GL1200 Startup Smoke Fix

Understanding Startup Smoke on Your Honda GL1200

Many owners of the venerable Honda GL1200, affectionately known as the "Gold Wing," have encountered a common, albeit sometimes concerning, phenomenon: smoke appearing from the exhaust pipes shortly after starting a hot engine. This can be particularly unnerving, especially if you've invested a significant amount into your machine and are meticulous about its upkeep. While it might seem like a sign of serious internal wear, often this startup smoke is a symptom of a much simpler issue, related to how the engine oil behaves when the motorcycle is shut down and parked.

The GL1200, with its robust engineering, is generally a reliable machine. However, like any complex mechanical device, it has its quirks. One such quirk, as reported by numerous owners and experienced first-hand, is this tendency to produce a puff of blue-tinged smoke upon ignition after a period of being stationary, especially when the engine was warm at shutdown. This article aims to demystify this behaviour and offer a practical, proven solution that doesn't involve expensive engine rebuilds or a switch to a different type of oil, although oil choice can play a minor role.

The Role of Engine Oil and Gravity

The core of the problem lies in the interaction between hot engine oil, gravity, and the boxer engine configuration of the GL1200. When an engine is running, oil is circulated throughout the system to lubricate and cool various components. After a ride, especially on a warm day, the engine oil will be hot and at its lowest viscosity, meaning it flows most freely. The GL1200, with its horizontally opposed cylinders, presents a unique challenge when it comes to oil management during shutdown.

When you shut off a hot engine and immediately place the motorcycle on its side stand (which leans the bike to the left), gravity begins to work on the oil still residing within the engine's internal passages. Unlike an inline-four or a V-twin, the boxer engine's cylinders are positioned horizontally. If the bike is leaned to the left, oil can pool in the lower parts of the engine. Specifically, oil can migrate past the piston rings, particularly the oil control rings, and accumulate in the combustion chambers of the lower cylinders. This is exacerbated by the fact that the ring end gaps, even in a healthy engine, allow for a small amount of oil seepage.

The "Right-Leaning" Shutdown Technique

The good news is that a simple change in your shutdown procedure can often resolve this issue entirely. The key is to prevent oil from pooling in the combustion chambers before the next startup. This is achieved by a subtle, yet crucial, adjustment to how you dismount and park the bike.

Instead of simply pulling up, putting your feet down, and immediately engaging the side stand, try this:

• Pull up to your parking spot.
• Place both feet firmly on the ground.
• Shut off the engine using the handlebar kill switch. This is important as it stops the engine's internal motion and oil circulation.
• Slightly rock the motorcycle to the right. This is the critical step. By nudging the bike to the right, you are momentarily tilting the engine in the opposite direction of the side stand. This action allows any excess oil that might be pooling in the left-side cylinders (due to the engine's configuration) to flow back towards the crankcase or into the right-side cylinders.
• As you pick up your left foot to deploy the side stand, continue to ease the bike back slightly to the left. This ensures the bike settles onto the side stand with minimal stress on the engine's oil system.
• Dismount the motorcycle.

This technique ensures that the oil is not trapped in a position where it can easily seep past the piston rings into the combustion chambers. By tilting the bike slightly to the right before leaning it to the left, you effectively "pour" the oil away from the cylinder walls that will be facing downwards. This preventative measure means that when you start the engine again, there's less oil present to be burned, thus reducing or eliminating the startup smoke.

Oil Viscosity and Quality: A Minor Factor

While the shutdown technique is the primary solution, the type and condition of your engine oil can play a minor role. The user mentioned using Delo 400LE 15W-40 and previously Honda Synthetic HP-4. Both are reputable oils.

Viscosity refers to an oil's resistance to flow. A 15W-40 oil is a common choice for many motorcycles, offering a good balance of protection at different temperatures. While synthetic oils like HP-4 can offer superior high-temperature stability and film strength, the fundamental issue with oil pooling in the GL1200's boxer engine is less about the oil's quality and more about its behaviour under gravity when the engine is hot and shut down.

However, older or lower-quality oils might break down more quickly or have less robust additive packages, potentially leading to slightly increased oil consumption or seepage past worn components. If you were experiencing significant smoke even with the correct shutdown procedure, then reviewing your oil choice and ensuring it meets the manufacturer's specifications would be a logical next step. But for the common startup smoke issue on a GL1200, the shutdown method is usually the most effective fix.

When to Worry: Other Causes of Smoke

It's important to distinguish between the characteristic startup smoke described above and smoke that indicates a more serious engine problem. While the shutdown technique addresses oil seeping into the combustion chambers, persistent or excessive smoke of a different colour could signal other issues:

• Blue Smoke: Usually indicates that oil is burning. This could be due to worn piston rings, worn valve guides, or worn valve stem seals. If you see blue smoke during acceleration or deceleration, not just on startup, it might point to these more significant wear issues.
• White Smoke: Typically indicates that coolant is burning. This is often a sign of a blown head gasket or a cracked cylinder head, allowing coolant to enter the combustion chamber. This is a serious issue that requires immediate attention.
• Black Smoke: Suggests that the fuel mixture is too rich, meaning the engine is burning too much fuel and not enough air. This could be due to clogged air filters, faulty fuel injectors, or incorrect carburettor settings.

If you've adopted the correct shutdown procedure and still experience excessive or discoloured smoke, it's advisable to have your GL1200 inspected by a qualified mechanic. They can perform diagnostics to pinpoint the exact cause of the smoke.

Comparison of Oil Types for GL1200

While the shutdown technique is paramount, understanding oil can be beneficial. Here's a general comparison:

Frequently Asked Questions (FAQs)

Q1: Why does my GL1200 smoke only on startup after it's been ridden and parked?

A1: This is typically due to hot engine oil pooling in the combustion chambers of the horizontally opposed cylinders when the bike is parked on its side stand. This oil then gets ignited and burned on the next startup, producing smoke.

Q2: Is the "right-leaning" shutdown technique really effective?

A2: Yes, this technique has been widely reported by GL1200 owners to be very effective in reducing or eliminating startup smoke. By briefly tilting the engine to the right before engaging the side stand, you encourage oil to drain away from the piston rings and combustion chambers.

Q3: Does the type of oil I use matter for this startup smoke issue?

A3: While a quality oil with good film strength (like a full synthetic) might offer a slight advantage, the shutdown technique is the primary factor in preventing oil from entering the combustion chambers. The specific oil used (Delo 15W-40 or Honda HP-4) is less critical than the parking method.

Q4: How long should I wait after shutting off the engine before parking it?

A4: The procedure suggests shutting off the engine and immediately performing the slight right-lean manoeuvre before placing it on the side stand. Waiting for the engine to cool significantly isn't necessary for this particular fix.

Q5: If I continue to have smoke, what else could it be?

A5: If the startup smoke persists after implementing the correct shutdown procedure, or if the smoke is discoloured (blue, white, or black) or occurs during riding, it could indicate more serious issues such as worn piston rings, valve seals, head gaskets, or fuel mixture problems. In such cases, a professional inspection is recommended.

Conclusion

The occasional puff of smoke from your Honda GL1200's exhaust upon starting a warm engine is often not a sign of impending doom, but rather a characteristic behaviour related to its boxer engine design and how it's parked. By adopting the simple yet effective "right-leaning" shutdown technique, you can proactively manage oil flow and significantly reduce or eliminate this startup smoke. This is a low-cost, high-impact maintenance tip that can help keep your Gold Wing running smoothly and looking its best. Always remember to consult your owner's manual for specific oil recommendations and maintenance procedures, and if in doubt, seek professional advice.
