots or hesitation, just crisp, immediate power delivery.
• Reliable Cold Starting: Gone are the days of fiddling with the choke. EFI provides consistent, easy starts regardless of ambient temperature.
• Cure for Run-On (Dieseling): A common annoyance with carburettors, EFI eliminates fuel delivery once the ignition is off, preventing the engine from continuing to run erratically.
• Consistent Performance: EFI adapts to changes in air density, temperature, and altitude, providing consistent performance that carburettors cannot match.
• Lower Emissions: While not always the primary goal for classic car owners, EFI can significantly reduce harmful emissions, making your MGB more environmentally friendly.

Frequently Asked Questions About B-Series EFI

Q: Why is fitting EFI to a B-Series engine considered difficult?

A: The main difficulty stems from the B-Series engine's siamesed inlet ports. This design means two cylinders share one inlet runner, making precise, individual fuel delivery challenging and potentially leading to 'charge robbing' if not properly managed. Solutions often involve 'wet manifold' systems or, ideally, a cross-flow cylinder head.

Q: What are the primary benefits of converting my MGB to EFI?

A: The key benefits include significantly improved fuel economy, much sharper and more consistent throttle response, vastly improved cold starting reliability, and a definitive cure for engine 'run-on' (dieseling).

Q: Is there an 'off-the-shelf' EFI kit available for the MGB B-Series?

A: Yes, Moss Europe offers a comprehensive Webcon EFI kit specifically designed for the MGB. This kit includes a new aluminium cross-flow cylinder head, throttle bodies, ECU, and all necessary components, providing a complete solution that addresses the siamesed port issue.

Q: Can I install an EFI system myself, or do I need professional help?

A: While basic TBI systems might be manageable for a competent DIY mechanic, a full EFI conversion, especially one involving a cross-flow head or custom ITBs, requires significant technical knowledge, wiring expertise, and often specialist tuning. Professional installation and mapping are highly recommended to ensure optimal performance and reliability.

Q: Is EFI worth the cost for a classic MGB?

A: This depends on your priorities. If your goal is to improve drivability, enhance fuel economy, eliminate common carburettor woes, and enjoy a more modern driving experience from your classic, then the investment in EFI can be highly rewarding. For concourse originality, it may not be the right path, but for a usable and enjoyable classic, it's a strong contender.

Q: Does EFI affect the classic character of the MGB?

A: While EFI undeniably modernises the engine's operation, it typically enhances the driving experience without fundamentally altering the 'feel' of the car. The engine will start easier, run smoother, and respond more predictably, allowing you to enjoy the classic MGB chassis and styling with fewer mechanical frustrations.

Ultimately, fitting EFI to a B-Series engine is a serious upgrade that requires careful consideration and, in many cases, a significant investment. However, for those seeking to unlock better performance, economy, and reliability from their beloved MGB, the rewards can be substantial, transforming the driving experience into something truly exceptional.
